  • Page 1 OneControl X1 Control Board ® OEM INSTALLATION MANUAL...

  • Page 2: Table Of Contents

    Loading Configuration Introduction The OneControl X1 Control Board will primarily be operated by a phone app utilizing a Bluetooth connection. Users can access and adjust a system via a touchscreen icon. If the trailer already has a OneControl Touch Panel, then the controller can be tied into the OCTP by CAN bus harness. The configurator kit supplied to OEMs must be used to program the configurable inputs and the latching and reversing outputs.

  • Page 3: Safety

    Safety Read and understand all instructions before installing or operating this product. Adhere to all safety labels. This manual provides general instructions. Many variables can change the circumstances of the instructions, i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This manual cannot begin to plot out instructions for every possibility, but provides the general instructions, as necessary, for effectively interfacing with the device, product or system.

  • Page 4: Installation

    Installation Install controller in watertight location. Connect 12V power and ground to the board. NOTE: Use a 30A circuit at the power converter or connect on the converter side of the battery disconnect with a 30A mini breaker in line prior to the X1 controller. Make sure to follow RVIA guidelines for wire gauge and fusing.

  • Page 5: Wiring

    Each output used must be assigned and named using the X Series Configurator (Fig. 4) during the configuration procedure. High Current (HC) Reversing Outputs (Fig. 1, #3, #4 and #5): Connections are available for three high current reversing outputs. Each output uses a quick slide connector for Extend and Retract. Each output used must be assigned and named using the X Series Configurator (Fig.

  • Page 6: Configuring Inputs, Outputs

    Configuring Inputs, Outputs The X Series Configurator with supplied OneControl Touch Panel must be used to program the configurable inputs and the latching and reversing outputs. Once the inputs and outputs are configured, the configuration can be saved onto a thumb drive and then loaded onto additional controllers. Open supplied X Series Configurator box (Fig.

  • Page 7: Latching Relays

    The HOME screen will appear on the OneControl Touch Panel (Fig. 8). Tap HOME (Fig. 8A) five times to reach the configurator screen. A warning about entering an Advanced Feature will appear (Fig. 9). Press YES. The configurator screen will appear (Fig. 10). Latching Relays Scroll down to the Latching Relay section and press UNKNOWN on Latching Relay #1 (Fig.
  • Page 8 NOTE: If more than one device type of the same name is used, press INSTANCE (Fig. 15B) to select a number, e.g. Ceiling Light 1, Ceiling Light 2, etc. Press UNKNOWN under Name to select a specific name (Fig. 14A). Press SET (Fig.
  • Page 9 Press SET (Fig. 18A). Saved! will replace Loaded! on the screen (Fig. 19A). PARK BRAKE OPERATION MODE (Fig. 20): Scroll down to PARK BRAKE OPERATION MODE. 10. Choose one of the options (Fig. 21): Always or Only with Park Brake On. 11.
  • Page 10 14. Press SET (Fig. 24A) Saved! will replaced Loaded! on the screen (Fig. 25A). 15. SWITCH TYPE (Fig. 26): Scroll down to SWITCH TYPE. 16. Choose one of the options (Fig. 27): Toggle Switch or Momentary Switch. 17. Press SET (Fig. 27A). Saved! will replace Loaded! on the screen (Fig. 28A). 18.
  • Page 11 20. Press SET (Fig. 30A). Saved! will replace Loaded! on the screen (Fig. 31A). 21. ON/OFF INPUT (Fig. 32): Scroll down to ON/OFF INPUT. 22. Choose one of the options (Fig. 33): Not Set, 1 to 16. NOTE: Use caution not to assign the same input to multiple outputs. 23.
  • Page 12 27. DEVICE ACTIVATION TIMEOUT (Fig. 38): Scroll down to DEVICE ACTIVATION TIMEOUT. 28. Choose one of the options (Fig. 39): Disabled, various increments from 1 minute to 1 hour. 29. Press SET (Fig. 39A). Saved! will replace Loaded! on the screen (Fig. 40A). 30.

  • Page 13: Reverse Polarity Outputs

    Reverse Polarity Outputs Press UNKNOWN at Momentary H-Bridge #1 (Fig. 41A) to begin programming reversing outputs. Press UNKNOWN under TYPE and select device type (Fig. 42). NOTE: If more than one device type of the same name is used, press INSTANCE (Fig. 44C) to select a number, e.g.
  • Page 14 IGNITION OPERATION MODE (Fig. 45): Scroll down to IGNITION OPERATION MODE. Choose one of the options (Fig. 46): Always or Only with ignition On. Press SET (Fig. 46A). Saved! will replace Loaded! on the screen (Fig. 47A). PARK BRAKE OPERATION MODE (Fig. 48): Scroll down to PARK BRAKE OPERATION MODE. Choose one of the options (Fig.
  • Page 15 11. IN-MOTION LOCKOUT LEVEL (Fig. 51): Scroll down to IN-MOTION LOCKOUT LEVEL. 12. Choose one of the options (Fig. 52): Operation NOT allowed or Only Retract allowed. 13. Press SET (Fig. 52A). Saved! will replace Loaded! on the screen (Fig. 53A). 14.
  • Page 16 17. EXTEND AND RETRACT INPUTS (Fig. 57): Scroll down to the EXTEND AND RETRACT INPUTS. 18. Select the input numbers to be assigned to EXTEND and RETRACT for this output (Fig. 58). 19. Press SET (Fig. 58A) Saved! will replace Loaded! on the screen (Fig. 59A) 20.
  • Page 17 22. Saved! will appear on the screen in the lower left (Fig. 61A). 23. Press the back button (Fig. 61B) to return to the main configuration screen. 24. Configure up to four more pairs of reversing outputs. 25. Press the Home button (Fig. 61C) to return to the Home screen. 26.

  • Page 18: Saving Configuration

    Saving Configuration The X Series Configurator may also be utilized to save the installed configuration onto a clean thumb drive so it can be loaded onto other controllers. Insert thumb drive into the USB port in the front of the OneControl Touch Panel (Fig. 63). A dialogue box will ask whether to save or load the configuration (Fig.

  • Page 19: Loading Configuration

    Loading Configuration Insert programmed thumb drive into the USB port of the OneControl Touch Panel (Fig. 69). A dialogue box will ask whether to save or load the configuration (Fig. 70). Press LOAD (Fig. 70A). NOTE: If the box doesn't pop up automatically, it can be accessed by pressing the menu bars in the top left corner beside All Devices (Fig.
  • Page 20 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”).  LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided.  Any unauthorized use shall void any applicable warranty. ...
