Simoco SRM9000 Alignment Manual page 2

PC
DB25
PRM80
Programming Cable
P/N 9525-001-00016
Figure 0 SRM9000 Programming & Alignment Breakout Box
To
SRM9000 P2
Pins 6 & 13
Figure 1 SRM9000 Speaker Output Breakout Box
SRM9000 ALIGNMENT
AF Generator
BNC (F)
Connector
White (8)
(Not Used)
Green(4)
Access and modify
cable as shown
.
T1
R
.
R = Audio power Load (set as appropriate)
or
Resistor 4R 4W for ½ Bridge Speaker option
Resistor 8R 12W for full Bridge Speaker option
2 of 13
Page
TNM-M-E-0019 Issue 1
22uF to 47uF
Tant. or Elect
White
+
470E R
Orange
Black
Red
Green
Yellow
Blue
Brown
9000_49/2
600R 1:1
To
Line Matching
Noise & Distortion Meter
Transformer
&
.
Oscilloscope
9000_49/3b
To
SRM9000
S1
RJ45
8
Mic Audio in
7
Ground
6
Handset AF Output
5
13.8V Switched
4
Mic Ground
3
On/Off
2
Rx Data
1
Tx Data
