- Page 3 Controller (GSC) enabling switching on a wah-wah effect by placing a foot on it and switching off a wah-wah effect by removing a foot. The wah-pad should be placed beneath a wah-wah effect and the wah-pad’s connector should be plugged into the GSC’s...
- Page 4 The GSC enables the two wah-pad’s modes of working: - to switch on at any preset a loop to which a wah-wah effect is connected (“adding to preset a wah-wah” mode), - to switch on No. 5 preset in each bank (“changing preset”...
- Page 5 To prevent moving a wah-wah effect along the wah-pad there should be stuck attached self adhesive elements. They should be placed on the upper wah-pad surface possibly close to a wah-wah legs as it is shown on the below picture.
- Page 6 Technical specification: Dimentions Weight Product Model [mm] [kG] code 260 x 100 x 13,5 0,55 00802 Wah-pad (wah-wah pad) This manual refers to products specified in the table above.
- Page 7 DO NOT PLACE THIS PRODUCT INTO THE WASTE CONTAINER ! This device is marked with a cross-lined waste container symbol according to 2002/96/EU Directive on Waste Electric and Electronic Equipment. Such marking informs that after usage equipment can not be trashed together with other household waste.
