1220-20 TRUCK &
STATIONARY FEED MIXER
SAFETY &
OPERATION MANUAL
ROTO-MIX
P.O. Box 1724
2205 E. Wyatt Earp Blvd.
Dodge City, Kansas 67801
(620) 225-1142
© ROTO-MIX LLC 2006
SERIAL NO. _______________
08/2020
441952
Printed in U.S.A.
