- Page 1 SKU: NOF100SS00 24” Dual Drawer Outdoor Wine and Beverage Fridge OWNER’S MANUAL Read and save these instructions. Manual v1.0...
-
Page 2: Table Of Contents
Register Your Product Online ................3 Safety Information & Warnings ................4 Assembly & Installation ..................6 Operating Your Fridge ..................11 Cleaning & Maintenance ..................12 Limited Manufacturer’s Warranty ..............13 SPECIFICATIONS NOF100SS00 ODEL 110-120V OLTAGE 1.3A URRENT 60Hz... -
Page 3: Register Your Product Online
REGISTER YOUR PRODUCT ONLINE Register Your NewAir Product Online Today! Take advantage of all the benefits product registration has to offer: Service and Support Diagnose troubleshooting and service issues faster and more accurately Recall Notifications Stay up to date for safety, system updates, and recall notifications... -
Page 4: Safety Information & Warnings
SAFETY INFORMATION & WARNINGS Your safety and the safety of others is very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. - Page 5 • Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in this manual. For any further issues, please contact customer service at support@newair.com. WARNING • Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
-
Page 6: Assembly & Installation
ASSEMBLY & INSTALLATION Initial Setup Before connecting the fridge to the power source, let it stand upright for approximately 24 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. Once you have plugged the unit into an electrical outlet, let the unit run for at least 30 minutes to acclimate before making any adjustments. - Page 7 OPTIONAL ANTI-TIP BRACKET INSTALLATION This unit comes with optional anti-tip brackets that help prevent sliding or tipping. If you want to install them, follow these instructions: 1. You can use one (or both) of the anti-tip brackets. Brackets are meant to be screwed into the floor for the back adjustable feet of the fridge to slide and lock into.
- Page 8 5. Once plastic anchors are in place, use the screws to secure the brackets in place. Alternate turning all four screws on each bracket to prevent the bracket from moving too much from the original location. 6. Lift the unit to access the adjustable feet at the back. Use a screwdriver to remove the two screws between the feet and the back of the unit.
- Page 9 INSTALLING THE HANDLE Press the included screws through the openings on the inside of each drawer so that they show through the front of the drawer. Line up the handle with the screws, and screw them in. Alternate turning each screw so the handle doesn’t end up crooked.
- Page 10 INSTALLATION OPTIONS This unit can be installed under a counter or between cabinets, but it • must be positioned so that the vent at the bottom of the front of the unit is free from obstruction. Allow for ¼ inch of clearance on all sides (and the top) and 1 inch of clearance at the back to prevent issues with proper airflow.
-
Page 11: Operating Your Fridge
OPERATING YOUR FRIDGE 1. Temperature increase and defrost on/off button (this button will only adjust the temperature if the temperature adjustment button is selected first. Otherwise, it will change the defrost setting.) Press and hold this button for 6 seconds to manually enable/disable defrosting mode. 2. -
Page 12: Cleaning & Maintenance
CLEANING & MAINTENANCE WARNING: To avoid electrical shock, always unplug your fridge before cleaning. Ignoring this warning may result in injury or death. CAUTION: Before using cleaning products, always read and follow manufacturer's instructions and warnings to avoid personal injury or product damage. -
Page 13: Limited Manufacturer's Warranty
When making a warranty claim, please have the original bill of purchase with purchase date available. Once confirmed that your appliance is eligible for warranty service, all repairs will be performed by a NewAir™ authorized repair facility. The purchaser will be responsible for any removal or transportation costs.
