QPC QMicro Customer Assembly Instructions

Receptacle connector flange mount and jam nut
Hide thumbs Also See for QMicro:
Table of Contents

Advertisement

Quick Links

Download this manual
QMicro Receptacle Connector
Flange Mount and Jam Nut
Customer Assembly Instructions
THE INFORMATION CONTAINED IN THIS DOCUMENT IS THE SOLE PROPERTY
OF QPC FIBER OPTIC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF QPC FIBER OPTIC IS PROHIBITED.
Document:
CAI-QMICR-01
Release Date:
03/13/2014
QPC Fiber Optic, LLC
27612 El Lazo Road, Laguna Niguel, CA 92677
CAI-QMICR-01: QMicro Receptacle Connector Customer Assembly Instructions
DOCUMENT:
REVISION:
REVISION DATE:
QPC CONFIDENTIAL
Revision:
Revision Date:
www.qpcfiber.com
Ph: (949) 361-8855
Page 1 of 13
CAI-QMICR-01
6
9/23/2019
6
09/23/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QMicro and is the answer not in the manual?

Questions and answers

Related Manuals for QPC QMicro

Summary of Contents for QPC QMicro

  • Page 1 REVISION DATE: 9/23/2019 QPC CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DOCUMENT IS THE SOLE PROPERTY OF QPC FIBER OPTIC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF QPC FIBER OPTIC IS PROHIBITED. Document: CAI-QMICR-01 Revision:...

  • Page 2: Connector Configurations

    CAI-QMICR-01: QMicro Receptacle Connector Customer Assembly Instructions SCOPE This document will describe the Assembly Instructions for the QPC QMicro Receptacle Connector for the Flange Mount and Jam Nut for all cable options. COMPONENTS TERMINI TERMINI & RETAINER PLATE & INSERT...

  • Page 3: Tool List

    CAI-QMICR-01: QMicro Receptacle Connector Customer Assembly Instructions TOOL LIST TK-060 QPC Cable and Connector Prep Tool Kit – (Equivalent tools may be used) PT-062 Miller Kevlar Scissors (Carbon Molybdenum & Vanadium Steel Blade) PT-500 Precise-Control .050” Screwdriver (1.27mm) Hex PT-501 Precise-Control Screwdriver, 1/16"...
  • Page 4 CAI-QMICR-01: QMicro Receptacle Connector Customer Assembly Instructions BACK NUT ONLY ASSEMBLIES (900µm Cable Option) CABLE PREPARATION Slide the components onto the cable in this order. (See image on right): 1. Back Nut 2. Spacer 3. Wave Spring TERMINATE Strip approximately 1-inch (25mm) of buffer off the fiber. Be sure to include a spring on each of the fibers.

  • Page 5: Final Assembly

    CAI-QMICR-01: QMicro Receptacle Connector Customer Assembly Instructions FINAL ASSEMBLY Use the Hex Driver PT-503 to align the key and install the insert into the Jam Nut or Flange Adapter Body. Rotate the body clockwise until the insert locates internal key. Push the insert forward. The Insert should protrude from the front face of the body to indicate it is seated properly.

  • Page 6: Cable Preparation

    CAI-QMICR-01: QMicro Receptacle Connector Customer Assembly Instructions LOW PROFILE BACKSHELL ASSEMBLIES (4x2mm Cable Option OR 4.5mm – 7.5mm Cable Option) CABLE PREPARATION Slide the components onto the cable in this order (See image on right): 1. Back Nut 2. Strain Relief 3.
  • Page 7 CAI-QMICR-01: QMicro Receptacle Connector Customer Assembly Instructions TERMINATE Use the Stripping Length Diagram seen below to Terminate and Polish the Fiber Optic Termini. Be sure to include a spring on each of the fibers. For Termination and Polishing details, reference CAI-TERM- CRIMP TO CABLE Remove tape after polishing the Fiber Optic Termini.
  • Page 8 CAI-QMICR-01: QMicro Receptacle Connector Customer Assembly Instructions POPULATE THE INSERT Insert the Fiber Optic Termini into the back of the Insert Cavities. Place the Termini Retainer Plate between the 900 µm fibers making sure that the springs are between the Fiber Optic Termini and Termini Retainer Plate.
  • Page 9 CAI-QMICR-01: QMicro Receptacle Connector Customer Assembly Instructions NOTE: Orientation of the connectors is seen below Slide the Wave Spring and Strain Relief into place. Hand tighten the Strain Relief. Check the fiber through the holes in the Strain Relief to make sure they are not twisted or kinked. Place assembly in the 4"...
  • Page 10 CAI-QMICR-01: QMicro Receptacle Connector Customer Assembly Instructions BACKSHELL (4.5mm – 7.5mm Cable Option) CABLE PREPARATION Slide the components onto the cable in the following order (See image on right): 1. Bend Limiter 2. Backshell 3. Cable Seal 4. Washer 5. Strain Relief 6.
  • Page 11 CAI-QMICR-01: QMicro Receptacle Connector Customer Assembly Instructions TERMINATE Use the Stripping Length Diagram seen below to Terminate and Polish the Fiber Optic Termini. Be sure to include a spring on each of the fibers. For Termination and Polishing details, reference CAI-TERM- CRIMP TO CABLE Remove tape after polishing the Fiber Optic Termini.
  • Page 12 CAI-QMICR-01: QMicro Receptacle Connector Customer Assembly Instructions POPULATE THE INSERT Insert the Fiber Optic Termini into the back of the Insert Cavities. Place the Termini Retainer Plate between the 900 µm fibers making sure that the springs are between the Fiber Optic Termini and Termini Retainer Plate.
  • Page 13 CAI-QMICR-01: QMicro Receptacle Connector Customer Assembly Instructions Slide the Wave Spring and Strain Relief into place. Hand tighten the Strain Relief. Check the fiber through the holes in the Strain Relief to make sure they are not twisted or kinked.
  • Page 14 DOC. NUMBER REV. PROPRIETARY AND CONFIDENTIAL D50058 THE INFORMATION CONTAINED IN THIS DRAWING IS CONFIDENTIAL AND THE SOLE PROPERTY OF QPC FIBER CHECKED OPTIC. ANY REPORDUCTION IN PART DRAWN OR AS A WHOLE OR DISCLOSURE OF DIMENSIONS ARE IN INCH [MM].
