Wire rope winch >LAMBDA< BGV C1 for stages and studios
English
The Winch
Do not exceed the capacity of name plate.
Before taking into operation, a competent person must check:
the lifting device
the load bearing parts of the structure
the carrying medium
mounting
Load attachment device:
check it has sufficient carrying capacity
load hooks must have safety catches
load hooks must be secured to the rope with a solid eye and high
pressure rope clamp and tested acc. to the regulations
fix the load correctly
do not use the winch rope as a hitching device
The winch should be given a thorough examination by a competent person at least once a year.
The entire installation has to be examined by a competent person before taking into operation, when
necessary, after considerable changes and every 4 years.
Always ensure the maintenance intervals are adhered to.
Only use original accessories and spare parts; otherwise safe function is not guaranteed.

Technical Data

Type
FEM Group acc. to DIN15020
Capacity
rec. wire rope
rope ø
minimum braking force
max. rope reception 1 rope
max. rope reception 2 ropes
rope reception for shunting winch
max. number of layers
required crank force
crank force – without load
lift per full turn of crank
ratio
Brake / securing the load
weight
suitable for ambient temperature
Functional Description
The wire rope winch for stages and studios is a drum type winch. A single reduction pair of straight cut internal
spur gear drives the winch.
A double safety spring locking device automatically holds the load.
For better rope coiling, the winch is equipped with a spring loaded wire rope pressure drum.
The gear is designed for double nominal load according to BGV C1!
Mounting Instructions
Mounting:
ATTENTION:
the mounting structure must be designed to sustain the max. forces imposed by the winch, (pay attentions to
regulations for stages and studios)
pay careful attention that the mounting surface is flat and true
only fix the winch by means of good quality screws,
tighten the screws evenly
secure the screws
ensure that the crank is free running (crank clearance)
technische Änderungen vorbehalten
030272015
daN
[mm]
[kN]
m
daN
daN
mm
8,83:1
Double safety spring brake with 2 built-in, independent of
kg
design changes under reserve
Daily examinations:
brake functions
condition of the rope and
loading device
load bearing parts of the structure.
the load carrying medium
030272017
2 m 2 m
300 300
DIN EN 12385-4, 15x7K-WSC-1960-B-sZ
ø6 ø6
33,1
1x10 1x14,8
- 2x6,1
7,5 13,0
1 1
18 18
ca. 4 ca. 4
50 50
8,83:1
each other operating, brake spring system
~ 30 ~ 36
- 20°C ÷ + 40°C
changements techniques sous réserve
04.04.014
030272018 030272019
2 m 2 m
300 300
ø6 ø6
1x19,8 1x24,3
2x8,75 2x10,9
18,0 23,0
1 1
18 18
ca. 4 ca. 4
50 50
8,83:1 8,83:1
~ 42 ~ 47
