Summary of Software
Features
Switch 4950 —
Front View Detail
Table 4 summarizes the software features that are supported by the
Switch 4950.
For information about using the software features of the Switch, refer to
the "SuperStack 3 Switch Management Interface Reference Guide" on
the CD-ROM that accompanies the Switch.
Table 4 Software features
Feature
Resilient Links
Aggregated Links
Broadcast Storm Control Supported
Virtual LANs (VLANs)
Multicast Filtering
Spanning Tree Protocol
RMON
Management
Figure 1 Switch 4950 — front view
WARNING: RJ-45 Ports. These are shielded RJ-45 data sockets. They
cannot be used as standard traditional telephone sockets, or to connect
the unit to a traditional PBX or public telephone network. Only connect
RJ-45 data connectors, network telephony systems, or network
telephones to these sockets.
Either shielded or unshielded data cables with shielded or unshielded
jacks can be connected to these data sockets.
Switch 4950 — Front View Detail
Switch 4950
Supported
Support for four groups of four ports per unit
Support for up to 30 VLANs using the IEEE 802.1Q
standard
128 Multicast filter groups supported
■
IGMP filtering supported
■
Supported
Seven groups supported: Statistics, History, Alarms,
Hosts, Hosts Top N, Matrix, Events
Web interface, command line interface, and SNMP
supported
