- Page 1 Replacing the adapter plate / Rear centering TP Instruction Sheet 2022-D063062 Revision: 01...
- Page 2 +41 81 300 10 30 info@wittenstein.tw +886 3 287 0191 WITTENSTEIN Güç Aktarma Türkiye info@wittenstein.com.tr +90 216 709 21 23 Sistemleri Tic. Ltd. Şti. © WITTENSTEIN alpha GmbH 2019 Subject to technical and content changes without notice. 2022-D063062 Revision: 01...
-
Page 3: Table Of Contents
Instruction Sheet Table of Contents About this manual ....................2 Safety........................2 2.1 Personnel ......................2 Disassembly / replacement .................2 3.1 Disassembling the adapter plate................2 Assembly ......................3 4.1 Preparations......................3 4.2 Attaching gearboxes with rear centering to a machine ........4 4.2.1 Mounting with through-holes ................4 4.2.2 Mounting with slotted holes ................4 4.3 Mounting the adapter plate ..................5 Appendix .......................6... -
Page 4: About This Manual
About this manual Instruction Sheet About this manual These instructions describe the replacement of the adapter plate on the gearbox as well as the motor-side installation of a gearbox with rear centering [M] on a machine. It is an amendment to the standard operating manual. -
Page 5: Assembly
Operation without an adapter plate might lead to damage. Only install your own adapter plate or replace an adapter plate according to the specifications of WITTENSTEIN alpha GmbH. Operation without an adapter plate is prohibited. In rare cases, a grease lubricated gearbox may show a small leak at the input (sweating). -
Page 6: Attaching Gearboxes With Rear Centering To A Machine
Assembly Instruction Sheet Attaching gearboxes with rear centering to a machine This section is only valid for TP gearboxes with rear centering. Center the gearbox in the machine bed. ® Apply threadlocker (e.g. Loctite 243) to the fastening screws. ... -
Page 7: Mounting The Adapter Plate
When attaching a new adapter plate, only use new screws (DIN EN ISO 4762) and clamping washers (DIN 6796). Only use adapter plates approved by WITTENSTEIN alpha GmbH. Notes on the disposal of components no longer in use can be found in chapter 5.5 "Disposal". -
Page 8: Appendix
23456789 Serial number 1234567 DMF: 10/18 Lubrication: xxx Made in Germany WITTENSTEIN alpha GmbH-Walter-Wittenstein-Str.1-97999 Igersheim Lubricant Production date Data matrix code (optional) Tbl-1: Identification plate (sample values) Ordering code xxxxxxx x - x x x - xxxxx - x x x - x x xxxxx... -
Page 9: Dp + / Hg + / Rp + / Sp + / Tp + / Xp
Instruction Sheet Appendix 5.3.1 DP / HG / RP / SP / TP / XP Fastening screws (DIN EN ISO 4762) for adapter plate**, Property class 12.9, Screw size x Length [ ]x[mm] Gearbox Number Code letter (.)* size of stages G / H I / K M3x25... -
Page 10: Np / Npl / Npr / Nps / Npt
Appendix Instruction Sheet 5.3.2 NP / NPL / NPR / NPS / NPT Fastening screws (DIN EN ISO 4762) for adapter plate**, Property class 10.9, Screw size x Length [ ]x[mm] Gearbox Number Code letter (.)* size of stages G / H I / K NPx005 M3x20... -
Page 11: Tightening Torques For Common Thread Sizes In General Mechanical Engineering
For further information, please visit our website at www.wittenstein-alpha.de. Or contact our Customer Service department at service@wittenstein-alpha.de WITTENSTEIN alpha GmbH Customer Service department Walter-Wittenstein-Straße 1 D-97999 Igersheim, Germany Tel.: +49 7931 493-12900 © WITTENSTEIN alpha GmbH 2019 Revision: 01 2022-D063062 en-9... - Page 12 Instruction Sheet Revision history Revision Date Comment Chapter 16.10.19 New version draft Revision: 01 2022-D063062...
- Page 13 WITTENSTEIN alpha GmbH · Walter-Wittenstein-Straße 1 · 97999 Igersheim · Germany Tel. +49 7931 493-12900 · info@wittenstein.de WITTENSTEIN ‒ with the future www.wittenstein-alpha.de AC: XXXXXXXX 2022-D063062 Revision: 01...
