64 C 4: C
HAPTER ONFIGURING THE
To configure the Voice VLAN settings for ports:
Select Voice VLAN Mode, and Security settings.
1
Select the ports you would like to apply these
2
settings to.
Click Apply.
3
Figure 51 QoS Port Setup Screen
Port Detail
Use the Port Detail tab to display the Voice
VLAN information for selected ports.
S
WITCH
Figure 52 QoS Port Detail Screen
OUI Summary
Use the OUI Summary tab to display the list of
Organizational Unique Identifier for a company
and their description.
Figure 53 QoS OUI Summary Screen
