- Page 1 4P590204-1 Packaged Air Conditioner Drain Pump Kit Installation manual BDU510B250VM...
- Page 2 70mm Drain pump kit Ceiling surface Drain pump kit The bottom surface of the drain pump kit will be lower than the bottom surface of the indoor unit Top View Side View Packaged Air Conditioner Drain Pump Kit - BDU510B250VM...
- Page 3 4. Insert heat insulating tube 1 (included) onto indoor unit drain socket. 5. Wrap the threaded end of the drain connecting pipe 1 (included) with thread seal tape. Then attach the drain connecting pipe 1 to the indoor unit drain socket. Packaged Air Conditioner Drain Pump Kit - BDU510B250VM...
- Page 4 14. Do not install the heat insulating material (fi eld supply) to the outlet of the drain pump kit at this point. It will be installed after the draining check in the trial operation procedure (Refer to 6. TRIAL OPERATION PROCEDURE). Drain pipe ( eld supply) Drain connection pipe 3 (included) Hose band (included) Indoor unit Drain pump kit Packaged Air Conditioner Drain Pump Kit - BDU510B250VM...
- Page 5 7. Connect the drain pump lead wire to the X25A terminal. 8. After completion of the wiring, be sure to organize the wires neatly, bind together and clamp the wires. 9. Install back the indoor unit control box cover. Packaged Air Conditioner Drain Pump Kit - BDU510B250VM...
- Page 6 3. To check the drain condition of the drain pump kit, pour approximately 3 litres of water from the service panel opening into drain pan (Refer to fi gure below). 4. Ensure that the water fl ows out smoothly without leakage. Packaged Air Conditioner Drain Pump Kit - BDU510B250VM...
- Page 7 Note: Be sure that there is no gap between the drain connecting pipe 3 (included) and the drain pump kit. 2. Insulate the drain connecting pipe 3 (included) with insulation tube (fi eld supply) to prevent dew condensation. Packaged Air Conditioner Drain Pump Kit - BDU510B250VM...
- Page 8 3. Remove dust and water in the areas around the inspection port. 4. After fi nish cleaning, install back the inspection port cover, rubber plug and insulation plug. Screws (4pcs.) Inspection port cover Drain pump kit Insulation plug Rubber plug Packaged Air Conditioner Drain Pump Kit - BDU510B250VM...
- Page 12 4P590204-1 2019.07...
