Merit FORCE Upright Removal/Installation Instructions

OBSERVE PRECAUTIONS FOR HANDLING ELECTROSTATIC DEVICES
Removal/Installation of Touchscreen -
(Fun Zone games and Fusion games with electronic boxes)
1. Turn off and unplug the game.
2. Unlock and open the bezel.
3. Remove the 6 thumbnuts fastening the bezel to the game (see Figure 1) and remove the
bezel.
4. Remove the cable clamp securing the touchscreen cable and the touchscreen power harness,
then remove the screws fastening the touchscreen controller (see Figure 1) to the game and
disconnect the cable from the back of the controller. Locate and disconnect the Molex connector
(orange and gray wires) running from the touchscreen controller cable to the main power
harness (you will need to remove the wires from the cable clamps keeping the harnesses in
place), and also disconnect the ground screw. See Figure 1.
5. Use dental floss to carefully cut the foam tape holding the touchscreen to the monitor until you
are able to completely remove the screen. Once the touchscreen is completely free from the
monitor, remove any residual foam tape from the monitor with denatured alcohol.
(Fun Zone games and Fusion games with electronic boxes)
1. Clean the glass on the new LCD monitor with the supplied alcohol wipe, then cut pieces of the
supplied 1/2" foam tape long enough to cover each edge of the monitor without overlapping.
After the tape is in place on the monitor, peel off the backing. Carefully place the touchscreen
over the monitor in the same manner it was attached to the old monitor, making sure the
screen is properly and evenly aligned over the glass. Clean the front of the touchscreen with
the supplied alcohol wipe once it is in place.
2. Connect the touchscreen cable in the back of the controller and secure the controller with the
existing hardware. Also connect the Molex connector (orange and gray wires) to the main
power harness (after routing the wires through the cable clamps) and attach the ground screw.
See Figure 1.
3. Reinstall the bezel on the game and fasten it with the 6 thumbnuts.
4. Plug in and turn on the game.
5. When the game is finished booting, press the CALIBRATE button.
6. Close and lock the bezel, then calibrate the touchscreen.
Troubleshooting Information - Removal/Installation of Touchscreen -
Megatouch FORCE Technical Reference Manual
COPYRIGHT © 2004 MERIT INDUSTRIES, INC.
ATTENTION:
FORCE Upright Fusion/Fun Zone

Touchscreen Removal

Touchscreen Installation

FORCE Upright Fusion/Fun Zone
