Introduction
Preventative Maintenance
Operation Mode
Fault Diagnostics
Troubleshooting
Override Modes
!
CAUTION
Do not work on your slide
out system unless the
battery is disconnected
Introduction
1
1
SYSTEM DESCRIPTION
2
Your Power Gear Slideout System is a rack and pinion design operated by a pair of
3
12 Volt DC electric motors.
4
MAJOR COMPONENTS
6
· Inner rail assemblies are designed to support the room weight.
· The 12 Volt DC gearmotor will operate the room using power from the battery.
· Slideout systems are equipped with a manual override that allows you to extend
/ retract the room in the event of a loss of power.
· A specially designed control that gives the user full control of room movement, in
or out. The control has programmable stops that stop the motor when the room
is fully extended or retracted and the ability to detect faults for ease in
troubleshooting.
Preventative Maintenance
Your Power Gear slide-out system has been designed to require very little
maintenance. To ensure the long life of your slide-out system read and follow these
few simple procedures.
‡ :KHQ WKH URRP LV RXW YLVXDOO\ LQVSHFW WKH LQQHU VOLGH UDLO DVVHPEOLHV &KHFN IRU
excess build-up of dirt or other foreign material; remove any debris or items that
may be present.
‡ ,I WKH V\VWHP VTXHDNV RU PDNHV DQ\ QRLVHV LW LV SHUPLVVLEOH WR DSSO\ D OLJKW FRDWLQJ
of silicone spray or lithium grease to the roller and bearing sleeve I.D., removing
any excess lubricant so that dirt or debris do not build-up. DO NOT lubricate the
slide-out drive gears, gear racks, or roller OD as this will attract dirt / debris.
IF YOU HAVE ANY PROBLEMS OR QUESTIONS CONSULT YOUR LOCAL
AUTHORIZED DEALER.
Owners Manual
M² - Sync Room Slideout System: for
slideout control boxes 1510000122,
1510000143 and 1510000198
© 01/13 REV 01/19 Power Gear 3010001344 Rev. 0E
M²-Sync Room
Slideout System
Owners Manual
CCD-0002533

Advertisement

loading
Need help?

Need help?

Do you have a question about the Power Gear M2-Sync and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lippert Components Power Gear M2-Sync

  • Page 1 Owners Manual M² - Sync Room Slideout System: for slideout control boxes 1510000122, 1510000143 and 1510000198 © 01/13 REV 01/19 Power Gear 3010001344 Rev. 0E M²-Sync Room Slideout System Owners Manual CONTENTS CONTENTS Introduction Introduction Preventative Maintenance SYSTEM DESCRIPTION Operation Mode Your Power Gear Slideout System is a rack and pinion design operated by a pair of Fault Diagnostics 12 Volt DC electric motors.
  • Page 2: Operation Mode

    M²-Sync Room Slideout System Page 2 Operation Mode Two different versions of touch pads are used on this system (see figure 1). Unless WARNING otherwise noted, all operation of the control is the same regardless of which touch pad comes equipped with your coach. Always make sure that the Touch Pad “A”...
  • Page 3: Fault Diagnostics

    M²-Sync Room Slideout System Page 3 Fault Diagnostics This control has the ability to detect and display several faults. When a fault is detected, the room movement will stop, and two different LEDs will flash in a pattern. •The Fault Code LED (Fig 1) will flash a number of times corresponding to a specific fault code.
  • Page 4 M²-Sync Room Slideout System Page 4 Troubleshooting - Touch Pad A Use this troubleshooting chart if your touchpad looks like the picture above. (Usually used with Control Box 1510000122) Fault Fault Description Probable Cause Possible Solutions Code Type Major Stop Not Programmed No stop locations has Stops need to be reprogrammed by an been set for the control...
  • Page 5 M²-Sync Room Slideout System Page 5 Troubleshooting - Touch Pad B Use this troubleshooting chart if your touchpad looks like the picture above. (Usually used with Control Box 1510000143 and 1510000198) CODE POSSIBLE SOLUTIONS TYPE DESCRIPTION PROBABLE CAUSE Stops need to be reprogrammed by an Major Stops Not Programmed No stop locations have been set for the...
  • Page 6 M²-Sync Room Slideout System Page 6 Override Modes In the event of component failure or loss of system power, your system can be WARNING manually overridden. After the room has been NOTE: At anytime during the override procedure, the unit will exit override mode if the room had not been moved for 2 minutes (note: on early production models, the 2 minute moved in the desired direct- timeout was only 45 seconds) or if a fault is detected during overriding, the Fault Code...
  • Page 7 M²-Sync Room Slideout System Page 7 Override Modes, cont. The system has been equipped with ¾” hex override couplers located on the back WARNING side of the motors. Due to the size and weight of the room, assistance will be needed and care taken during the process.
  • Page 8 M²-Sync Room Slideout System Page 8 Additonal Reference Documents Additional Reference Documents Located at www.lci1.com: 3010001343 Installation and Service Manual for Slideout Control Box 1510000122 3010002088 Installation and Service Manual for Slideout Control Boxes 1510000143 and 1510000198 82-SO521 Encoder Test 1: Dual Sync Slide Controllers (M²) 1510000122, 1510000143, and 1510000198 82-SO522 Encoder Test 2: Dual Sync Slide Controllers (M²) 1510000122, 1510000143, and...
