Lippert Components OneControl X1 Oem Installation Manual page 8

NOTE: If more than one device type of the same name is used, press INSTANCE (Fig. 15B) to select a
number, e.g. Ceiling Light 1, Ceiling Light 2, etc.
3. Press UNKNOWN under Name to select a specific name (Fig. 14A).
4.
Press SET (Fig. 14B) and Saved! (Fig. 15A) will appear in the lower left corner, replacing Loaded!
5.
Scroll down to the next field of FUSE TYPE, select a fuse and press SET to save the selection.
Saved! (Fig. 16A) will appear in the lower left corner, replacing Loaded!
NOTE: The next options are all pre-loaded but will not be active until SET is pressed and Saved! appears in
the lower left corner.
6. IGNITION OPERATION MODE (Fig 17): Scroll down to IGNITION OPERATION MODE.
7.
Choose one of the options (Fig. 18): Always or Only with Ignition On.
A
A
Rev: 08.31.20
Fig. 14
Fig. 16
Fig. 18
B
A
A
A
Page 8
Fig. 15
B
Fig. 17
Fig. 19
CCD-0002697
