Seek Thermal Seek Scan User Manual

Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Patents pending on Seek Scan System and Fixed Heat Source
SEEK SCAN DOES NOT DIAGNOSE COVID-19 OR OTHER DISEASE, ILLNESS OR DISORDERS.
THE SYSTEM MEASURES SKIN TEMPERATURE AS A PROXY FOR BODY TEMPERATURE.

TABLE OF CONTENTS

What's In The Box.............................................................................................................................
System Setup......................................................................................................................................
Software Overview............................................................................................................................
Settings & About Menu...................................................................................................................
Tips For Optimal Performance.....................................................................................................
Skin vs. Body Temperature ...........................................................................................................
Regulatory and Compliance..........................................................................................................
USER MANUAL
THERMAL
VISIBLE
CAMERA
CAMERA
8 cm
HEAT SOURCE
CAMERA
1.
FIXED HEAT SOURCE
Temperature-Controlled
Reference Device
9 cm
2
3
4
5
6
7
8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Seek Scan and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seek Thermal Seek Scan

Summary of Contents for Seek Thermal Seek Scan

  • Page 1: Table Of Contents

    8 cm 9 cm Patents pending on Seek Scan System and Fixed Heat Source SEEK SCAN DOES NOT DIAGNOSE COVID-19 OR OTHER DISEASE, ILLNESS OR DISORDERS. THE SYSTEM MEASURES SKIN TEMPERATURE AS A PROXY FOR BODY TEMPERATURE. TABLE OF CONTENTS What’s In The Box..........................

  • Page 2: What's In The Box

    WHAT’S IN THE BOX Quick Start Guide Warranty Camera Fixed Heat Source Removable for international power plugs Camera USB Stick with Fixed Heat Source USB-A Cable Seek Scan Software Power Cable...

  • Page 3: System Setup

    SYSTEM SETUP Connect USB stick to PC or tablet and follow Place two pieces of tape 5 feet (1.5 m) apart. instructions to install Seek Scan software. Distance is critical to system performance. Set tripod heights to 5 feet (1.5 m).

  • Page 4: Software Overview

    SOFTWARE OVERVIEW means the heat source is not detected. This shows the heat source is detected but means the subject is not detected. a subject is not detected. Set a custom alarm by clicking up & down Blue box means the camera has detected a arrows.

  • Page 5: Settings & About Menu

    SETTTINGS MENU 1. Change between Celsius and Fahrenheit. 2. Turn the temperature display on or off. 3. Seek Scan measures skin temperature as a proxy to estimate body temperature. Check this box to also show the skin temperature measurement. 4. Enabling this feature sends anonymous system data to Seek Thermal to help improve Seek Scan software.

  • Page 6: Tips For Optimal Performance

    Heat Source and the face of the subject. 3. Measure and confirm the distance from the Heat Source to the Camera is no further than 5 feet (1.5 meters). Seek Scan has been qualified to work at 5 feet (1.5 meters) to accommodate people of different heights.

  • Page 7: Skin Vs. Body Temperature

    Seek Scan uses skin temperature to provide an estimated body temperature. 2. Seek Scan is programed to measure the most reliable parts of the face to produce the best results with high accuracy. 3. A person’s skin temperature may vary based on a variety of circumstances such as ambient temperature, sweat and eyewear.

  • Page 8: Regulatory And Compliance

    510(k) clearance during the health emergency, provided the thermal imaging system meets the standards set forth in the guidance. Seek Scan meets all of these applicable standards. Seek Scan should not be solely or primarily relied upon to diagnose or exclude a diagnosis of COVID-19, or any other disease. While this device can be used by anyone...

Table of Contents
