  • Page 1 POWERPAINTER 90 EXTRA SKID ORIGINAL- BETRIEBSANLEITUNG wagner-group.com...
  • Page 2 PowerPainter 90 EXTRA Skid POWERPAINTER 90 EXTRA OPERATING INSTRUCTIONS wagner-group.com Reduziert die Abnutzung der Kolbenstangen und Pumpendichtungen Reduces wear on cylinders rods and pump packings Réduit I‘usure des cylindres, des tiges et des bourrages de pompe Verminderd slijttage aan de...
  • Page 3 PowerPainter 90 EXTRA Skid PRIME SPRAY SPRAY...
  • Page 4 PowerPainter 90 EXTRA Skid 25 - 30 cm 25 - 35 cm 25 - 30 cm 25 - 30 cm...
  • Page 5 PowerPainter 90 EXTRA Skid...
  • Page 6 PowerPainter 90 EXTRA Skid Translation of the original operating instructions Warning! Attention: Danger of injury by injection! Airless units develop extremely high spraying pressures. Danger Never put your fingers, hands or any other parts of the body into the spray jet! Never point the spray gun at yourself, other persons or animals.

  • Page 7: Explanation Of Symbols Used

    PowerPainter 90 EXTRA Skid Congratulations on your purchase of a WAGNER colour application device. You have purchased a proprietary device that requires careful cleaning and care to ensure trouble-free functioning. Read the operating instructions carefully before using the tool and observe the safety instructions. Keep the operating instructions in a safe place.

  • Page 8: Flammable Materials

    PowerPainter 90 EXTRA Skid 3. Safety of Persons a) Be attentive. Pay attention to what you are doing and work sensibly with a power tool. Do not use the tool if you are tired or under the influence of drugs, alcohol or medication. Just a moment of inattentiveness while using the tool can lead to serious injuries.
  • Page 9 PowerPainter 90 EXTRA Skid Explosion protection Do not use the unit in work places which are covered to the explosion protection regulations. Danger Danger of explosion and fire through sources of flame during spraying work There may be no sources of flame such as, for example, open fires, smoking of cigarettes, cigars or tobacco pipes, sparks, glowing wires, hot surfaces, etc.
  • Page 10 PowerPainter 90 EXTRA Skid For reasons of function, safety and durability, only use genuine WAGNER high-pressure hoses and spray nozzles. For overview see „Spare parts lists“. The risk of damage rises with the age of the high-pressure hose. Wagner recommends replacing high-pressure hoses after 6 years.
  • Page 11 Flammable materials In order to ensure compatibility of the coating substance with the materials used to manufacture the device, please contact Wagner Service in cases of doubt. Field of application Coating interior walls and outside objects (e.g. garden fences, garage doors, etc.).

  • Page 12: Spray Gun

    PowerPainter 90 EXTRA Skid Assembly 1. Remove the protective covers on the hose and hose connection. (Fig. 2) 2. Screw the pressure gauge to the hose connection. 3. Screw the high pressure hose onto the pressure gauge. Keep hold of the connection using an adjustable spanner and tighten the hose connection with another spanner. (Fig. 3) 4.

  • Page 13: Spray Technique

    PowerPainter 90 EXTRA Skid 9. Fix the return line using the suction hose clips. (Fig. 14) 10. Turn the switch to the SPRAY position (horizontal). 11. Aim the spray gun at a piece of cardboard and switch the device on.

  • Page 14: Taking Out Of Operation And Cleaning

    PowerPainter 90 EXTRA Skid Taking Out of Operation and Cleaning Proper cleaning is the prerequisite for problem-free operation of the paint application device. No warranty claims are accepted in case of improper or no cleaning. Do not use flammable materials for cleaning purposes.
  • Page 15 PowerPainter 90 EXTRA Skid b) Servicing the pump Repair kits (Fig. 26) Description Order No. Repair kit for piston pump (Pos. 5,6,7,8,9,10,11) 2325 023 Repair kit for seals (Pos. 8,9) 2324 303 Always wear protective eye wear while servicing the pump. Be sure to follow the Pressure Relief Procedure when shutting the unit down for any purpose, including servicing or adjusting.
  • Page 16 Sieve package (5 pcs) for paint 34952 Sieve package (5 pcs) for dispersion 34951 Easy Glide (118 ml) 0508619 Further information about the WAGNER range of products for renovating is available under www.wagner-group.com Technical Data Pump type Piston pump Power source 230 V...

  • Page 17: Environmental Protection

    PowerPainter 90 EXTRA Skid electric tools. The oscillation level is also for determining an initial assessment of the vibrational strain. Attention! The vibration emission value can differ from the specified value when the electric tool is actually in use, depending on how the electric tool is being used.
  • Page 18 (Status 01.02.2009) 1. Scope of guarantee All Wagner professional colour application devices (hereafter referred to as products) are carefully inspected, tested and are sub- ject to strict checks under Wagner quality assurance. Wagner exclusively issues extended guarantees to commercial or profession- al users (hereafter referred to as “customer”) who have purchased the product in an authorised specialist shop, and which relate to...
  • Page 19 PowerPainter 90 EXTRA Skid incorrect assembly and/or commissioning by the buyer or by a third party, or utilisation other than is intended, abnormal ambient conditions, unsuitable coating materials, unsuitable operating conditions, operation with the incorrect mains voltage supply/ frequency, over-operation or defective servicing or care and/or cleaning.
  • Page 20 PowerPainter 90 EXTRA Skid EU Declaration of conformity We declare under sole responsibility that this product conforms to the following relevant stipulations: 2006/42/EC, 2014/30/EU, 2011/65/EU, 2012/19/EU Applied harmonised norms: EN ISO 12100, EN 1953, EN 60204-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-3 The EU declaration of conformity is enclosed with the product.
