AN5516-06
Optical Line Terminal Equipment
Hardware Description
Version: A
Code: MN000000814
ZyXEL FiberHome
May 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FiberHome AN5516-06 and is the answer not in the manual?

Questions and answers

Related Manuals for ZyXEL Communications FiberHome AN5516-06

Summary of Contents for ZyXEL Communications FiberHome AN5516-06

  • Page 1 AN5516-06 Optical Line Terminal Equipment Hardware Description Version: A Code: MN000000814 ZyXEL FiberHome May 2011...

  • Page 2: Preface

    Preface Related Documentation Document Description AN5516-06 Optical Line Introduces the retrieval method, contents, releasing, Terminal Equipment reading approach, and suggestion feedback method for Documentation Guide the complete manual set for the AN5516-06. Introduces the AN5516-06's network location, functional features, hardware structure, FTTx application model, AN5516-06 Optical Line...
  • Page 3 Document Description Introduces the method for configuring the EPON services supported by the equipment via ANM2000 Network AN5516-06 Optical Line Management System, such as basic configuration, voice Terminal Equipment EPON service configuration, data service configuration, multicast Configuration Guide service configuration, software upgrading configuration, to guide users on start-up for various...

  • Page 4: Version

    Version Version Description Initial version. Intended Readers This manual is intended for the following readers:  Planning and designing engineers  Commissioning engineers  Operation and maintenance engineers To utilize this manual, these prerequisite skills are necessary:  Electrical safety knowledge ...

  • Page 5: Conventions

    Conventions Terminology Conventions Terminology Convention AN5516-06 AN5516-06 Optical Line Terminal Equipment ZyXEL FiberHome e-Fim ANM2000 Broadband Access ANM2000 Network Management System EC4B 4×EPON-C Interface Card (type B) EC8B 8×EPON-C Interface Card (type B) GC4B 4×GPON-B Interface Card (type B) GC8B 8×GPON-C Interface Card (type B) C155A 1×STM-1 Optical Interface Card (CES Mode)

  • Page 6: Table Of Contents

    Contents Preface ........................I  Related Documentation ..............I  Version ..................III  Intended Readers ................III  Conventions ..................IV  1  Cabinet ......................1-1  1.1  Appearance ..................1-2  1.2  Size and Weight ................1-5  1.3  Structure ..................1-6  1.4  Typical Layout ................1-12  1.5 ...
  • Page 7 4  Card ......................4-1  4.1  Appearance and Structure ............. 4-2  4.2  Card Configuration Table ............... 4-7  4.3  HSWA Card ..................4-8  4.4  EC4B Card ................... 4-12  4.5  EC8B Card ................... 4-16  4.6  GC4B Card .................. 4-20  4.7  GC8B Card .................. 4-24  4.8 ...
  • Page 8 Appendix A Abbreviation ................... A-1 ...
  • Page 10 Figures Figure 1-1 An illustration of the 19-inch cabinet ..........1-2 Figure 1-2 An illustration of the 21-inch cabinet ..........1-3 Figure 1-3 An illustration of the 21-inch antidust cabinet ......... 1-4 Figure 1-4 The 19-inch cabinet ............... 1-6 Figure 1-5 The 21-inch cabinet ...............
  • Page 11 Figure 5-2 The ground cable ................5-3 Figure 5-3 The protection earth ground cable ..........5-3 Figure 5-4 The end of the cabinet power cable connected with the PDP ..5-3 Figure 5-5 The subrack power cable ............... 5-4 Figure 5-6 The subrack protection earth ground cable ........
  • Page 12 Tables Table 1-1 The size and weight of the cabinets ..........1-5 Table 1-2 Descriptions of alarm indicator LEDs on the top of the 19-inch cabinet ....................... 1-7 Table 1-3 Descriptions of alarm indicator LEDs on the top of the 21-inch cabinet .......................
  • Page 13 Table 4-18 The GC4B card technical specification ........4-22 Table 4-19 The GC8B card interfaces ............4-24 Table 4-20 The GC8B card indicator LEDs ............ 4-25 Table 4-21 The GC8B card key ..............4-25 Table 4-22 The GC8B card technical specification ........4-26 Table 4-23 The HU1A card interfaces ............
  • Page 14 Table 5-2 The corresponding relationship between the card and the fiber jumper ..................5-11 Table 5-3 Signal description associated with the E1 interface pin ....5-13 Table 5-4 The wiring scheme of the straight-through network cable .... 5-17 Table 5-5 The wiring scheme of the cross-over network cable ....

  • Page 16: Cabinet

    Cabinet This chapter introduces the AN5516-06 cabinet and includes the following contents: Appearance Size and weight Structure Typical layout Ventilation principle Version: A...

  • Page 17: Appearance

    AN5516-06 Optical Line Terminal Equipment Hardware Description Appearance The AN5516-06 can be mounted in a 19-inch cabinet or a 21-inch cabinet. Figure 1-1 illustrates the appearance of the 19-inch cabinet. Figure 1-1 An illustration of the 19-inch cabinet Version: A...

  • Page 18: Figure 1-2 An Illustration Of The 21-Inch Cabinet

    1 Cabinet Figure 1-2 illustrates the appearance of the 21-inch cabinet. Figure 1-2 An illustration of the 21-inch cabinet Version: A...

  • Page 19: Figure 1-3 An Illustration Of The 21-Inch Antidust Cabinet

    AN5516-06 Optical Line Terminal Equipment Hardware Description Figure 1-3 illustrates the appearance of the 21-inch antidust cabinet. Figure 1-3 An illustration of the 21-inch antidust cabinet Version: A...

  • Page 20: Size And Weight

    1 Cabinet Size and Weight Table 1-1 provides the size and weight of each type of cabinet. Table 1-1 The size and weight of the cabinets Cabinet Type Size (H×W×D) Hardware Number Weight (Empty Cabinet) 1600mm×600mm×600mm 4.102.596 94kg 2000mm×600mm×600mm 4.102.597 109kg 19-inch cabinet 2200mm×600mm×600mm...

  • Page 21: Structure

    AN5516-06 Optical Line Terminal Equipment Hardware Description Structure The structure and components of the 19-inch cabinet are illustrated in Figure 1-4. (1) Mounting hole for the top-connection bent angle bracket (2) Wiring hole (top) (3) Ventilation hole area (top) (4) LED (top) (5) ESD protection earth ground fastener (6) Mounting hole on the vertical mounting flange (7) Wiring hole(bottom)

  • Page 22: Table 1-2 Descriptions Of Alarm Indicator Leds On The Top Of The 19-Inch Cabinet

    1 Cabinet Three alarm indicator LEDs are installed on the top of the cabinet. Table 1-2 describes the meaning and status of each alarm LED. Table 1-2 Descriptions of alarm indicator LEDs on the top of the 19-inch cabinet Color Meaning Status Description...

  • Page 23: Figure 1-5 The 21-Inch Cabinet

    AN5516-06 Optical Line Terminal Equipment Hardware Description (1) Wiring hole (top) (2) LED (top) (3) ESD protection earth ground fastener (4) Rear door (5) Wiring channel (6) Wiring hole (bottom) (7) Mounting hole on the vertical mounting flange (8) Front door (9) Mounting hole for the top-connection bent angle bracket (10) Ventilation hole (top) Figure 1-5...

  • Page 24: Table 1-3 Descriptions Of Alarm Indicator Leds On The Top Of The 21-Inch Cabinet

    1 Cabinet Three alarm indicator LEDs are installed on the top of the cabinet. Table 1-3 describes the meaning and status of each alarm LED. Table 1-3 Descriptions of alarm indicator LEDs on the top of the 21-inch cabinet Color Meaning Status Description...
  • Page 25 AN5516-06 Optical Line Terminal Equipment Hardware Description (1) Wiring hole (top) (2) LED (top) (3) Wiring channel (4) Rear door (5) ESD protection earth ground fastener (6) Mounting hole on the vertical mounting flange (7) Wiring hole (bottom) (8) Front door (9) Mounting hole for the top-connection bent angle bracket (10) Ventilation hole (top) Figure 1-6...

  • Page 26: Table 1-4 Descriptions Of Alarm Indicator Leds On The 21-Inch Antidust Cabinet

    1 Cabinet Three alarm indicator LEDs are installed on the top of the cabinet. Table 1-4 describes the meaning and status of each alarm LED. Table 1-4 Descriptions of alarm indicator LEDs on the 21-inch antidust cabinet Color Meaning Status Description An emergency alarm in equipment Emergency...

  • Page 27: Typical Layout

    AN5516-06 Optical Line Terminal Equipment Hardware Description Typical Layout Cabinets of different specifications can house different number of AN5516-06 subracks. A cabinet can hold up to two subracks. Figure 1-7 Typical layout of the 19-inch cabinet 1-12 Version: A...

  • Page 28: Figure 1-8 Typical Layout Of The 21-Inch Cabinet

    1 Cabinet Door lintel PDP (100) Empty (≥100) AN5516-06 subrack Door lintel (300) PDP (100) Door lintel Empty (≥100) Empty (≥100) PDP (100) AN5516-06 subrack AN5516-06 subrack Empty (≥100) Door lintel (300) (300) PDP (100) AN5516-06 subrack Empty (≥100) Empty (≥100) Empty (≥100) (300) AN5516-06 subrack...

  • Page 29: Ventilation Principle

    AN5516-06 Optical Line Terminal Equipment Hardware Description Ventilation Principle The principle of ventilation inside the cabinet is illustrated in Figure 1-9 and Figure 1-10. A flow of air is forced by the air guide unit at the lower part of the subrack into the cabinet.

  • Page 30: Figure 1-9 An Illustration Of Ventilation Principle For A 19-Inch Cabinet

    1 Cabinet Figure 1-9 An illustration of ventilation principle for a 19-inch cabinet Version: A 1-15...

  • Page 31: Figure 1-10 An Illustration Of Ventilation Principle For A 21-Inch Cabinet

    AN5516-06 Optical Line Terminal Equipment Hardware Description Figure 1-10 An illustration of ventilation principle for a 21-inch cabinet 1-16 Version: A...

  • Page 32: Pdp

    This chapter introduces the AN5516-06 PDP and includes the following contents: Function Structure Power connector Alarm terminal Lightning-protection module Specifications Version: A...

  • Page 33: Function

    AN5516-06 Optical Line Terminal Equipment Hardware Description Function The PDP used by the AN5516-06 is PDP296B. It inducts two channels of -48V power (active and standby) from the external (e.g. the power cabinet) and provides three sets of redundant branch power rails (six branch power rails totally) for three subracks.

  • Page 34: Structure

    2 PDP Structure The structure of the PDP296B is illustrated in Figure 2-1 and Figure 2-2. Note: After being installed with different mounting ears, the PDP296B can be mounted in a 19-inch cabinet or a 21-inch cabinet. Figure 2-1 The PDP structure Connectors, switches and other components are provided on the panel of the PDP, as shown in Figure 2-2.

  • Page 35: Figure 2-2 The Pdp Panel

    AN5516-06 Optical Line Terminal Equipment Hardware Description Figure 2-2 The PDP panel JP1 is the jumper pin for selecting the working status indicator LED of the PDP. It can be set in the following two ways:  Short pin1 and pin2 of JP1, the green LED on the top of the cabinet will indicate the working status of the PDP.

  • Page 36: Power Connector

    2 PDP Power Connector 2.3.1 Main and Branch Power Supply Connector Posts  Table 2-1 introduces the external power input connectors. Table 2-1 Introduction to external power input connectors Connector Introduction Active and standby -48V external power input connector. The -48V _A, -48V _B -48V _A and -48V _B connectors back up each other.

  • Page 37: Automatic Circuit Breaker

    AN5516-06 Optical Line Terminal Equipment Hardware Description 2.3.2 Automatic Circuit Breaker The branch power automatic circuit breaker (ACB) is located on the front panel of the PDP, as shown in Figure 2-3. Figure 2-3 The PDP front panel Version: A...

  • Page 38: Alarm Terminal

    2 PDP Alarm Terminal  Subrack alarm aggregation terminal The three RJ45 sockets AlmIn1 to Almln3 on the PDP are subrack alarm aggregation terminals.  Alarm output terminal (connected to the head of row cabinet) The alarm output terminal (connected to the head of row cabinet) XP1 is a three-conductor D-type socket.

  • Page 39: Specifications

    AN5516-06 Optical Line Terminal Equipment Hardware Description Specifications Table 2-3 shows the relevant specifications of the PDP. Table 2-3 The PDP specifications Item Parameter Range of input voltage -38V to -60V Input Input mode Inducts two channels of power (active and standby). features Maximum input current The maximum current of a single channel of power is 96A.

  • Page 40: Subrack

    Subrack This chapter introduces the AN5516-06 subrack, and includes the following sections: Structure Size and weight Subrack configuration Fan unit Version: A...

  • Page 41: Structure

    AN5516-06 Optical Line Terminal Equipment Hardware Description Structure The hardware number of the subrack is 3.061.098. The structure and names of various components of the subrack are illustrated in Figure 3-1. Figure 3-1 Subrack structure Size and Weight Table 3-1 shows the size and weight of the subrack. Table 3-1 The size and weight of the subrack Item...

  • Page 42: Subrack Configuration

    3 Subrack Subrack Configuration The subrack configuration and slot distribution are illustrated in Figure 3-2. Figure 3-2 An illustration of subrack configuration The AN5516-06 subrack provides altogether 14 slots. Slot 21 is a vertical slot and located on the upmost left side of the subrack. It is dedicated for the fan card. Other horizontal slots are distributed like this: Slots 19 and 20 on the top of the subrack are specially for the uplink card;...

  • Page 43: Fan Unit

    AN5516-06 Optical Line Terminal Equipment Hardware Description Fan Unit 3.4.1 Function Located on the left side of the subrack, the fan unit is used for forced air cooling. The fan unit supports intelligent progressive speed control with 8 speed choices. Depending on the ambient temperature, it changes the speed to adjust air flow and properly cool the equipment.

  • Page 44: Specifications

    3 Subrack 3.4.3 Specifications Table 3-2 provides the size, weight and power consumption of the fan unit. Table 3-2 Fan unit parameter table Item Parameter Fan size (Width×Height×Depth) 58.3 mm×244.3 mm×224.3mm Fan weight 1.84kg The maximum power consumption is 64W. The Fan power consumption typical power consumption is 20W when the input voltage is -48V and the current is 0.42A.

  • Page 46: Card

    Card This chapter introduces the functions, interfaces, indicator LEDs, keys and technical specifications of all cards used in the AN5516-06. It includes the following sections: Appearance and structure Card configuration table HSWA card EC4B card EC8B card GC4B card GC8B card HU1A card HU2A card GU6Fcard...

  • Page 47: Appearance And Structure

    AN5516-06 Optical Line Terminal Equipment Hardware Description Appearance and Structure The AN5516-06 cards can be classified into four categories as per the height of the card panels. Table 4-1 Classification of the AN5516-06 cards Height of Card (mm) Example Card Refer to EC4B Figure 4-1...

  • Page 48: Figure 4-1 Appearance And Structure Of The Ec4B Card

    4 Card Figure 4-1 Appearance and structure of the EC4B card Version: A...

  • Page 49: Figure 4-2 Appearance And Structure Of The Hu1A Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description Figure 4-2 Appearance and structure of the HU1A card Version: A...

  • Page 50: Figure 4-3 Appearance And Structure Of The Pwr Card

    4 Card Figure 4-3 Appearance and structure of the PWR card Version: A...

  • Page 51: Figure 4-4 Appearance And Structure Of The Cio Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description Figure 4-4 Appearance and structure of the CIO card Note: The card number is indicated in a tag attached to the lower part of the PCB. Version: A...

  • Page 52: Card Configuration Table

    4 Card Card Configuration Table Table 4-2 The AN5516-06 card configuration table Type Slot Symbol Card Number Remarks Performs the aggregation, switch and management traffic flow; processes Layer-2 protocols; Core switch card 9, 10 HSWA 2.115.334 manages the troubleshooting, performance and configuration of the equipment.

  • Page 53: Hswa Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description HSWA Card Main functions  Provides a RS-232 interface to connect a local CLI network management system computer.  Supports multiple management VLANs and multiple management IPs.  Supports up to twelve GE uplink interfaces or four 10GE uplink interfaces. ...
  • Page 54 4 Card Interface description Table 4-3 The HSWA card interfaces Symbol Meaning Description Local Management Serial Used connect network Console Interface management computer. Local Management Ethernet Used to connect an out-of-band ANM2000 Interface network management computer. Indicator LED description Table 4-4 The HSWA card indicator LEDs Symbol Meaning...

  • Page 55: Figure 4-5 The Location Of The Key On The Hswa Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description Key description Table 4-5 The HSWA card key Symbol Meaning Description Card reset key For resetting the card. The mounting side The panel side Figure 4-5 The location of the key on the HSWA card Caution: The reset operation may result in interruption of all services carried by the AN5516-06.
  • Page 56 4 Card Technical specifications Table 4-6 The HSWA card technical specifications Item Specification IEEE802.3, IEEE802.3u, IEEE 802.3z, IEEE802.3x, IEEE Network standards 802.1d, IEEE802.1p and IEEE 802.1q, etc. Working modes supported 10/100/1000Mbit/s, 10Gbit/s (full duplex) Switching mode Store-and-Forward Capacity of the core switch 488Gbit/s card Backplane switch rate...

  • Page 57: Ec4B Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description EC4B Card Main function  Provides four EPON interfaces.  Supports multiple services including data, voice and IPTV.  Supports IGMP proxy / snooping multicast and controllable multicast.  Supports real-time DBA.  Provides flexible QoS and SLA. ...

  • Page 58: Table 4-8 The Ec4B Card Indicator Leds

    4 Card Indicator LED description Table 4-8 The EC4B card indicator LEDs Symbol Meaning Color Status Description The card is working normally. The card is initializing or the software is starting. The communication link Blinking between the active card and the slowly standby card has not been established Working...

  • Page 59: Figure 4-6 The Location Of The Keys Of The Ec4B Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description Key description Table 4-9 The EC4B card keys Symbol Meaning Description For EPON1 system reset. May result in Reset EPON interruption of the connected ONU services of interfaces 1 & 2 EPON interfaces 1 & 2. For EPON2 system reset.
  • Page 60 4 Card Technical Specification Table 4-10 The EC4B card technical specification Item Specification IEEE802.3, IEEE802.3ah, IEEE802.3u, IEEE 802.3z, Network standard IEEE802.3x, IEEE 802.1d, IEEE802.1p, IEEE 802.1q, etc. Working mode supported Full duplex / half duplex Switching mode Store-and-Forward Maximum package Wire-speed forwarding forwarding rate MAC address...

  • Page 61: Ec8B Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description EC8B Card Main function  Provides eight EPON interfaces.  Supports multiple services including data, voice and IPTV.  Supports IGMP proxy / snooping multicast and controllable multicast.  Supports real-time DBA.  Provides flexible QoS and SLA. ...
  • Page 62 4 Card Indicator LED description Table 4-12 The EC8B card indicator LEDs Symbol Meaning Color Status Description The card is working normally. The card is initializing or the software is Blinking starting. communication link slowly between the active card and the standby card has not been established yet.
  • Page 63 AN5516-06 Optical Line Terminal Equipment Hardware Description The panel side The mounting side Figure 4-7 Location of the key of the EC8B card Caution: The reset operation may result in interruption of all ONU services carried by the EC8B card. The reset operation is generally conducted in course of the card maintenance and upgrade.
  • Page 64 4 Card Item Specification Maximum split ratio 1:64 Maximum LLID Bandwidth allocation 64kbit/s granularity Optical fiber SC/PC connector 1000BASE-PX10: G.652 single-mode fiber, transmission distance ≥10km Network cable 1000BASE-PX20: G.652 single-mode fiber, transmission distance ≥20km Power consumption ≤70W Working temperature 0℃ to 45℃ Ambient temperature -30℃...

  • Page 65: Gc4B Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description GC4B Card Main function  Provides four GPON interfaces.  Supports multiple services including data, voice and IPTV.  Supports IGMP proxy / snooping multicast and controllable multicast.  Supports real-time DBA.  Provides flexible QoS and SLA. ...
  • Page 66 4 Card Indicator LED description Table 4-16 The GC4B card indicator LEDs Symbol Meaning Color Status Description The card is working normally. The card is initializing or the software is starting. The communication link Blinking between the active card and the slowly standby card has not been established Working...

  • Page 67: Figure 4-8 Location Of The Key Of The Gc4B Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description The panel side The mounting side Figure 4-8 Location of the key of the GC4B card Caution: The reset operation may result in interruption of all ONU services carried by the GC4B card. The reset operation is generally conducted in course of the card maintenance and upgrade.
  • Page 68 4 Card Item Specification Maximum Alloc ID 1k/PON Maximum Port ID 4k/PON Bandwidth allocation granularity Optical fiber connector SC / PC Network cable G.652 single-mode fiber Power consumption ≤44w Working temperature 0℃ to 45℃ Ambient temperature for storage -30℃ to 60℃ Ambient humidity for storage 10% to 90% Version: A...

  • Page 69: Gc8B Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description GC8B Card Main function  Provides eight GPON interfaces.  Supports multiple services including data, voice and IPTV.  Supports IGMP proxy / snooping multicast and controllable multicast.  Supports real-time DBA.  Provides flexible QoS and SLA. ...
  • Page 70 4 Card Indicator LED description Table 4-20 The GC8B card indicator LEDs Symbol Meaning Color Status Description The card is working normally. The card is initializing or the software starting. Blinking communication link between the slowly active card and the standby card has not been established yet.
  • Page 71 AN5516-06 Optical Line Terminal Equipment Hardware Description The panel side The mounting side Figure 4-9 Location of the key of the GC8B card Caution: The reset operation may result in interruption of all ONU services carried by the GC8B card. The reset operation is generally conducted in course of the card maintenance and upgrade.
  • Page 72 4 Card Item Specification Maximum split ratio 1:64 Maximum Alloc ID 1k/PON Maximum Port ID 4k/PON Bandwidth allocation granularity Optical fiber SC / PC connector Network cable G.652 single-mode fiber Power consumption ≤60W Working temperature to 45 ℃ ℃ Ambient temperature to 60 ℃...

  • Page 73: Hu1A Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description HU1A Card Main function  Provides four GE uplink optical / electrical interfaces and one 10GE uplink optical interface. The four GE uplink optical interfaces support the replacement of GE optical / electrical module; uplink optical interfaces 3 and 4 are self-adaptive to the opposite-end equipment.
  • Page 74 4 Card Symbol Meaning Color Status Description The port is linked up. The uplink port is transmitting Port status Blinking data to or receiving data from the LNK1-5 Green LEDs quickly upper level equipment, example, switches. The port is not linked up. mode 10GE interface.

  • Page 75: Hu2A Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description HU2A Card Main function  Provides two GE uplink optical / electrical interfaces (replace the optical / electrical module to select the optical / electrical interface) and two 10GE uplink optical interfaces.  Each uplink interface can be used as an in-band network management interface to connect a network management computer.
  • Page 76 4 Card Symbol Meaning Color Status Description The port is linked up. The uplink port is transmitting data Port status Blinking to or receiving data from the upper LNK1-5 Green LEDs quickly level equipment, example, switches. The port is not linked up. WAN / LAN The WAN mode of 10GE interface.

  • Page 77: Gu6F Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description 4.10 GU6F Card Main function  Provides six GE uplink optical / electrical interfaces. Users can replace the optical / electrical module to select the corresponding optical / electrical interface. Of these interfaces, the optical interfaces 3 and 4 are auto negotiate to rates 10/100/1000M.
  • Page 78 4 Card Symbol Meaning Color Status Description The port is linked up. The uplink port is transmitting data Port status Blinking to or receiving data from the upper LNK1-6 Green LEDs quickly level equipment, example, switches. The port is not linked up. Technical specification Table 4-31 TheGU6F card technical specification...

  • Page 79: Ce1B Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description 4.11 CE1B Card Main function  Provides 32 E1 uplink interfaces.  Supports E1 circuit emulation.  Supports four clock acquisition modes: Clock extraction from the input E1 line, external input reference clock, internal free running clock and clock received from other clock cards.

  • Page 80: Figure 4-10 Location Of The Key Of The Ce1B Card

    4 Card Key description Table 4-34 The CE1B card key Symbol Meaning Description For card reset. May result in interruption of all hosted Reset key of the card services. The panel side The mounting side Figure 4-10 Location of the key of the CE1B card Caution: The reset operation may result in interruption of all services carried by the CE1B card.
  • Page 81 AN5516-06 Optical Line Terminal Equipment Hardware Description Item Specification Delay Loopback delay <3ms Bit error ratio Free of bit error in 24 hours. Power consumption ≤40W Working temperature to 45 ℃ ℃ Ambient temperature for storage to 60 ℃ ℃ Ambient humidity for storage 10% to 90% 4-36...

  • Page 82: C155A Card

    4 Card 4.12 C155A Card Main function  Provides two STM-1 uplink optical interfaces and implements 1+1 protection.  Supports E1 circuit emulation.  Supports four clock acquisition modes: clock extraction from the input E1 line, external input reference clock, internal free running clock and clock received from other clock cards.
  • Page 83 AN5516-06 Optical Line Terminal Equipment Hardware Description Symbol Meaning Color Status Description card resetting Alarm experiencing an alarm. indicator The card is working normally. The optical interface is linked up. Blinking The optical interface is transmitting Port status LNK1-2 Green quickly or receiving data.
  • Page 84 4 Card Caution: The reset operation may result in interruption of all services carried by the C155A card. The reset operation is generally conducted in course of the card maintenance and upgrade. It is not recommended that the user directly issue a reset command using the reset key. Technical Specification Table 4-39 The C155A card technical specification...

  • Page 85: Puba Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description 4.13 PUBA Card Main function Provides interfaces for signals of 14 dry contacts. Interface description Table 4-40 The PUBA card interfaces Symbol Meaning Description Environmental DC1-DC14 Used to connect dry contact signals. monitoring interface Reserved for debugging.

  • Page 86: Figure 4-12 Location Of The Key Of The Puba Card

    4 Card The panel side The mounting side Figure 4-12 Location of the key of the PUBA card Caution: The reset operation may result in interruption of all services carried by the PUBA card. The reset operation is generally conducted in course of the card maintenance and upgrade.

  • Page 87: Cio Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description 4.14 CIO Card Main function  Provides the EMS interface for out-of-band network management system.  Provides the RS485 environment monitoring interface.  Provides the alarm monitoring interface (ALM interface).  Provides signal input interfaces for 14 dry contacts. Interface description Table 4-44 The CIO card interfaces...
  • Page 88 4 Card Technical specification Table 4-46 The CIO card technical specification Item Specification Power consumption ≤2 W Working temperature to 45 ℃ ℃ Ambient temperature for storage to 60 ℃ ℃ Ambient humidity for storage 10% to 90% Version: A 4-43...

  • Page 89: Pwr Card

    AN5516-06 Optical Line Terminal Equipment Hardware Description 4.15 PWR Card Main function Performs the lightning protection and filtering function, and inducts -48V power. Interface description Table 4-47 The PWR card interfaces Symbol Meaning Description Inducts DC -48V power. The 0V interface corresponds to Power supply the high potential of the DV power supply;...

  • Page 90: Cable And Connector

    Cable and Connector This chapter introduces various cables and connectors used by the AN5516-06. It includes the following sections: Power cable Protection earth ground cable Alarm cable Fiber jumper Coaxial E1 cable Coaxial clock cable Network cable Serial-port cable Dry contact cable Version: A...

  • Page 91: Power Cable

    AN5516-06 Optical Line Terminal Equipment Hardware Description Power Cable 5.1.1 Cabinet Power Cable Purpose The cabinet power cable is used to induct two channels of -48V power that serve as hot standby to each other from the external, and provides dual-switched power (-48V / 96A / 6 branch power rails) for the PDP of the equipment.

  • Page 92: Figure 5-2 The Ground Cable

    5 Cable and Connector Figure 5-2 The ground cable The yellow-green power cable is used to connect external protection earth ground and the PE external power supply terminal on the PDP. Its appearance is shown in Figure 5-3. Figure 5-3 The protection earth ground cable Figure 5-4 illustrates the connector of the cabinet power cable connected with the PDP.

  • Page 93: Subrack Power Cable

    AN5516-06 Optical Line Terminal Equipment Hardware Description Specifications Item Specification Double-sheathed heat-resistant (withstanding Cable type temperature up to105 ) ℃ single-core soft cable Color Blue, black, yellow-green Maximum current Conductor cross-sectional area 16mm 5.1.2 Subrack Power Cable Purpose The subrack power cable of the AN5516-06 is used to connect the PDP and the subrack power supply card and provide both the active and standby power supplies for the subracks.
  • Page 94 5 Cable and Connector Specifications Item Specification Cable type Double-sheathed two-core soft cable Color Sheath: grey white; wires: blue, black Maximum current Conductor cross-sectional area 2×2.5mm Version: A...

  • Page 95: Protection Earth Ground Cable

    AN5516-06 Optical Line Terminal Equipment Hardware Description Protection Earth Ground Cable 5.2.1 Subrack Protection Earth Ground Cable Purpose The subrack protection earth ground cable is used to connect the subrack earth ground pole with the vertical mounting flange of the cabinet to achieve protection earth ground of the subrack.

  • Page 96: Cabinet Protection Earth Ground Cable

    5 Cable and Connector 5.2.2 Cabinet Protection Earth Ground Cable Purpose The cabinet protection earth ground cable is used to connect the protection earth ground of the PDP with the cabinet earth ground point. Its hardware number is 408000018R1A. The copper tube uninsulated terminal (which is connected to the PDP) of the cabinet protection earth ground cable has already been connected to the PE inside terminal of the PDP before delivery.

  • Page 97: Alarm Cable

    AN5516-06 Optical Line Terminal Equipment Hardware Description Alarm Cable 5.3.1 Alarm Cable for the Head of Row Cabinet Purpose The alarm cable for the head of row cabinet is used to connect the PDP and the head of row cabinet and output the equipment alarm signal from the cabinet to the head of row cabinet.

  • Page 98: Subrack Alarm Cable

    5 Cable and Connector 5.3.2 Subrack Alarm Cable Purpose The subrack alarm cable connects the CIO card of the subrack with the PDP, and outputs the subrack alarm to the PDP. Its hardware number is 3.695.095R4A. The subrack alarm cables have already been connected in the cabinet before delivery. Appearance view The subrack alarm cable is universal straight-through network cable, both ends of which are RJ-45 connectors, as shown in Figure 5-9.

  • Page 99: Fiber Jumper

    AN5516-06 Optical Line Terminal Equipment Hardware Description Fiber Jumper Purpose The fiber jumper is used to connect the optical interface of the card and the ODF. The purpose of the fiber jumper varies depending on the interface type as shown in Table 5-1.
  • Page 100 5 Cable and Connector Figure 5-10 The LC / PC optical fiber connector Figure 5-11 The SC / PC optical fiber connector The corresponding relationship between the AN5516-06 cards and the fiber jumper is shown in Table 5-2. Table 5-2 The corresponding relationship between the card and the fiber jumper Card Interface...

  • Page 101: Coaxial E1 Cable

    AN5516-06 Optical Line Terminal Equipment Hardware Description Coaxial E1 Cable Purpose A coaxial E1 cable carries eight E1 signals. Each CE1B card has four E1 interfaces, which supports the receiving and transmitting of 32 E1 signals. The coaxial E1 cable is mainly used to connect the E1 interfaces of the CE1B card and the MDF. The coaxial E1 cable includes 75Ω...

  • Page 102: Figure 5-13 The Db-44P Plug

    5 Cable and Connector Figure 5-13 The DB-44P Plug Table 5-3 Signal description associated with the E1 interface pin Coaxial Coaxial Cable Cable Cable Cable Signal Number Property Signal Number Property Number Number Conductor Conductor (core) (core) Shield Shield (ground) (ground) Conductor Conductor...
  • Page 103 AN5516-06 Optical Line Terminal Equipment Hardware Description Coaxial Coaxial Cable Cable Cable Cable Signal Number Property Signal Number Property Number Number Conductor Conductor (core) (core) Shield Shield (ground) (ground) Conductor Conductor (core) (core) Shield Shield (ground) (ground) Note 1: The copper foil inside the plastic casing is connected to the metal shell of the plug. Note 2: Ri indicates the i-th input, and Ti indicates the i-th output.

  • Page 104: Coaxial Clock Cable

    5 Cable and Connector Coaxial Clock Cable Purpose The coaxial clock cable is used to connect the equipment clock interface and the clock source or the clock in a lower layer. The hardware number of the 75Ω coaxial clock cable is 3.695.187R1A. Appearance view The end of coaxial clock cable connected with the AN5516-06 is a SAA type coaxial plug, and the end connected with the MDF is composed of bare wires, as...

  • Page 105: Network Cable

    AN5516-06 Optical Line Terminal Equipment Hardware Description Network Cable Purpose The network cable is used to connect devices such as the network management computer and environment monitoring device. Its hardware number is 3.695.095R4A. Appearance view Both ends of the network cable are the RJ-45 connectors. The network cable is illustrated in Figure 5-15.

  • Page 106: Figure 5-16 The Rj-45 Connector

    5 Cable and Connector Figure 5-16 The RJ-45 connector The wiring schemes of the straight-through network cable and the cross-over network cable are shown in Table 5-4 and Table 5-5. Table 5-4 The wiring scheme of the straight-through network cable Pin of the Local End (X1) Wire Color Pin of the Opposite End (X2)
  • Page 107 AN5516-06 Optical Line Terminal Equipment Hardware Description Specification Item Specification Cable type CAT-5 twisted pair Connector (X1/X2) type RJ-45 Number of cores Conductor diameter AWG 24 Breakdown voltage 2000V 5-18 Version: A...

  • Page 108: Serial Port Cable

    5 Cable and Connector Serial Port Cable Purpose The serial port cable is used to connect the CONSOLE port of the core switch card or the D port of every card with the serial port of local computer. It is used for the aforesaid connection only when equipment commissioning is performed.
  • Page 109 AN5516-06 Optical Line Terminal Equipment Hardware Description Terminal definition The connection relationship of the corresponding pins is shown in Table 5-6. Table 5-6 Definition of the serial port cable pins Connected Signal DE-9 Connector Pin RJ45 Connector Pin Specification Item Specification Cable type CAT-5 twisted pair...

  • Page 110: Dry Contact Cable

    5 Cable and Connector Dry Contact Cable Purpose The dry contact cable is used to connect the DC1 to DC14 interfaces of the AN5516-06 with the external dry contact devices that monitor infrared detection, smoke, electric supply, humidity, temperature, fan, vibration and access control. The hardware number of the dry contact cable is 3.695.452R1A.
  • Page 111 AN5516-06 Optical Line Terminal Equipment Hardware Description Table 5-7 The wiring scheme of the dry contact cable Terminal Illustration Pin Number Wire Color Opposite End Orange Grounding Dry contact device 1 level White-orange output end Dry contact device 2 level Green output end Dry contact device 3 level...
  • Page 112 Appendix A Abbreviation Access Control List CATV Cable Antenna Television Command Line Interface DHCP Dynamic Host Configuration Protocol EPON Ethernet Passive Optical Network Gigabit-capable Passive Optical Network GPON IGMP Internet Group Management Protocol Internet Protocol Local Area Network Media Gateway Controller MGCP Media Gateway Control Protocol Next Generation Network...
