ALIGNMENT (LEVEL 3 SERVICE ONLY)
This procedure is applicable to all versions of SRM9000 mobile transceivers.
Preparing the radio for alignment will erase from the radio all customer PMR and Trunking
configuration data (channel, signalling information etc). The only data retained by the Alignment
Tool is the factory alignment data for the radio (DAC settings for Tx power, front-end tuning, etc).
Using the Alignment Tool will allow changes to the original factory alignment and will invalidate
all warranties and guarantees unless performed by an authorised level 3 service centre.
If the radio contains customer configuration data that must be retained, you must first use the SRM/SRP
Personality Programmer (FPP) software to read all radio configuration files and save them on to alternative
media before commencing the alignment procedure.
When the Alignment is completed, use the FPP software to retrieve this stored data and write it back to the
radio.
It is preferred that the radio remain installed in its aluminium extruded case throughout this alignment
procedure. If the radio is to be aligned when removed from the case, a temporary heat sink must be fitted
under the Transmitter PA module and the receiver output must be kept below 100mW.
Note. Final Tx power adjustments must be performed with the radio board installed in the chassis.
T
E
EST
QUIPMENT
1.
Radio transceiver test set
2.
Variable DC power supply
3.
Oscilloscope
4.
SRM9000 Programming & Alignment Breakout
Box
5.
SRM9000 Speaker O/P Breakout Box
6.
Personal Computer
7.
SRM/SRP Alignment Tool
8.
SRM/SRP Field Personality Programmer
(FPP)
SRM9000 ALIGNMENT
Caution
1 of 13
Page
TNM-M-E-0019 Issue 1
CMT, 52/82 or similar.
Note. For alternative equipment, the Mod
Balance test requires internal DC coupling
between the demodulated signal and
demodulation output connector.
10.8V to 16.3V current limited to 7 amps
20 MHz bandwidth minimum
As detailed in Figure 0
As detailed in Figure 1
486 DX 66 or better.
Operating system Windows 95 or later.
Minimum RAM - 16MB.
5MB free hard disk space.
Floppy drive - 1.44MB.
Mouse and serial port required
Computer Software file
Computer Software file

Advertisement

loading
Need help?

Need help?

Do you have a question about the SRM9000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Simoco SRM9000

  • Page 1 SRM9000 ALIGNMENT TNM-M-E-0019 Issue 1 ALIGNMENT (LEVEL 3 SERVICE ONLY) This procedure is applicable to all versions of SRM9000 mobile transceivers. Caution Preparing the radio for alignment will erase from the radio all customer PMR and Trunking configuration data (channel, signalling information etc). The only data retained by the Alignment Tool is the factory alignment data for the radio (DAC settings for Tx power, front-end tuning, etc).
  • Page 2 PRM80 Brown Tx Data Programming Cable P/N 9525-001-00016 Access and modify cable as shown 9000_49/2 Figure 0 SRM9000 Programming & Alignment Breakout Box 600R 1:1 SRM9000 P2 Line Matching Noise & Distortion Meter Pins 6 & 13 Transformer & Oscilloscope R = Audio power Load (set as appropriate) Resistor 4R 4W for ½...
  • Page 3 SRM9000 ALIGNMENT TNM-M-E-0019 Issue 1 Noise & Distortion Meter SRM9000 SRM9000 Speaker O/P Breakout (DB15M) SRM9000 Programming RJ45 Alignment Breakout 13.8V DC Power Supply Antenna Skt Coax (<200 mm) Generator Radio Transceiver Test 9000_49 Figure 2 Test Set-up 1. Connect the radio to the test equipment as shown in Figure 4-3.
  • Page 4: Comms Set Up

    SRM9000 ALIGNMENT TNM-M-E-0019 Issue 1 COMMS Set up Copy the SRM9000 Alignment Tool Computer Software file to the PC hard drive and run the program The Alignment Tool Opening Menu is displayed. Go to the Options menu and choose Comms Setup.
  • Page 5: Radio Preparation

    SRM9000 ALIGNMENT TNM-M-E-0019 Issue 1 Radio Preparation Radio parameters are to be aligned sequentially as detailed in this procedure. At the Opening Menu, select the Align Menu and choose Prepare/Read Radio. The WARNING is displayed. Choose No if you want to save the configuration and use the FPP software to read and save the data to a file.
  • Page 6: Alignment Procedure

    SRM9000 ALIGNMENT TNM-M-E-0019 Issue 1 Alignment Procedure Radio alignment must be done in the sequence detailed in the following paragraphs. This alignment assumes that the radio is functioning normally. VCO DAC Alignment Select the VCO DAC page. Select Auto Align. The Synth DAC Rx slider will automatically adjust its value for each receiver alignment frequency to set the VCO loop filter value between 140 and 150.
  • Page 7 SRM9000 ALIGNMENT TNM-M-E-0019 Issue 1 TCXO (Radio Netting Adjustment) Select the Mute/TCXO page. Select PTT. Adjust the TCXO slider to ensure that the transmit frequency error is within 50Hz for the selected channel (to be measured on the RF Test Set frequency counter).
  • Page 8 SRM9000 ALIGNMENT TNM-M-E-0019 Issue 1 Rx Front End Ensure that the TCX0 Alignment has been done before proceeding with this section. Select the Rx Front End Page. Select Open Mute. Set the Volume slider to 15. Speaker audio should now be visible on the Scope. If required readjust the Volume slider to a suitable level.
  • Page 9 SRM9000 ALIGNMENT TNM-M-E-0019 Issue 1 Mute Adjustment Note. This adjustment has default setting of 1000/2600 and should not need changing except for specific requirements. Select the Mute/TCXO page and select Open Mute. Set the RF signal generator to the receiver alignment frequency, and adjust the RF level such that the desired mute opening SINAD (typically 10dB SINAD) is achieved.
  • Page 10 SRM9000 ALIGNMENT TNM-M-E-0019 Issue 1 RSSI Select the RSSI Cal page. Set the Signal Generator for a RF output level of -90dBm and 2kHz deviation at the specified frequency. Activate the Store RSSI button. The receiver RSSI threshold setting is calibrated.
  • Page 11 SRM9000 ALIGNMENT TNM-M-E-0019 Issue 1 Tx Power Select Tx Power/Mod page. Select Channel 0. Select the 1W power level. Press the PTT button. Adjust the Tx Final Value slider for a power output of 1W. Repeat step 5 for the remaining 3 Channels (1, 2, & 3).
  • Page 12 SRM9000 ALIGNMENT TNM-M-E-0019 Issue 1 Modulation Select Tx Power/Mod page. Select Channel 0. Select the 1W power level. Set the microphone input signal from the Audio Generator to 1000Hz at 400 mV RMS. Adjust the VCO Modulation Limit slider for a maximum peak deviation of ±2.3kHz Reduce the microphone input level to 40mV RMS and check that the deviation is within the range ±1.25 kHz to ±1.75 kHz.
  • Page 13 SRM9000 ALIGNMENT TNM-M-E-0019 Issue 1 Programming When all channels have been aligned the radio is programmed with the new alignment data: Select Align and choose Write Alignment. A warning message is displayed. Choose Yes. New alignment data is written to the radio.
