Specifications; Ordering Information - 3Com 4005 Datasheet

3 C O M ® S W I T C H 4 0 05 D ATA S H E E T

Specifications

Ordering Information

Dimensions
Height: 22.23 cm (8.75 in)
Width: 43.94 cm (17.3 in)
Depth: 43.68 cm (17.2 in)
Weight: 22.68 kg (50 lb)
Performance
24 Gbps total bandwidth
18 Mpps forwarding
performance
RIP v1 and RIP v2
OSPF
UDP/DHCP Helper
DVMRP Multicast Routing
Access Control Lists
256 VLANs
Link Aggregation (802.3ad
trunking)
Fast Spanning Tree Protocol
802.1p and 802.1Q
802.3x flow control
Power
300 W AC Power Supply
Input voltage: 90-264 VAC,
autoranging
Operating frequency: 47-63 Hz
Maximum input current: 6 A at
100 VAC; 3.1 A at 200 VAC
Maximum Power Consumption
455 W (1,553 Btu/hour)
3Com Switch 4005 40-Port Copper
Fast Ethernet Starter Kit (RJ-45 connectors)
Software
Switch 4005 v2.0 Advanced Software
For units running earlier versions to upgrade
to version 2.0 features
Modules
Switch 4005 8-port 10/100BASE-TX Module
(RJ-45)
Switch 4005 8-port 100BASE-FX Module
(MT-RJ)
Switch 4005 2-Port 1000BASE-T Module
(RJ-45)
Switch 4005 2-Port 1000BASE-SX Module
(MT-RJ)
Switch 4005 2-Port GBIC Module**
(GBIC)
**GBIC ordered separately.
3Com Corporation, Corporate Headquarters, 350 Campus Drive, Marlborough, MA 01752-3064
To learn more about 3Com solutions, visit www.3com.com. 3Com Corporation is publicly traded on NASDAQ under the
symbol COMS.
Copyright © 2004 3Com Corporation. All rights reserved. 3Com is a registered trademark of 3Com Corporation. The 3Com
logo is a trademark of 3Com Corporation. All other company and product names may be trademarks of their respective
companies. While every effort is made to ensure the information given is accurate, 3Com does not accept liability for any
errors or mistakes which may arise. All specifications and other information in this document is subject to change without
notice.
Environmental Ranges
Operating temperature:
0° to 50°C (32° to 122°F)
Operating humidity:
10% to 90% noncondensing
Storage temperature:
-40° to 70°C (-40° to 158°F)
Storage humidity:
10% to 90% noncondensing
SNMP Standards
SNMP Protocol (RFC 1157)
MIB-II (RFC1213)
Bridge MIB (RFC 1493)
RMON MIB II (RFC 2021)
Remote Monitoring MIB
(RFC 1557)
MAU MIB (RFC 2239)
Electromagnetic Compatibility
The Switch 4005 is certified
with the following standards:
CE Mark
Australian Declaration of
Conformity for tick-mark
Emissions
FCC, Part 15 Subpart B, Class A
Canada, ICES003, Class A
VCCI Class A
EN 55022/CISPR 22, Class A
AS/NZS 3548, Class A
CNS 13438, Class A
Korea No. 34, Class A
Spare Components
3C16830
Switch 4005 Chassis/Power Supply/
Fan/Fabric/Management
Switch 4005 300-Watt Power Supply
3C16844
Switch 4005 Fan Assembly
Switch 4005 Fabric/Managment Module
GBICs
3Com 1000BASE-SX GBIC
3C16828
3Com 1000BASE-LX GBIC
3Com 1000BASE-T GBIC
3C16829
3Com 1000BASE-LH70 GBIC
3C16841
3C16842
3C16843
Safety
CSA/NRTL (UL1950, CSA
22.2.950, 3rd Edition)
TUV/GS (EN 60950, 3rd Edition,
including Amendments and
Annexes ZB, ZC; with GS Mark
(Bauart Mark for power
supplies)
CB Report/Certificate to IEC
60950, including all national
deviations
Management
3Com Network Supervisor (trial
copy provided on accompanying
CD)
Backup and Restore
Web Management
Command line interface
SNMP
Four RMON groups
Warranty
One year hardware warranty;
ninety (90) days software
warranty. Refer to
3com.com/warranty for details.
3C16820
3C16822
3C16823
3C16824
3CGBIC91
3CGBIC92
3CGBIC93A
3CGBIC97
400670-012 05/04
