GETTING TO KNOW YOUR DATA LOGGER
USB port
LCD
Button
Connectors
USING THE SOFTWARE
Windows™ 7/8/10 (32 & 64bit)
Visit www.easylogusb.com and click 'Download'.
Quick Start Guide
Battery cover
screw
EL-USB-ACT
INSTALLING YOUR BATTERY
The EL-USB-ACT is supplied with two AA
batteries fitted. To begin use the battery
tab must be removed as shown below.
Advertisement
Table of Contents
Related Manuals for EasyLog EL-USB-ACT
Summary of Contents for EasyLog EL-USB-ACT
- Page 1 EL-USB-ACT Quick Start Guide GETTING TO KNOW YOUR DATA LOGGER INSTALLING YOUR BATTERY The EL-USB-ACT is supplied with two AA USB port batteries fitted. To begin use the battery tab must be removed as shown below. Battery cover screw Button...
- Page 2 SELECTING A CURRENT CLAMP The EL-USB-ACT is compatible with most current clamps which output an AC or DC mV signal proportional to the amount of current the clamp is detecting. It is advisable to select a current clamp which features 4mm banana plugs for quick connection to the EL-USB-ACT; otherwise banana plugs must be manually fitted in order to connect to the data logger.
