Merit FORCE Upright Removal/Installation Instructions

OBSERVE PRECAUTIONS FOR HANDLING ELECTROSTATIC DEVICES
Removal/Installation of Motherboard -
1. Turn off and unplug the game.
2. Unlock and open the bezel.
Fun Zone games and Fusion games with electronic boxes only: Remove the 2 screws
fastening the electronics box cover and move the cover aside.
3. Disconnect all connections to the motherboard, as well as any other connectors that may
interfere with removal of the board.
4. Using Figure 1, remove the 4 screws fastening the I/O board (the I/O board will be on the top
or left edge of the motherboard). Then carefully move the board aside until you're able to
remove the 2 standoffs fastening the edge of the motherboard to the game (see Figure 2).
5. Remove the 2 screws fastening the other edge of the motherboard to the inside of the game
(see Figure 1), then carefully lift the motherboard out of the game and insert the board into an
anti-static bag for storage. NOTE: Be sure to read the Motherboard Handling Precautions
before handling the board.
1. Place the new motherboard in the game and fasten one side with the 2 screws and the other
side with the 2 standoffs (see Figures 1 and 2) .
2. Fasten the I/O board and with the 4 screws (see Figure 1).
3. Reconnect all connections to the motherboard, as well as any harnesses that were discon-
nected earlier.
4. Close and lock the bezel.
Fun Zone games and Fusion games with electronic boxes only: Replace the the electronics
box cover and fasten with the 2 screws .
5. Plug in and turn on the game.
Troubleshooting Information - Removal/Installation of Motherboard -
Megatouch FORCE Technical Reference Manual
COPYRIGHT © 2004 MERIT INDUSTRIES, INC.
ATTENTION:
FORCE Upright Fusion/Fun Zone

Motherboard Removal

Motherboard Installation

FORCE Upright Fusion/Fun Zone
