User Manual
MELAtherm
Washer-Disinfector
from software version 3.0.20
EN
Dear customer,
We thank you for your confidence demonstrated by the purchase of this MELAG product. As an owner-run and operated
family concern founded in 1951, we have a long history of successful specialization in hygiene products for practice-
based use. Our focus on innovation, quality and the highest standards of operational reliability has established MELAG
as the world's leading manufacturer in the instrument treatment and hygiene field.
You, our customer are justified in your demand for the best products, quality and reliability. Providing
hygiene"
and
"Quality – made in
agement system is subject to close monitoring: one instrument to this end is our annual multi-day audit conducted in ac-
cordance with EN ISO 13485. This guarantees that all MELAG products are manufactured and tested in accordance with
strict quality criteria.
The MELAG management and team.
®
10 Evolution
Germany", we guarantee that these demands will be met. Our certified quality man-
"competence in
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MELAG MELAtherm 10 Evolution DTA
Summary of Contents for MELAG MELAtherm 10 Evolution DTA
- Page 1 3.0.20 Dear customer, We thank you for your confidence demonstrated by the purchase of this MELAG product. As an owner-run and operated family concern founded in 1951, we have a long history of successful specialization in hygiene products for practice- based use.
-
Page 3: Table Of Contents
Contents Contents 1 General guidelines ................................ 6 Symbols used.................................. 6 Formatting rules ................................... 6 Disposal .................................... 6 2 Safety..................................... 7 3 Performance specifications .............................. 9 Intended use .................................. 9 User benefits .................................. 9 Program sequence................................ 10 Process agents .................................. 11 4 Description of the device.............................. 12 Scope of delivery................................ 12 Views of the device ................................ 12 Symbols on the device ............................... 14 Operating panel and acoustic signal .......................... 16 Menu structure ................................... 19... - Page 4 Contents Removing the load after program end.......................... 41 7 Logging .................................... 42 Batch documentation ................................. 42 Output media.................................. 42 Outputting logs immediately and automatically........................ 44 Subsequent log output ............................... 45 Deleting the saved logs.............................. 45 Determining the format for the program logs ........................ 46 Finding the logs.................................. 48 8 Settings .................................... 49 Settings menu .................................. 49 Log settings.................................. 50 Setting the date and time .............................. 56...
- Page 5 Contents 13 Technical data .................................. 93 14 Accessories and spare parts ............................ 95 15 Documentation and approval ............................ 96 Glossary .................................... 97...
-
Page 6: General Guidelines
Store this user manual carefully and in close proximity to your device. It represents a component of the product. Should the user manual no longer be legible, damaged or lost, obtain a new copy from MELAG. State the device type and your address in an e-mail. -
Page 7: Safety
Use only original MELAG accessories or those from other suppliers authorized for use by MELAG. When using non-MELAG accessories for the mounting of instruments (especially hollow body instru- ments) comply with the information from the manufacturer of the accessories. - Page 8 The fore ventilation slots may not be covered. Never operate the device unattended (e.g. overnight). Unsupervised operation of the device can result in damage to the device or your facility and is performed at your own risk. In such a case, MELAG does not accept any liability.
-
Page 9: Performance Specifications
3 Performance specifications Intended use The MELAtherm 10 Evolution DTA/MELAtherm 10 Evolution DTB is intended for use in a medical context such as a clinic or medical and dental practices. EN ISO 15883- 1 and -2 defines it as a washer-disinfector intended for reprocessing medical instruments prior to their re-use or a further reprocessing step such as sterilization in a steam sterilizer. -
Page 10: Program Sequence
3 Performance specifications Metering monitoring The required amounts of cleaning agent and neutralizer are metered using a hose metering pump. A measuring turbine performs flow monitoring. The rinse aid is metered using a hose pump subject to moni- toring for rotation speed. Drawer for process agents The drawer for the process agents is located in the lower area of the device in which the cleaning agent, neutralizer and rinse aid containers are stored. -
Page 11: Process Agents
Use only suitable process agents. The use of unsuitable process agents can impair the reprocessing results and the damage materials (stain accretion). MELAG recommends using MEtherm process agents. The suitability of the MEtherm process agents for use in MELAtherm has been proven in comprehensive cleaning effectiveness and material- compatibility tests. -
Page 12: Description Of The Device
4 Description of the device 4 Description of the device Scope of delivery Please check the scope of delivery before setting up and connecting the device. Standard scope of delivery ▪ MELAtherm 10 Evolution Washer-Disinfector ▪ User manual ▪ Technical manual ▪... - Page 13 4 Description of the device Slot Ejection button Ethernet data connection Fig. 2: Cover cap slot open Demineralized water (DI water) connection Cold water connection Wastewater connection Transport rollers Ethernet data connection for permanent network connection Mains cable Fig. 3: View from rear...
-
Page 14: Symbols On The Device
4 Description of the device Injector rail connection fitting Cold water (CW) inflow and demineralized (DI) water Salt container Lower rinse arm Coarse and fine sieve Fig. 4: View inside Drying fan pre-filter Assignment of the process agents Container for rinse aid with suction lance Suction lance bracket Container for neutralizer with... - Page 15 - it must be delivered to the vendor to be disposed of. MELAG devices are synonymous for long-term quality. When you eventually need to decommission your MELAG device, we offer a special disposal service. Simply contact your stockist.
-
Page 16: Operating Panel And Acoustic Signal
The serial number of the device and the number (ID) of the event will be displayed following warning and malfunction messages. This is the information that can be transferred to MELAconnect via QR code or which can be transferred manually in the troubleshooting area of the MELAG website, in order to access context-dependent troubleshooting assistance. - Page 17 4 Description of the device LED display and acoustic signals The LED display to the left and right of the the main area issues a colour to indicate the operating state. An acoustic signal is associated with the colour of the LED display and indicates an expected event. Colour of the LED Meaning Blue...
- Page 18 Malfunction Documentation Additional markings that indicate the availability of assistance (e.g. in the user manual, in MELAconnect or on the troubleshooting area in the MELAG website) regarding the issue with which the current QR code message is concerned. Action bar...
-
Page 19: Menu Structure
4 Description of the device Menu structure Main menu Universal-Program Quick-Program Intensive-Program Ophthalmo-Program Rinsing Emptying Conductivity measurement DI Air removal Regeneration Time metering 60 s Log output Output internal log memory Select output medium: automatic CF card MELAprint Computer All logs Last log All malfunction logs Last malfunction log... -
Page 20: Water Softening Unit
4 Description of the device Water softening unit The tap water is processed in the internal water softening unit to produce an optimal cleaning outcome. Use coarse-grain regeneration salt (NaCl) to regenerate the water softening unit. Water hardness conversion table °dH mmol/l °f °e... -
Page 21: First Steps
Record of installation and setup The record of installation and setup is to be completed by the responsible stockist and a copy sent to MELAG as proof of the correct setup, installation and initial commissioning. This is a constituent part of any guarantee claim. -
Page 22: Switching The Device On And Off
5 First steps Switching the device on and off Switch the device on or off at the power switch. Video tutorials The Multimedia menu contains video tutorials which describe the use of this washer-disinfector in a number of operating situations. View of the video control Description Description... -
Page 23: Melaconnect App
▪ Locating malfunctions and accessing solutions and assistance immediately ▪ Performing quick paperless documentation of routine checks of MELAG sealing devices ▪ Contacting the service technician (contact data must be entered manually) In order to connect the MELAconnect app with your MELAG device, see the Connectivity [} page 59] sec- tion. -
Page 24: Manual Door Emergency-Opening
5 First steps Manual door emergency-opening The door can be opened manually in an emergency via the emergency-opening following a power failure or malfunction. Comply with the following during manual door emergency-opening: Escaping steam brings the danger of scalding. Never operate the door emergency-opening mechanism during an active program. A program aborted by door emergency-opening is classed as not having been completed successfully. -
Page 25: Filling The Regenerating Salt
NOTICE Malfunctions of the water softening unit from unsuitable regenerating salt. Fine grain regenerating salt can cause device malfunctions. MELAG does not recommend the use of pellets, as the salt dissolves too slowly. Use only special, coarse grain regenerating salt (additive-free NaCl). -
Page 26: Regenerating The Water Softening Unit
5 First steps Place the filling funnel for the regenerating salt in the opening and fill the salt container. Remove the filling funnel and any excess salt residue from the washing chamber. NOTICE The salt has a corrosive effect on stainless steel. Salt residue must be removed from the washing chamber and the screw cap of the salt container be closed tightly to protect the instruments and the device. -
Page 27: Holding Process Agents Ready
5 First steps Holding process agents ready CAUTION Danger of chemical burns! Inappropriate handling of the process agents can lead to chemical burns and injury to health. Comply with the information from the manufacturer of the process agents. In the case of damage, every type of liquids (e.g. in the drawer, in the device floor trough or liquid issued from the device) could potentially contain aggressive process agents. - Page 28 Unscrew the suction lance from the container and place it in the bracket behind it. Transfer the rinse aid from the original packaging into the MELAG container. Ê Fill the container with rinse aid ¾ full, otherwise the rinse aid will overflow during insertion of the suction lance.
-
Page 29: Removing Air From The Metering System
5 First steps Removing air from the metering system Air must be removed from the metering system during commissioning or after removal of the suction lances. The “Air removal” function removes all air pockets from the hoses and ensures good metering. ü... -
Page 30: Cleaning And Disinfection
Further accessories may be required when reprocessing ophthalmological instruments (not available from MELAG). The operator is responsible for validating the procedure in combination with special load accessories. It is especially important that lines to hollow-body instruments are maintained without kinking and as short as possible. -
Page 31: Arranging The Load
6 Cleaning and disinfection Arranging the load NOTICE Only reprocess instruments designed by their manufacturer for automatic reprocessing in a washer-disinfector. Some brands are only authorized for thermal disinfection after a specific year of manufacture. Comply with the information from the relevant instrument manufacturer. The basis basket must be inserted with insert racks, instrument baskets, wash trays and/or sieve cassettes in order to arrange the load. -
Page 32: Reprocessing Dental Transmission Instruments
Reporcess only those hollow-body instruments which guarantee sufficient and reproducible flushing. Remove instruments with a recognisably reduced throughflow. Use only MELAG adapters to reprocess hollow-body instruments on the injector rail. The suitability of a hollow-body instrument for the respective adapters and the sufficient flushing can only be proven by validation. -
Page 33: Reprocessing Ophthalmological Instruments
6 Cleaning and disinfection Reprocessing ophthalmological instruments Comply with national recommendations for the cleaning of medical products under the aspect of decon- tamination of infectious prion proteins (CJD). WARNING Danger of contamination from biological interactions. Devices used to reprocess ophthalmologic instruments may only be used exclusively for this purpose. -
Page 34: Overview Of Programs
6 Cleaning and disinfection All hollow bodies must be connected with the adapters designed for the purpose. Ensure that plugs and/or cables from Phaco handpieces are not able to slip through the basis basket, otherwise the rinse arm can become blocked. Try to prevent soiling from drying or encrusting on and in the instruments. -
Page 35: Selecting, Starting And Following The Program
6 Cleaning and disinfection Additional Symbol Application Operating time* program Rinsing ▪ For rinsing strongly soiled instruments (e.g. 3 min blood). A disinfection program must then be started. ▪ To rinse out the washing chamber after adding salt; without process agents, no disinfection. Emptying ▪... -
Page 36: Manual Program Abort
6 Cleaning and disinfection Following the program run on the computer You can follow the current progress of a program run on every computer in the (practice) network. To do so, an IP address must be issued for the device and it must be incorporated in the (practice) network. Open a web browser window in the practice PC (we recommend Mozilla Firefox or Internet Explorer / Microsoft Edge). -
Page 37: Authentication And Batch Approval
6 Cleaning and disinfection If a program is aborted during drying, the program is classed as having been ended successfully. Proceed as follows to abort the program during drying: Wait until the display shows Partial cycle: Drying. Press the CANCEL key and confirm the abort with the YES key. - Page 38 6 Cleaning and disinfection Batch assessment and approval with authentication Once the reprocessing program has been completed successfully, you will automatically be asked to evaluate the batch and provide it with approval. Proceed as follows to perform batch assessment with authentication: ü...
- Page 39 6 Cleaning and disinfection Batch assessment and approval without authentication Batch assessment can only be performed without authentication if batch approval is activated and authen- tication has been deactivated. If this is the case, you will be requested to enter your user PIN before batch assessment.
- Page 40 6 Cleaning and disinfection Authentication without batch approval If you do not require an automatically documented batch assessment and approval, you can perform authenticated removal of the load. In this case, the fact of the reprocessed load having been removed by an authenticated user will be documented.
-
Page 41: Removing The Load After Program End
6 Cleaning and disinfection Press the SKIP key. Ê The security query Skip authentication is displayed. Press the YES key. Ê The door is unlocked. Ê The Door unlocked window is displayed. Open the door. Ê The log states User ID: Skipped and Batch approved: NO. Removing the load after program end CAUTION Danger of burns from hot instruments and surfaces. -
Page 42: Logging
[} page 50]). If the program is con- tinued, the logs are deleted automatically; the last ten saved logs remain in the log memory. MELAG recommends outputting logs immediately. Output media You can output the logs of the finished programs via the following output media: ▪... - Page 43 Open the CF card cover cap. Insert the CF card in the slot with the contacts at the front. The MELAG logo on the CF card points towards the LED. Slide the CF card in the card slot until it clicks. Do not use force.
-
Page 44: Outputting Logs Immediately And Automatically
7 Logging Outputting logs immediately and automatically In its delivery state, the MELAflash CF card is set on the device as the output medium in the Settings menu. As such, automatic output of logs after program end (immediate output = yes) is activated. Log output on multiple activated media is performed successively. -
Page 45: Subsequent Log Output
7 Logging Subsequent log output The Log output menu provides the option of deleting and outputting logs subsequently independently of the time of the program end. Proceed as follows: Working in the main menu, press the FORWARDS or BACK key until the Log output menu is displayed. Press the CONFIRM key to open the menu. -
Page 46: Determining The Format For The Program Logs
7 Logging If necessary, press the FORWARDS or BACK key until the All logs window is displayed. Working in the context menu, press the DELETE key. Ê A security query is displayed: Delete all internal log memory logs? Press the YES key to delete all logs. Determining the format for the program logs The log format enables you to determine which of the data saved in the log memory is to be outputted. - Page 47 >> Never change code in following row << Proof of authenticity: 0100002C1B4802BE0306064C0B3C0AD0130D9610 Must never be changed; permits inference that the data 07BD3EFECA15229618881B257A98850427217323 was created on a MELAG device andh as not been 930815C1C892292E3965C071864442576F5F38AC changed. 648A82A3945A3D404141440157A94648AE494AEC >> Proof of authenticity batch log <<...
-
Page 48: Finding The Logs
7 Logging Finding the logs PLEASE NOTE Do not rename the directories, otherwise logs will be stored in both the renamed directory as well as the device directory which the device generates automatically. All memory media (CF card or computer) contain a directory with the encoded serial number of the device concerned following log output. -
Page 49: Settings
8 Settings 8 Settings Settings menu In the Settings menu you can set parameters such as the date, time or display brightness. The following sequence describes general steps for performing settings. Working in the main menu, press the FORWARDS or BACK key until the Settings menu is displayed. -
Page 50: Log Settings
8 Settings Press the YES key to save the settings. Press the NO key to discard the settings. PLEASE NOTE Not all the settings made are saved immediately and automatically, but only upon leaving the Settings menu. Pressing the YES key, saves the settings. Pressing the NO key means that the settings are not saved. - Page 51 8 Settings Press the FORWARDS or BACK key to navigate between yes and no. Press the CONFIRM key to accept the change. Immediate output If you have set an output medium for logging, immdiate output must also be activated. If immdiate output is not active, then none of the output media pre-determined for automatic logging will be used.
- Page 52 8 Settings Press the EDIT key, if this parameter is to be changed. Press the FORWARDS or BACK key to navigate between the formats 0, 1 and 2. Press the CONFIRM key to accept the change. For comprehensive information regarding the log formats 0, 1 and 2, see Determining the format for the program logs [} page 46].
- Page 53 8 Settings MELAtherm IP, computer IP, MELAprint EDM IP, gateway IP, subnet mask This example demonstrates how to set the MELAtherm-IP. The computer IP, MELAprint EDM IP, gateway IP or subnet mask are set in the same fashion. ü The Settings > Log settings > Network menu is open. Working in the Network submenu, press the FORWARDS or BACK key until the MELAtherm-IP window is displayed.
- Page 54 8 Settings Press the EDIT key. Press the FORWARDS or BACK key to navigate between 0 (FTP) and 1 (TCP/IP). Press the CONFIRM key to accept the change. FTP password, TCP port This example demonstrates how to set the FTP password. The TCP port is set in the same fashion. ü...
- Page 55 8 Settings Outputting graphic logs Working in the Graphic logs submenu, you can select the output medium for automatic logging of graphic logs. The following example describes how to select a CF card as an output medium for graphic logs. The selection of a different or a further output medium is performed in accordance with the same procedure.
-
Page 56: Setting The Date And Time
8 Settings Setting the date and time Correct batch documentation requires the correct date and time setting on the device. Setting the date The following example demonstrates the setting of the day parameter. Proceed in the same fashion to set the month and year parameters. -
Page 57: Setting The Display Brightness
8 Settings Press the EDIT key. Press the FORWARDS or BACK key to change the parameter. Press the CONFIRM key to accept the change. Setting the display brightness Proceed as follows to set the display brightness: ü The Settings menu is open. Working in the Settings menu, press the FORWARDS or BACK key until the Display brightness parameter is displayed. -
Page 58: Setting The Idle Mode
8 Settings Setting the idle mode Proceed as follows to set the idle mode: ü The Settings menu is open. Working in the Settings menu, press the FORWARDS or BACK key until the Idle mode in min. Press the EDIT key. Press the FORWARDS or BACK key to change the parameter. -
Page 59: Setting The Volume Of The Key Tone
8 Settings Press the CONFIRM key to accept the change. Setting the volume of the key tone Proceed as follows to set the volume of the key tone: ü The Settings menu is open. Working in the Settings menu, press the FORWARDS or BACK key until the Key tone volume parameter is displayed. -
Page 60: Setting The Language
Alternatively, you can enter the IP address of your device in the MELAconnect app manually. With manual entry of the IP address: Owners of multiple MELAG devices of the identical type can differentiate between their devices by viewing serial number on the display to check whether MELAconnect has been connected to the correct device. -
Page 61: Setting The Water Supply
8 Settings Setting the water supply If the device is connected to a DI water supply e.g. MELAdem 53/MELAdem 53 C or another water treat- ment unit, this must be set on the device. In its delivery state, the water supply is set to DI water yes. PLEASE NOTE This setting is performed by the service technician during device commissioning. -
Page 62: Administrative Settings
8 Settings Press the EDIT key. Press the FORWARDS or BACK key to change the parameter. Press the CONFIRM key to accept the change. Administrative settings Working in the Administration submenu, the administrator can assign user PINs to existing user IDs and can activate or deactivate the authentication and batch approval. - Page 63 8 Settings Logging off as an administrator Proceed as follows to log out as an administrator: ü You are working in the Settings > Administration menu as an administrator. Working in any window, press the LEAVE key until the security query for leaving the settings has been displayed.
- Page 64 Changing an existing admin/user PIN In its delivery state, the admin PIN is set to 1000 as standard. MELAG recommends that you change the admin PIN upon commissioning. The admin PIN (user ID 1) can be changed just as a user ID (user ID 2-20).
- Page 65 8 Settings Press the EDIT key. Working in the action bar, press C until all the digits to be changed have been deleted. Working in the action bar, select digits from 0 to 9 to generate the four-digit PIN. Press the CONFIRM key to assign the altered PIN to the displayed user ID.
- Page 66 8 Settings Authentication The administrator can activate or deactivate user authentication. In its delivery state, authentication is deactivated as standard (= inactive). Activating authentication Proceed as follows to activate authentication: ü You are working in the Settings > Administration menu and are logged on as an administrator, see Administrative settings page 62].
- Page 67 8 Settings Batch approval The administrator can activate or deactivate batch approval. In its delivery state, batch approval is deacti- vated as standard (= inactive). Activating batch approval Proceed as follows to activate batch approval: ü You are working in the Settings > Administration menu and are logged on as an administrator, see Administrative settings page 62].
-
Page 68: Function Tests
9 Function tests 9 Function tests Automatic and manual functional check Automatic The device components are monitored and checked automatically for their functionality and interplay. Should the parameter thresholds be exceeded, the device will issue warnings or malfunction messages. If necessary, it will abort a program with the relevant notification. -
Page 69: Maintenance
10 Maintenance 10 Maintenance WARNING All maintenance work, especially that performed in the washing chamber may only be performed after a successfully completed reprocessing program. Wear suitable personal protective equipment (e.g. gloves). Maintenance intervals Interval Measure Device component Daily Check for soiling, deposits or Coarse and fine sieves, rinse arms, door damage seal... - Page 70 10 Maintenance Check the sieves in the washing chamber A coarse and a fine sieve are fitted in the washing chamber. The sieves are designed to hold back dirt par- ticles or residue e.g. from the instruments. They can become blocked over time. Inspect the coarse and the fine sieves for small components and soiling which have fallen from the load.
-
Page 71: Cleaning On Demand
Check the injector rail nozzles and adapters for free passage MELAG recommends checking the injector rail nozzles and adapters for free passage on a monthly basis. To test whether the injector rail nozzles and adapters are blocked, hold them upright under running water. -
Page 72: Avoiding Staining
To avoid the development of stains and/ or corrosion on the instruments or the washing chamber, MELAG recommends a final rinse with deminer- alized water (DI water) All water-bearing parts of the device consist of non-rusting material. This rules out the development of stains or rust caused by the device. -
Page 73: Maintenance
10 Maintenance Undo the screw on the cover cap of the drying fan by hand and lift up the cover cap. Pull out the pre-filter upwards and change it. Pull out the HEPA filter upwards and change it. Close the cover cap and turn the screw hand-tight. Maintenance NOTICE Continuing operation beyond the maintenance interval can result in malfunctions in the... -
Page 74: (Process) Validation
[} page 11]) can result in increased validation requirements or a renewed performance qualification. ▪ MELAG cannot provide a guarantee for non-MELAG accessories, even if they are in possession of validation. ▪ The validator and technical service can download a “Recommendations for the validation of... -
Page 75: Pause Times
▪ Decommission the device if you plan to have an immobilization time of over two weeks. Decommissioning Preparation for transport Decommissioning in preparation for transport outside the practice should only be undertaken by MELAG- authorized individuals. Following longer operating pauses When decommissioning the device for a long pause (e.g. -
Page 76: Transport Within The Practice
11 Pause times Transport within the practice CAUTION Danger of injury from incorrect carrying. Lifting and carrying too heavy a load can result in spinal injury. Failure to comply with these provisions can result in crushing. Comply with the safety regulations issued by your professional association. Comply with the following provisions pertaining to transport within the practice: Empty the device entirely. -
Page 77: Malfunctions
Not all notifications on the display are malfunction messages. Messages are issued on the display with an event number. The number serves identification purposes for obtaining assistance on the MELAG website (Service > Troubleshooting), the MELAconnect app and when communicating with the authorized customer services or the stockist technician. -
Page 78: Displaying Events In Melaconnect
Should you be unable to find the relevant event, or your efforts do not redress the problem, you can contact your nearest stockist or authorized MELAG customer service provider. Please have your device serial number, the event number and/or a detailed description of the message contained in the notification to hand. - Page 79 12 Malfunctions Event Possible cause Remedy White layer on the The internal water softening unit has not Check the water hardness of the tap instruments been adjusted correctly. water and re-adjust the internal water softening unit if necessary, see Description of the device [} page 12].
-
Page 80: Warnings
The CF card memory is too large (max. Insert a CF card with a memory of up to 4 GB). 4 GB. The MELAG logo must point rightwards during insertion. MELAG recommends using original accessories only. Whilst outputting the logs via the Log... - Page 81 Insert a new CF card (max. 4 GB) in the card slot. The MELAG logo must point rightwards during insertion. MELAG recommends using original accessories only.
- Page 82 The CF card memory is too large (max. Insert a CF card with a memory of up to 4 GB). 4 GB. The MELAG logo must point rightwards during insertion. MELAG recommends using original accessories only. The internal log memory of the device is full.
- Page 83 Setting the date and time [} page 56]. The CF card does not function correctly. Insert a CF card with a memory of up to 4 GB. The MELAG logo must point There is no CF card in the slot. rightwards during insertion. MELAG recommends using original accessories only.
- Page 84 12 Malfunctions Event Possible cause Remedy The system is unable to locate a computer Check the network connection to the for log output. computer / server. The network connection has been interrupted. The computer / server is not switched on. Switch on the computer / server.
-
Page 85: Malfunction Messages
12 Malfunctions Event Possible cause Remedy Insufficient conductivity (> 15 µS/cm and Close the screw cap of the salt container < 25 µS/cm) was measured in the washing correctly. chamber during disinfection in the Setup the containers in the device with Ophthalmo-Program. their openings facing downwards. This could be caused by carry-over of Check the hollow bodies before repro- process agents, regenerating salt or... - Page 86 12 Malfunctions Event Possible cause Remedy The collection tank has not been emptied Switch the device off and then on again. correctly. Start the program again. The coarse or fine sieves are soiled. Switch off the device. Clean the coarse and fine sieves, see Regular checks and cleaning [} page 69].
- Page 87 12 Malfunctions Event Possible cause Remedy The cleaning agent has been exhausted. Replace the cleaning agent container, working in accordance with the working safety regulations. Alternatively, refill. NOTICE! Use only process agents which you have used before. Start the “Air removal” program. No cleaning agent is pumped.
- Page 88 12 Malfunctions Event Possible cause Remedy Water is in the pump pit after pumping out. Clean the coarse and fine sieves, see Regular checks and cleaning [} page 69]. The coarse or fine sieves are soiled. The non-return valve in the pump pit is Insert the non-return valve in the pump pit missing or fitted incorrectly.
- Page 89 12 Malfunctions Event Possible cause Remedy The water inflow is insufficient. Check the water inflow of the device. The water inflow tap has not been opened Open the water inflow tap completely. completely. The sieve in the cold water connection is Remove and clean the sieve in the cold water blocked.
- Page 90 12 Malfunctions Event Possible cause Remedy The rinse pressure in the washing chamber is Check the water inflow of the device. Open the too low. water inflow tap completely. The water inflow is insufficient. The basis basket has been inserted incorrectly Insert the basis basket in the washing or not at all.
- Page 91 12 Malfunctions Event Possible cause Remedy The fine sieve has been fitted incorrectly. Insert the fine sieve correctly. The arrow on the fine sieve must point towards the left-hand corner of the washing chamber. The upper / lower rinse arm is mechanically Check the freedom of motion of the upper / blocked.
- Page 92 12 Malfunctions Event Possible cause Remedy The coarse or fine sieves are soiled. Remove and clean the coarse and fine sieves, see Regular checks and cleaning [} page 69]. Switch the device off and then on again. Start the program again. The water inflow was interrupted during the Open the water inflow tap completely.
-
Page 93: Technical Data
13 Technical data 13 Technical data MELAtherm 10 Evolution DTA/DTB device dimensions Device types Semi-integrated unit Free standing Top-frame device Device dimensions 81.8 x 59.8 x 68.1 cm 83.6 x 59.8 x 68.1 cm 124 x 59.8 x 68.1 cm... - Page 94 13 Technical data Device types MELAtherm 10 Evolution DTA MELAtherm 10 Evolution DTB Wastewater Wastewater connection DN21 Max. wastewater temperature 93 °C (< 1 min, approx. 7 l) Amount of wastewater per hour approx. 38 l (in short intervals) Capacity of drain pump max.
-
Page 95: Accessories And Spare Parts
14 Accessories and spare parts 14 Accessories and spare parts You can obtain the specified articles together with an overview of further accessories from your stockist. Information regarding the instrument reprocessing accessories can be found in the current MELAG price list. Article Art. -
Page 96: Documentation And Approval
15 Documentation and approval 15 Documentation and approval B*** Program / Process Process Instru- Remarks Signature load success- approved? ments ful? approved? reprocessed on: partially reprocessed on: partially reprocessed on: partially reprocessed on: partially reprocessed on: partially reprocessed on: partially reprocessed on: partially reprocessed on:... -
Page 97: Glossary
The term “authorized technician” refers to an em- ployee of a customer service provider or stockist Process agents who has been trained and authorized by MELAG A process agent is a composition of chemical com- to perform maintenance and installation work on pounds for designed for reprocessing purposes MELAG devices. - Page 98 MELAG Medizintechnik GmbH & Co. KG Geneststraße 6-10 10829 Berlin Germany Email: info@melag.com Web: www.melag.com Original instructions Responsible for content: MELAG Medizintechnik GmbH & Co. KG We reserve the right to technical alterations Your stockist...
