- Page 1 720-16 FEED MIXER OPERATION & PARTS MANUAL ROTO-MIX LLC P.O. BOX 1724 2205 E. Wyatt Earp Blvd. Dodge City, Kansas 67801 (620) 225-1142 ©ROTO-MIX 2006 SERIAL NUMBER_________________ 05/2020 441911 Printed in U.S.A.
-
Page 2: Table Of Contents
CHAIN TENSIONING & LOADING INSTRUCTIONS ..........21-23 LUBRICATION ......................24 SPECIFICATIONS ......................25 PTO CHART ......................... 26 720-16 TRUCK DIMENSIONS ..................27 720-16 TANDEM TRAILER DIMENSIONS ..............28 720-16 STATIONARY DIMENSIONS ................29 MOUNTING DIMENSIONS....................30 REPAIR PARTS TABLE OF CONTENTS..............33... -
Page 3: Warranty
ROTO-MIX and that it be returned to ROTO-MIX within 10 days of purchase and be re- corded in ROTO-MIX’s owner file for this warranty to be valid. In the event an owner’s card is not on file at the ROTO-MIX office, the warranty period will extend only from date equipment was picked up or shipped from the ROTO-MIX plant. -
Page 4: Scales Warranty & Service Policy
- ROTO-MIX is not responsible and will not be liable for damage caused to persons or property, commercial loss, loss of time or production, loss of use by reason of the installation or use of ROTO-MIX products or their mechanical failure. -
Page 5: Operator Qualifications
OPERATOR QUALIFICATIONS Operation Of this mixer/feeder shall be limited to competent and experienced persons. In addition, anyone who will operate or work around a mixer/feeder must use good common sense. In order to be qualified, he or she must also know and meet all other qualifications, such as: 1. -
Page 6: Safety Information
It may also be used to alert against unsafe practices. If you have questions not answered in this manual or require additional copies or the manual is damaged, please contact your dealer or ROTO-MIX, 2205 E. Wyatt Earp, Dodge City, Kansas, 67801. (Telephone) 620-225-1142 (Fax) 620-225-6370... - Page 7 SAFETY FIRST REMEMBER: The careful operator is the best operator. Most accidents are caused by human error. Certain precautions must be observed to prevent the possibility of injury or death. ALLOW PERSONNEL OTHER THAN QUALIFIED OPERATOR NEAR THE MACHINE. NEVER START MACHINE UNTIL ALL GUARDS AND SAFETY SHIELDS ARE IN PLACE.
- Page 8 SAFETY READ BEFORE YOU FEED EQUIPMENT SAFETY GUIDELINES Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers and manufactures build in as many safety features as possible. However, every year many accidents occur which could have been avoided by a few seconds of thought and a more careful approach to handling equipment.
- Page 9 SAFETY READ BEFORE YOU FEED KEEP ALL SHIELDS IN PLACE Do not operate mixer/feeder without safety shields in place. Rotating parts can crush or dismember causing personal injury or death. Disconnect PTO driveline before removing shields for adjustment or service. OPERATE MIXER/FEEDER SAFELY Rotating parts can entangle or strike people, resulting in personal injury or death.
- Page 10 SAFETY READ BEFORE YOU FEED STAY CLEAR OF ROTATING DRIVELINES Entanglement in rotating driveline can cause serious injury or death. Keep tractor master shield and driveline shields in place at all times. Make sure rotating shields turn freely. Wear close fitting clothing. Stop the engine and be sure PTO driveline is stopped before making adjustments, connections, or cleaning out PTO driven equipment .
- Page 11 SAFETY READ BEFORE YOU FEED PREPARING TRACTOR FOR TRAILER MIXER POSITIONING DRAWBAR IMPORTANT: Drive components can be damaged from excessive speed. Under no circumstances should a feed mixer equipped with 540 RPM be operated by a tractor with 1000 RPM PTO. Feed mixers are available with either 540 or 1000 RPM driveline.
- Page 12 SAFETY SIGNS...
- Page 13 SAFETY SIGNS...
- Page 14 SAFETY SIGNS...
- Page 15 Replace safety decals and signs that are missing or have become illegible. Replaced parts that displayed a safety sign should also display the current sign. Safety decals or signs are available from your dealer or the ROTO-MIX manufacturing plant. How to Install Safety Decals: Be sure that the installation area is clean and dry.
- Page 16 Your best assurance against accidents is a careful and responsible operator. If there is any portion of this manual or function you do not understand, contact your dealer or the ROTO-MIX plant. BEFORE OPERATION: Carefully study and understand this manual.
- Page 17 SAFETY READ BEFORE YOU FEED DURING OPERATION: Beware of bystanders, particularly children! Always look around to make sure that it is safe to start the engine of the towing vehicle or move the unit. This is particularly important with higher noise levels and quiet cabs, as you may not hear people shouting.
- Page 18 SAFETY READ BEFORE YOU FEED DURING OPERATION (CONT.) Never leave running mixer/feeder unattended. As a precaution, always recheck the hardware on mixer/feeder following every 100 hours of operation. Correct all problems. Follow the maintenance safety procedures. FOLLOWING OPERATION: Following operation, or when unhitching, stop the tractor or towing vehicle, set the brakes, disengage the PTO and all power drives, shut off the engine and remove the ignition keys.
- Page 19 SAFETY READ BEFORE YOU FEED HIGHWAY AND TRANSPORT OPERATIONS (CONT.): Comply with state and local laws governing highway safety and movement of farm machinery on public roads. Use approved accessory lighting flags and necessary warning devices to protect operators of other vehicles on the highway during daylight and nighttime transport.
- Page 20 If equipment has been altered in any way from original design, ROTO-MIX does not accept any liability for injury or warranty. A fire extinguisher and first aid kit should be kept readily accessible while...
-
Page 21: Chain Tensioning & Loading Instructions
READ THE FOLLOWING BEFORE WELDING ON THIS MIXER/FEEDER When welding on your mixer/feeder, do not allow the current to flow through the ball bearings or the roller chains. Ground directly to the item being welded. Always disconnect the scale instrumentation from the weigh bars or load cells and the power source. - Page 22 ALWAYS USE DRY HAY Drain rain water out of mixer before use. 1” of rain in a 720-16 equals (83 1/2 gal) 696 lbs. of water which will increase the moisture in 1000 lbs. of dry hay (12%) to 48% moisture or 500 lbs.
- Page 23 LOADING INSTRUCTIONS FOR HAY PROCESSOR Load all commodities except liquids on the discharge (auger) side with the hay pan in the raised position. The raised hay pan does not affect the mixing action 1. If molasses and/or liquid protein is used, load on the rotor side of the mixer first with the mixer not running.
-
Page 24: Lubrication
LUBRICATION DISENGAGE PTO & SHUT OFF POWER BEFORE LUBRICATING THE MACHINE. LOOSE OR FLOPPY CLOTHING SHOULD NOT BE WORN BY THE OPERATOR. OIL BATH: Fill the oil bath with 30 weight motor oil to sight plug level. GREASE BANK: Grease every 10 hours. FRONT END BEARINGS: Grease every 10 hours. -
Page 25: Specifications
720-16 SPECIFICATIONS Capacity (Cu. ft.) .......... 720 Struck level capacity (Cu. ft.) ....... 750 Top Auger Bearing (Front) ......2-7/16” 4-Bolt Top Auger Bearing (Rear) ......4” 4-Bolt Bottom Auger Bearing (Front) ...... 2-7/16” 4-Bolt Bottom Auger Bearing (Rear) ...... 4” 4-Bolt Rotor Bearing (Front) ........ -
Page 26: Pto Chart
PTO CHART 720-16 INPUT JACKSHAFT (% ENGINE SPEED) SPROCKET SPROCKET DIESEL 80-85 AUTOMATIC 250 ft-lb/min 2:1 Gearbox 17 Tooth 14 Tooth TRANS Engine rotation 48 Tooth (For other engine or transmission applications, consult factory) 1000 TRACTOR 15 Tooth 12 Tooth... -
Page 27: 720-16 Truck Dimensions
115" (SPOUT UP) 110" 108" HEIGHT DIMENSIONS ARE BASED ON 38" TRUCK FRAME WITH 24" 57 3/4" SPOUT 23 3/4" APPROXIMATE WEIGHT 720-16 ON TRUCK ....18,020 LB. WITH HAY PROCESSOR ..18,845 LB. SPOUT RUBBER 122" 38" 38 1/4" TRUCK FRAME 8 1/2"... -
Page 28: 720-16 Tandem Trailer Dimensions
720-16 TRAILER DIMENSIONS DIMENSIONS BASED ON 24” SPOUT AND 15 x 22.5 TIRES STANDARD APPROXIMATE WIEGHT: 700-16 ON TRAILER - 17,360 LB W/HAY PROCESSOR - 18,185 LB All Dimensions & Specifications are Approximate and Subject to Change Without Notice... -
Page 29: 720-16 Stationary Dimensions
720-16 STATIONARY DIMENSIONS 108" APPROXIMATE WEIGHT, LESS MOTOR 57 1/2" 700-16 STATIONARY ....16,700 LB. WITH HAY PROCESSOR ..17,525 LB. 21" 2" 65 1/2" 79 3/4" 90 1/2" 25" 10 3/4" 62 1/4" 32 1/4" 15 1/4" 219 1/4"... -
Page 30: Mounting Dimensions
720-16 TRUCK MOUNTING DIMENSIONS 720-16 TRAILER MOUNTING DIMENSIONS AUGER SIDE OF PEDESTAL PEDESTAL IS FLUSH WITH SIDE FRAME. All Dimensions & Specifications are Approximate and Subject to Change Without Notice... - Page 31 This Page intentionally left blank.
- Page 32 How to read a Roto-Mix Serial Number 4 1 01 5 0157 Manufactured Location Year Manufactured Month Manufactured Consecutive Numbering...
-
Page 33: Repair Parts Table Of Contents
REPAIR PARTS TABLE OF CONTENTS DESCRIPTION PAGE NO. WIRING SCHEMATIC ..................... 34 JOYSTICK ASSEMBLY ....................35 CONTROL PANEL ASSEMBLY ..................36 HYDRAULIC VALVE ...................... 37 HYDRAULIC PUMP (TRUCK) ..................38 OIL RESERVOIR ......................39 HYDRAULIC SCHEMATIC (STRAIGHT DOOR) ............40 STATIONARY HYDRAULIC ASSEMBLY .............. -
Page 34: Wiring Schematic
WIRING SCHEMATIC FOR STRAIGHT DOOR GREEN BROWN BROWN YELLOW YELLOW GREEN REF # PART # DESCRIPTION QTY. 780080 PUSH BUTTON SWITCH PANEL ASSEMBLY 780081 JOYSTICK PANEL ASSEMBLY 781055 TRUCK TO MIXER WIRE ASSEMBLY 780123 HYDRAULIC CONTROM VALVE... -
Page 35: Joystick Assembly
JOYSTICK ASSEMBLY TOP SIDE BOTTOM SIDE TO 12 VOLT GREEN YELLOW BROWN BROWN YELLOW REF # PART # DESCRIPTION QTY. 781056 SWITCH WIRE ASSEMBLY 185575 JOYSTICK BRACKET 357705 JOYSTICK SWITCH... -
Page 36: Control Panel Assembly
720-16 CONTROL PANEL ASSEMBLY ITEM # PART # DESCRIPTION QTY. 190928 TRUCK SWITCH PANEL 357705 JOYSTICK, (4-WAY) SCHNEIDER 9001K35 357753 RED LIGHT INDICATOR 3/4" DIA. 440835 DECAL, 4-WAY JOYSTICK (HORIZONTAL) 452744 SWITCH, ROCKER ON-OFF, (SPST), 44301... -
Page 37: Hydraulic Valve
HYDRAULIC VALVE ITEM # PART # DESCRIPTION QTY. 362209 HYD VALVE 12V DOUBLE, BUCHER 368024 HYD SWIVEL 9/16"MOR x 3/8"FPS 45º 368115 STRAIGHT ADAPTER 9/16 MOR x 3/8 FPS 453146 DIN CONNECTOR 781057 12 VOLT SOLENOID VALVE GROUND WIRE... -
Page 38: Hydraulic Pump (Truck)
HYDRAULIC PUMP REF. # PART # DESCRIPTION QTY. 336008 SH BUSHING 1/2” BORE 324040 1B x 4.0” SH BELT SHEAVE 182766 HYDRAULIC PUMP BRACKET 362017 HYDRAULIC PUMP 368050 3/4” FP x 7/8” MOR 90o SWIVEL 368512 3/4” MP x 3/4” HOSE BARB 368040 3/8”... -
Page 39: Oil Reservoir
OIL RESERVOIR REF. # PART # DESCRIPTION QTY. 362550 FILLER CAP 870477 OIL RESERVOIR WELDMENT 362400 FILTER ASSEMBLY 362504 SUCTION SCREEN 368512 3/4” HOSE BARB 310815 3/4” TO 3/8” REDUCER BUSHING 781059 3/8” x 20” HYD. HOSE ASSY. (3/8” MP ENDS) -
Page 40: Hydraulic Schematic (Straight Door)
HYDRAULIC SCHEMATIC NOTE (C) NOTE (A) NOTE (B) NOTE (D) NOTE A: CONNECT TO SPOUT CYLINDER BASE NOTE B: CONNECT TO SPOUT CYLINDER ROD END NOTE C: CONNECT TO DOOR CYLINDER BASE NOTE D: CONNECT TO DOOR CYLINDER ROD END REF. -
Page 41: Stationary Hydraulic Assembly
STATIONARY HYDRAULIC ASSEMBLY REF. # PART # DESCRIPTION QTY. 781004 HYDRAULIC VALVE ASSEMBLY 357700 PENDANT SWITCH 781134 STATIONARY HYDRAULIC PUMP ASSEMBLY 781005 OIL RESERVOIR ASSEMBLY 410852 EYEBOLT, 3/8” x 8” 185448 CHAIN, 2/0 x 18” 410008 PULL SPRING, 1-1/4” x 5-1/4” 872136 PUMP LEVER ARM WELDMENT 412416... -
Page 42: Spout Assembly 14" & 24
SPOUT ASSEMBLY 10 11 TO CYLINDER ITEM # PART # DESCRIPTION QTY. 182238 SPOUT SHAFT 183145 SPOUT RUBBER 16" x 64" 183152 SPOUT BACKUP ANGLE, 47" 183160 SPOUT RUBBER SIDE BAR x 8" 185896 SPOUT CYLINDER BAR - 9-1/2 189079 SPOUT MAGNET GUARD, 24"... -
Page 43: Straight Door Assembly
STRAIGHT DOOR ASSEMBLY REF. # PART # DESCRIPTION QTY. 872328 STRAIGHT DOOR PLATE WELDMENT 872248 STRAIGHT DOOR ARM WELDMENT 872247 STRAIGHT DOOR LEVER ARM WELDMENT 402518 FLAT WASHER 1 1/8” SAE 364055 HYDRAULIC CYLINDER 2” x 8” 184267 DOOR CYLINDER MARKER CLAMP (2 PIECE) 368007 HYD. -
Page 44: Fenders & Mud Flaps
720-16 FENDERS & MUD FLAPS REF # PART # DESCRIPTION 183087 MUD FLAP STRAP 354391 POLY FENDER 354392 POLY FENDER TUBING MOUNT KIT (2 per kit) 354393 POLY FENDER TAPER BRACKET KIT (4 per kit) 370200 ROTO-MIX MUD FLAP 24" x 30"... -
Page 45: Top & Bottom Auger Assemblies
720-16 TOP AUGERS ITEM # PART # DESCRIPTION QTY. 872367 620/700 TOP AUGER WA 3/8" FLGT 185708 24" TOP AUGER PADDLE - 6" x 9 5/8" 382424 FLIGHT 24"OD x 6 5/8"ID x 3/8" RH 2/3 PITCH 872736 620/720 HVY TOP AUGER W.A. -1/2" FLGT 185708 24"... -
Page 46: Ladder Assembly
720-16 BOTTOM AUGERS ITEM # PART # DESCRIPTION QTY. 872730 720 BTM AUGER WA - 3/4" 189269 24" AUGER KICKER 4-7/16" x 9-7/16" 382427 24" OD x 8 5/8" ID x 1/2" LH FULL PITCH 382454 24" OD x 8-5/8" ID x 3/4" RH FULL PITCH 382455 24"... -
Page 47: Staggered Rotor Assembly
720-16 STAGGERED ROTOR ASSEMBLY ITEM # PART # DESCRIPTION QTY. 190339P PLASTIC WIPER 190770 WIPER CHANNEL 5/8 BOLTS 401106 HEX NUT, 3/8"-16 NYLOCK #5 400910 HEX CROWN LOCNUT 5/8"-11 #9 PLTD 402806 FLAT WASHER 3/8" #9 BOWMALLOY 406906 HHCS 3/8"-16 x 1-1/4" #9 BOWMALLOY 407130 CHCS 5/8"-11 x 2"... -
Page 48: 6-Bar Rotor Assembly
720-16 6-BAR ROTOR ASSEMBLY REF. # PART # DESCRIPTION QTY. 872414 720-16 6-ARM ROTOR WELDMENT 872361 ROTOR SQUARE WIPER WELDMENT 850007 ROTOR SPRIMG COVER WELDMENT 189141 END WIPER STRAP 27-1/4” 189142 CENTER WIPER STRAP 60” 189143 END PLASTIC WIPER 62-1/2”... -
Page 49: 5-Bar Rotor Assembly
720-16 5-ARM ROTOR ASSEMBLY REF. # PART # DESCRIPTION QTY. 872372 720-16 5-ARM ROTOR WELDMENT 872361 ROTOR SQUARE WIPER WELDMENT 850007 ROTOR SPRIMG COVER WELDMENT 189141 END WIPER STRAP 27-1/4” 189142 CENTER WIPER STRAP 60” 189143 END PLASTIC WIPER 62-1/2”... -
Page 50: Front End Assembly
720-16 FRONT END ASSEMBLY ITEM # PART # DESCRIPTION QTY. 185257 SHAFT SPACER 185258 ROTOR PLATE INDICATOR, 15/16" OD 185259 Washer, Shaft Spkt, 3 1/2 OD 191969 SHAFT SPACER, 5/8" x 3-1/2" ID 192383 AUGER SHAFT SPACER, 2 1/2" ID X 1 7/8"... -
Page 51: Oil Bath Lubrication Assembly
720-16 OIL BATH LUBRICATION ASSEMBLY VIEW A-A REF. # PART # DESCRIPTION QTY. 356001 1/8” NPTF x 3/16” COMP. 90° 356004 1/4” NPTF x 3/16” XOMP. STRAIGHT 310750 1/8” FPT GREASE ZERK 185045 GREASE LINE x 36” REAR JACKSHAFT BEARING... -
Page 52: Oil Bath Door Assembly
720-16 OIL BATH DOOR ASSEMBLY REF. # PART # DESCRIPTION QTY. 185219 OIL BATH TOP DOOR 189503 CAM ROD SPACER 370317 CAM LOCK BOTTOM PLATE 370316 CAM LOCK TOP PLATE 370323 LEVELING PAD 872706 700 LEFT OB DOOR CAM WA... - Page 53 This page intentionally left blank.
-
Page 54: Drive Assembly
720-16 DRIVE ASSEMBLY CHAINS & TIGHTENERS ROTOR SPROCKET TOP AUGER SPROCKET BOTTOM AUGER SPROCKET TOP AUGER FULL VIEW BOTTOM AUGER TOP AUGER SPROCKET BOTTOM AUGER SPROCKET IDLER SPROCKET IDLER SHAFT SPROCKET INPUT SPROCKET... - Page 55 720-16 DRIVE ASSEMBLY CHAINS & TIGHTENERS ITEM # PART # DESCRIPTION QTY. 181198 PULL TAB 3/4" 182576 CHAIN-2/0 PASSING LINK 185290 SPRING PULL BAR 185487 CHAIN, 2/0 x 3" 185488 CHAIN-2/0 PASSING LINK 185582 IDLER BLOCK #100 x 2 7/8"...
- Page 56 720-16 DRIVE ASSEMBLY DETAIL TOP AUGER DETAIL JACKSHAFT 30 37 42 TOP AUGER 31 38 44 38 44 BOTTOM AUGER 35 47 JACKSHAFT DETAIL ROTOR SECTION M-M ROTOR INPUT SHAFT 46 41 32 DETAIL INPUT SHAFT DETAIL BOTTOM AUGER 32 39 46...
- Page 57 720-16 DRIVE ASSEMBLY ITEM # PART # DESCRIPTION QTY. 185132 INSERT, AUGER COUPLING, 2-1/2" x 3" 185220 BTM AUGER DRIVE BEARING PLATE 185261 WASHER 5 1/2" O.D. 185268 700 TOP AUGER BRG PLATE 14" x 20-1/4" 185269 16" BOTTOM AUGER PLATE MSF 64...
-
Page 58: Stationary Drive Assembly
720-16 STATIONARY DRIVE ASSEMBLY ELEC MOTOR SHAFT... - Page 59 720-16 STATIONARY DRIVE ASSEMBLY REF. # PART # DESCRIPTION QTY. 185641 COVER PLATE 8” x 8” 185643 720 STATIONARY INPUT SHAFT 25” 781130 SEAL PLATE ASSEMBLY 2” 355032 SHAFT SEAL 2” CR 20098 332618 SPROCKET CHAIN COUPLER, 80B18 x 2”...
-
Page 60: Truck Tandem Axle, Driveline Assembly
720-16 TRUCK TANDEM AXLE, DRIVELINE ASSEMBLY 14 16 18 14 16 21 17 15 ITEM # PART # DESCRIPTION QTY. 183319 TRUCK JACKSHAFT BRACKET 185485 KEY, 1/2 x 1/2 x 2-1/2 LG. 185504 JACKSHAFT, 700 TRK, 1-3/8" x 48" 188267 DRIVESHAFT x 48"... -
Page 61: Truck Driveline Assemblies Break Down
620-16/720-16 TRUCK DRIVELINES #780488 ITEM # PART # DESCRIPTION QTY. 338054 DRIVE SHAFT ASSY, INCLUDES ITEMS 2 & 5 338413 U-STRAP & BOLT KIT 1350 338423 YOKE 1-1/4" RD BORE, 5/16" KWY 338424 YOKE 1-3/8" RD BORE, 5/16" KWY 338436... -
Page 62: Truck Single Axle, Driveline Assembly
720-16 TRUCK SINGLE AXLE, DRIVELINE ASSEMBLY ITEM # PART # DESCRIPTION QTY. 183319 TRUCK JACKSHAFT BRACKET 185504 JACKSHAFT, 700 TRK, 1-3/8" x 48" 190487 INPUT SHAFT 2-7/16" x 50-3/4", 720 191974 GEAR BOX PLATE 338048 TRUCK DRIVE SHAFT 340222 BEARING, 1 3/8" VCJT 340232 BEARING, 2", 2 BOLT FLANGE, VCJT... -
Page 63: Trailer Driveline Assembly
720-16 TRAILER DRIVELINE ASSEMBLY ITEM # PART # DESCRIPTION QTY. 185299 CARRIER BEARING ANGLE 185302 PTO SHIELD 185480 3/8" SQ. X 2" KEY 185485 KEY, 1/2" SQUARE 185733 600 TRAILER DRIVELINE 1-3/4" 189555 TRAILER BEARING PLATE 190487 700 INPUT SHAFT 2-7/16" x 50-3/4"... -
Page 64: Trailer To Tractor Driveshaft
TRACTOR TO TRAILER DRIVESHAFT (1000 RPM) - #338058 1 3/8"-21 SPLINE 1 3/4" ITEM # PART # DESCRIPTION QTY. 338442 SLIDE YOKE 1000 RPM, W2400 338443 CROSS KIT, W2400 338450 INBOARD YOKE W2400 S4 356905 338473 ROLL DRIVE PIN #10MM x 80MM 338473 ROLL DRIVE PIN W LTSH 10MM x 90MM 338475... -
Page 65: Truck Loadcell Scale Frame Assembly
720-16 TRUCK LOAD CELL SCALE FRAME ASSEMBLY 8 11 ITEM # PART # DESCRIPTION QTY. 182881 SCALE MOUNT MIXER PLATE 182915 LOAD CELL CAGE PLATE 185997 SCALE PAD 192175 LOAD CELL SPPRT PLT, CRG HEAD 400116 HEX NUT, 3/4"-10 SERRATED FLANGE #5 PLTD 400210 HEX NUT 5/8"-11 #5 PLTD... -
Page 66: Tandem Trailer Loadcell Assembly
720-16 TRAILER LOADCELL ASSEMBLY ITEM # PART # DESCRIPTION QTY. 182881 SCALE MOUNT MIXER PLATE 182915 LOAD CELL CAGE PLATE 185997 SCALE PAD 190075 DIGI-STAR LOAD CELL SUPPORT PT 400210 HEX NUT 5/8"-11 #5 PLTD 400212 HEX NUT 3/4"-10 #5 PLTD 402010 SPRING LOCK WASHER 5/8"... -
Page 67: Stationary Loadcell Scale Frame Assembly
720-16 STATIONARY LOADCELL SCALE FRAME ASSEMBLY REF # PART # DESCRIPTION QTY. 872185 720 STATIONARY SCALE FRAME WELDMENT 870501 SCALE CHECK ROD WELDMENT 19-1/2” CTR-CTR 871053 TRAILER CHECK ROD WELDMENT 31-1/2” CTR-CTR 870519 MIXER SCALE CHECK WELDMENT 182881 SCALE MIXER MOUNT PLATE... -
Page 68: Tandem Trailer Assembly
720-16 TANDEM TRAILER ASSEMBLY REF NO PART NO DESCRIPTION 357400 BATTERY BOX W/STRAP 372077 AXLE ASSEMBLY 77" WT 372188 TANDEM SUSPENSION KIT, 44000lb 400912 HEX CROWN LOCK NUT 3/4"-10 #5 PLTD 405792 HHCS 3/4" x 6 1/2" #5 PLTD 651024... -
Page 69: Trailer 10-Bolt Hub Assembly
720-16 10-BOLT HUB ASSEMBLY (20,000LB) #750110 ITEM # PART # DESCRIPTION QTY. 184614 SPINDLE, 20,000# 342213 INNER BEARING 3.543" BORE 342214 OUTSIDE BEARING 2-5/8" OD 342215 INNER BEARING RACE 5.787"OD 342216 OUTSIDE BEARING RACE 4-13/16" OD 372212 10-BOLT HUB ASSEMBLY, (RIGHT HAND) 20,000# 372304 SEAL 4-3/8"... -
Page 70: Roto-Hay Processor Assembly (Hydraulic Option)
720-16 ROTO-HAY PROCESSOR ASSEMBLY (HYDRAULIC OPTION) #780481 REF # PART # DESCRIPTION QTY. 188226 FEEDER ELECTRIC CONTROL BRACKET 357702 PUSH BUTTON SWITCH 12V-2POLE 780124 MV5 3RD VALVE ADD ON KIT 780109 HYDRAULIC CYLINDER ASSY, 2” x 8” (WITH FITINGS) 364055 HYDRAULIC CYLINDER 2"... -
Page 71: Rotor-Hay Processor Assembly (Cable Option)
720-16 ROTO-HAY PROCESSOR ASSEMBLY (CABLE OPTION) REF. # PART # DESCRIPTION QTY. 850090 HAY PAN CABLE ARM W.A. 850105 CORNER PULLEY BRACKET W.A. 850066 CABLE PULLEY BRACKET W.A. 150186 CABLE WINCH MOUNT PLATE 150279 HAY PAN CABLE 13FT 150188 CABLE BAR 150189 SLEEVE 13/16”... -
Page 72: Roto-Hay Processor Assembly
720-16 ROTO-HAY PROCESSOR ASSEMBLY ITEM # PART # DESCRIPTION QTY. 150198 BAFFLE PLUNGER 4-3/4" 150223 KNIFE BACK UP PLATE 189127 HAY TUBE SLEEVE RETAINER 4-1/2" 189128 CROSS BAR PLATE 385002 SICKLE SECTION, HARD SURFACED, 5/16" 872351 524/600 HAY PAN WA 872353 600 HAY PAN BEARING W.A. -
Page 73: Cross Over Bar & Hay Shear Bar
720-16 CROSS OVER BAR & HAY SHEAR BAR 1 2 5 ITEM # PART # DESCRIPTION 400908 HEX CROWN LOCNUT 1/2"-13 #9 402408 WASHER, FLAT 1/2" MED PLTD 407101 CHCS 1/2"-13 x 1-1/4" #5 PLTD 407112 CHCS 1/2"-13 x 5" #5 PLTD 407113 CHCS 1/2"-13 x 4-1/2"... -
Page 74: Ladders Options
LADDER OPTIONS AVAILABLE ITEM # PART # DESCRIPTION QTY. 780095 LADDER BUNDLE, (2 RUNG EXTN) 780288 LADDER BUNDLE, (6 RUNG) 780289 LADDER BUNDLE, (5 RUNG) 780906 LADDER BUNDLE, (7 RUNG) -
Page 75: Truck Front Bumpers
TRUCK FRONT BUMPERS HYDRO FRONT BUMPER HIGH MNT W/ROLLER #780945 ITEM # PART # DESCRIPTION QTY. 192227 SPACER, BUMPER ROLLER 340222 BEARING, 1 3/8" VCJT 872431 BMPR FRT HYDRO W/HIGH RLLR WA 872434 ROLLER, FT BUMPER, 5" DIA. HEAVY FRONT BUMPER HIGH MNT W/ROLLER #780946 ITEM #... - Page 76 TRUCK FRONT BUMPERS FRONT BUMPER With HIGH ROLLER #981018 ITEM # PART # DESCRIPTION QTY. 192227 SPACER, BUMPER ROLLER 340222 BEARING, 1 3/8" VCJT 370334 MARKER, ORANGE STICK x 2 FT 872434 ROLLER, FT BUMPER, 5" DIA. 872439 BUMPER FRT W/HIGH ROLLER WA. FRONT BUMPER With LOW ROLLER #981019...
- Page 77 TRUCK FRONT BUMPERS FRONT BUMPER NO ROLLER #981021 ITEM # PART # DESCRIPTION QTY. 370334 MARKER, ORANGE STICK x 2 FT 872432 BUMPER, TRK FRT, NO ROLLER HYDRO FRONT BUMPER NO ROLLER #981022 ITEM # PART # DESCRIPTION QTY. 872433 BUMPER, TRK FRT NO ROLLER 370334 MARKER, ORANGE STICK x 2 FT...
-
Page 78: Truck Rear Bumpers
ITEM # PART # DESCRIPTION QTY. 185600 TAIL LIGHT BRKT 192219 PLATE, FLR 10" RR BMPR ROTO-MIX 400005 FLANGE NUT, TOP LOCK. 5/8-11 GR"G" 400007 Flange Nut, Top Lock. 3/8-16 GR "G" 407040 CHCS 3/8"-16 x 1" #5 PLTD 407121 CHCS 5/8"-11 x 2"... - Page 79 TRUCK REAR BUMPER, 10", ROUND LIGHT HOLES #780949 ITEM # PART # DESCRIPTION QTY. 192219 PLATE, FLR 10" RR BMPR ROTO-MIX 400005 FLANGE NUT, TOP LOCK. 5/8-11 GR"G" 400007 Flange Nut, Top Lock. 3/8-16 GR "G" 407040 CHCS 3/8"-16 x 1" #5 PLTD 407121 CHCS 5/8"-11 x 2"...
