Buffer, loops (LOOP 1 to LOOP 6), SWITCH outputs and AUX outputs

In order to switch on or off the buffer, particular effect LOOPs, SWITCH outputs and AUX outputs press the
button placed under the indicator signalising their state. Lighting lamp means: the buffer is switched on, the
effect connected to the loop is switched on, output shorting state of the particular SWITCH and high level
of AUX output.
Lighting of the decimal point after the P letter means that actual preset was modified.

MIDI program numbers programming

MGC-6 enables to control three MIDI devices separately (on different channels set on SETUP function) by
the Program Change commands defined as PRG CHG-1, PRG CHG-2, PRG CHG-3.
Programming no value results in not sending for given preset Program Change command.

CC Contollers' value programming

Controller enables to send Control Change command with controller No set on SETUP function and with
the value programmed for each preset defined as CTRL CHG.
6
