IBM ThinkPad X40 Series Setup Poster

X40 series Setup Poster
P/N 27R0597
10/07/2004
ThinkPad
Setup Instructions
These instructions are only for first time setup. For more detailed information, press the
Access IBM button.
Unpack:
®
ThinkPad computer Battery pack
or
2 TrackPoint caps ®
Modem cord
* See reverse for notes about unlisted,
missing, or damaged items and recovery CD.
Note: Please read the safety notices in the
Service and Troubleshooting Guide before you
use the computer.
Install battery pack:
Your battery is ready to use.
Note: Some models have a
battery that is shaped differently.
Connect to power:
3 2
Turn on the power:
Point and click with IBM TrackPoint Navigation System:
TM
Press the IBM TrackPoint cap in the direction you want to move the pointer. The left and right
buttons below the space bar function like mouse buttons.
Configure the Operating System following on-screen instructions:
This process takes several minutes, and your computer may restart multiple times.
For more detailed information, press the Access IBM button:
UltraConnect
Wireless Antenna
Optimal placement provides
superior range and performance
Power cord AC adapter
W elcome
Books
- Setup Instructions (this sheet)
- Service and Troubleshooting Guide
- Other supplements or flyers
1
2
1
1
Fn Key
Use in combination with keys
with blue icons to access
special ThinkPad features
Size : 11x13 inches
Color : 2 color job = Black and Red (PMS 032cvc)
Font : IB M Fonts and Helvetica Neue Fam
Material : 100 gsm gloss art paper (Use 100% recycled paper in only Japan)
Blue line show s die-cut. DO NOT PRINT
Please chang e the barcode No. and printi
One - Handed Latch
TM
TrackPoint Center Button
Scroll documents or magnify an
area of the screen
ily
.
ng country name.
®
ThinkLight
Keyboard Light
Illuminates your
keyboard, so you can
work in the dark
Volume and Mute
Buttons
Wireless Radio
Control
Presentation
Director
Easily give presentations
or use multiple monitors
EasyEject
Use to undock and
remove attachable
devices
Powered USB
Connector
Use USB optical drives
without a separate power
adapter.
Internet Navigation
Keys
Web browser back and
forward
Full Screen Magnifier
Zooms the entire screen
P/N: 27R0597
