Merit The Vibe Removal/Installation Instructions

OBSERVE PRECAUTIONS FOR HANDLING ELECTROSTATIC DEVICES
NOTE: Do NOT attempt to remove the monitor or motherboard from The Vibe. If these
components need to be replaced, contact Merit Customer Service at 1-800-445-9353 or (215)
639-4700 outside the USA and Canada to arrange to have your game sent in for repair.
1. Turn off and unplug the game.
2. Unlock the lock on the processor cover and loosen the 3 screws on either side of the cover
(see Figure 1). Slide the cover away from the connector side of the processor and lift the cover
off of the unit.
3. Remove the 3 screws securing the hard drive to the processor (see Figure 2).
4. Disconnect the SA0345-01 I/O and audio harness, then remove the hard drive assembly until
you're able to disconnect the hard drive ribbon cable and hard drive power connector. See
Figure 2.
5. Remove the 4 screws and shoulder washers fastening the hard drive to the mounting plate.
1. Fasten the new hard drive to the mounting plate with the 4 screws and shoulder washers.
2. Connect the ribbon cable and power connector to the hard drive, then reconnect the audio
harness.
3. Fasten the hard drive to the processor with the 3 screws (see Figure 2).
4. Replace the processor cover and tighten the 3 screws (see Figure 1).
5. Plug in and turn on the game.
Troubleshooting Information - Removal/Installation of Hard Drive -
COPYRIGHT © 2004 MERIT INDUSTRIES, INC.
ATTENTION:
Removal/Installation of Hard Drive -
The Vibe and Vibe w/ Coin

Hard Drive Removal

Hard Drive Installation

The Vibe and Vibe w/ Coin
