Lothian II™ User/Service Manual
User & Full Service Manual
Herida Lothian II
Pressure Relieving / Alternating Air Mattress & Pump
Pump Model: HH/P09 Mattress Model: HH/T06
NB: Please ensure this document is fully read & understood
by the Clinician / Carer / Service Engineer prior to use.
1 |
P a g e
A U G U S T 2 0 1 9
Advertisement
Table of Contents
Related Manuals for Herida Healthcare Lothian II HH/T06
Summary of Contents for Herida Healthcare Lothian II HH/T06
- Page 1 Lothian II™ User/Service Manual User & Full Service Manual Herida Lothian II Pressure Relieving / Alternating Air Mattress & Pump Pump Model: HH/P09 Mattress Model: HH/T06 NB: Please ensure this document is fully read & understood by the Clinician / Carer / Service Engineer prior to use. P a g e A U G U S T 2 0 1 9...
- Page 2 Lothian II™ User/Service Manual P a g e A U G U S T 2 0 1 9...
-
Page 3: Table Of Contents
Lothian II™ User/Service Manual CONTENTS SAFETY………………………………………………………4 INTRODUCTION………………………………………….…5 Product Description Application Contra indications Working Principle OPERATION………………………..………………………..6 Static Mode Alternating Mode Profiled Bed – Clinical Considerations Installation Safety Instructions Pump Operation Mattress & Pump Characteristics MAINTENANCE…………………………………………….10 Cleaning Maintenance & Repair Service Interval & Instructions Storage Transportation Other Considerations... -
Page 4: Safety
& these should only be carried out by suitably trained & authorised personnel. For further advice please call Herida Healthcare on Freephone 0800 193 6030. P a g e... -
Page 5: Introduction
This product forms part of a holistic care package and should only be used by trained personnel. For training or further advice contact Herida Healthcare on Freephone +44 800 193 6030. Working Principle The dynamic mattress system consists of a dynamic air pump and an alternating air mattress. The air mattress has three distinct airway chambers: 1. -
Page 6: Operation
Herida Healthcare Customer Services. The clinician must select the correct mattress type at prescription point / patients individual circumstances. -
Page 7: Installation
Lothian II™ User/Service Manual OPERATION Image 1DA (NB: use hand to check ensure appropriate clearance when profiled as below. Add more pressure on the pump if required in order to achieve this. NB: Weight setting is a guide only and cell pressure must also be taken into consideration for individual patients). -
Page 8: Safety Instructions
Lothian II™ User/Service Manual OPERATION Safety Instructions 1. Ensure that there are no sharp objects, fire or abrasive materials in the vicinity. If the mattress is damaged. Remove the patient & transfer to an alternative mode of pressure relief. A foam underlay is provided as standard at the base of the mattress to ensure pressure relief is maintained (to an extent) in the event of a power failure. -
Page 9: Mattress & Pump Characteristics
Lothian II™ User/Service Manual OPERATION Air Leakage / Low Pressure Alarm • After working for 50 minutes and the pressure is lower than 15mmHg, the pump will alarm indicating an initialisation failure. • During normal operation, when the pressure is lower than 6mmHg for 6 minutes, the pump will alarm indicating possible air leakage from the mattress. -
Page 10: Maintenance
Maintenance & repair work should only be carried out by an appointed engineer who have been trained by Herida Healthcare Ltd. and only original manufacturers parts should be used. Failure to do so could result in a void warranty situation. -
Page 11: Storage
Lothian II™ User/Service Manual MAINTENANCE At point of service the following aspects must be maintained to ensure that manufacturer’s warranty remains intact. These can be done in a non-alphabetic way, if all areas are covered: • Ensure the pump unit and mattress / cells are fully decontaminated prior to service and are cleaned in accordance with the schedule provided. -
Page 12: Transportation
Lothian II™ User/Service Manual MAINTENANCE Transportation • Care should be taken when loading, unloading and during transportation & refrain from placing heavy objects on top of the mattresses. • Do not expos to direct sunshine for any period of time when loading and unloading & ensure a cover is used to protect the mattress when raining or snowing. -
Page 13: Routine Checks
Lothian II™ User/Service Manual ROUTINE CHECKS Mattress • Remove top cover and inspect for signs of wear or any tears. • Check zips are still operative & function as normal. • Check integrity of all connectors including cells, tubing and CPR toggle. •... -
Page 14: P09 Pump
Lothian II™ User/Service Manual P09 Pump 14 | P a g e A U G U S T 2 0 1 9... -
Page 15: Warnings & Symbols
Lothian II™ User/Service Manual WARNINGS & SYMBOLS Warning – Follow guidance at all times as per the instructions within the user manual. BF application symbol – Provides a higher degree of protection against electric shock. Class II electrical appliance – Double insulated. Dispose of electrical equipment correctly (WEEE). -
Page 16: Trouble Shooting
Lothian II™ User/Service Manual TROUBLE SHOOTING Issue Possible Cause Possible Resolution • The plug is not • Make sure the power is properly connected. correctly connected and the • Power Cut. voltage is normal. • Await re-connection of • The fuse is broken. power / look at generator. -
Page 17: Company Information
VAT Registration Number: 233587691 Disclaimer Please be aware that all products should be disposed of in an environmentally friendly & infection control manner in compliance with any local or national requirements. Contact Herida Healthcare Ltd. for responsible WEEE disposal methods. 17 |...
