- Page 1 CITATION BAR OWNER’S MANUAL...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Do Not Use Extension Cords To avoid safety hazards, use only the power cord supplied with this product. We do not recommend that extension cords be used with this product. As with all electrical devices, do not run power cords under rugs or carpets, or place heavy objects on them. -
Page 3: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..........2 INTRODUCTION ..................4 WHAT’S IN THE BOX ................5 PRODUCT OVERVIEW ................7 INSTALLATION ................... 11 CONNECTING TO TV ................14 CONNECTING TO OTHER DEVICES ..........16 POWER ON ....................18 CONNECTING TO INTERNET .............19 SPEAKER SETUP (OPTIONAL) ............21 USING YOUR CITATION BAR .............23 SOUND SETTINGS ................ -
Page 4: Introduction
Design and specifications are subject to change without notice. If you have any questions about these products, their installation or their operation, please contact your Harman Kardon retailer or customer service, or visit us at www. harmankardon.com... -
Page 5: What's In The Box
WHAT’S IN THE BOX Carefully unpack the box and check if the following parts are included. If any part is damaged, do not use it, contact your Harman Kardon retailer or customer service. 1. Main unit 2. Power cord 3. HDMI cable 4. - Page 6 Inserting batteries before using the remote control (AAA batteries x 2) Slide the battery cover in the direction of the arrow until it is completely removed. Insert 2 AAA batteries (1.5V) oriented so that their polarity is correct. Slide the battery cover back into position.
-
Page 7: Product Overview
PRODUCT OVERVIEW Front Panel & Top Panel 1. Touch screen (Swipe up / down / left / right to find out more) Wi-Fi signal indicator. Press to mute or unmute the microphone. Push to talk to Xiaowei Voice Assistant. Press to select a source (Bluetooth / Aux / / / / HDMI / Optical). - Page 8 3. - / + (Volume) • Press to decrease or increase the volume. • Press both simultaneously to mute the soundbar audio. Back Panel 1 2 3 4 5 6 7 8 1. ETHERNET • Connect to the Internet (RJ45 connector). 2.
- Page 9 (Power) Remote Control • Power on or switch to standby. 2. Source zone • Select an input source for the soundbar: OPTICAL / AUX / HDMI TV / HDMI 1 / HDMI 2 / HDMI 3 / Bluetooth. • Press to pair with a new device.
- Page 10 9. BASS - / + • Decrease or increase the bass level of the soundbar (or the optional subwoofer when successfully paired). 10. AUDIO SYNC - / + • Decrease or increase audio sync delay if the video and audio synchronization is not correct. 11.
-
Page 11: Installation
INSTALLATION Placement NOTES: • To avoid wireless interference, keep a minimum distance of 5 meters (16.4 feet) between other wireless devices and the soundbar. • Make sure that there is a live AC (mains) outlet nearby. • Do not place the soundbar on its front, back or top when in use. •... - Page 12 Wall-mount NOTES: • Before mounting on a wall, make sure the wall can support the weight of this product. • For the wall mounting, avoid a location with high temperature or humidity. Install on a vertical wall only. • Connect cables from the product to external devices before mounting on the wall.
- Page 13 2) Screw the wall-mount brackets on the pen mark; screw the threaded mounting post into the back of the soundbar, then hook the soundbar on the wall. ≤8 mm/ 4mm/0.16" 0.31" ≥35 mm/1.4"...
-
Page 14: Connecting To Tv
CONNECTING TO TV NOTES: • If you want to enjoy sound only from the soundbar, make sure to set your TV audio settings to support external speakers and disable the built-in TV speakers. • Before you make or change any connections, make sure that all devices are disconnected from the power outlet. - Page 15 Optical NOTE: • Make sure you have removed the protective cap from both ends of the optical cable. 1) Connect the OPTICAL IN connector on the soundbar to the OPTICAL OUT connector of your TV with an optical cable (sold separately). 2) Press OPTICAL IN on the touch screen or press the OPTICAL button on the remote control to select the OPTICAL mode.
-
Page 16: Connecting To Other Devices
CONNECTING TO OTHER DEVICES HDMI (Preferred) Connect a digital device such as a set-top box, DVD/Blu-ray player, or games console to your soundbar through a single HDMI connection. 1) Connect the HDMI cable from the HDMI IN connector on the back of the soundbar to the HDMI OUT connector on your digital device. - Page 17 Optical or Analogue 1) Connect the OPTICAL IN or AUX IN connector on the soundbar to the OPTICAL OUT or AUDIO OUT jack of the source device by using an optical cable (sold separately) or 3.5mm audio cable (sold separately). 2) Press OPTICAL IN or AUX on the touch screen or press the OPTICAL or AUX button on the remote control to select the OPTICAL or AUX mode.
-
Page 18: Power On
POWER ON NOTES: • Use the provided power cord only. • Before connecting the power cord, make sure all other connections have been completed. • When you disconnect the power cord, always pull the plug, never the cable. • Do not connect this product or other components to an AC outlet until all connections between components are complete. -
Page 19: Connecting To Internet
CONNECTING TO INTERNET Your CITATION BAR is required to connect to the Internet (Wi-Fi or Ethernet) with the HK Citation / Surround app. NOTES: • If you want to use the Internet with Ethernet, make sure to connect the Ethernet cable before plugging in the power cord. •... - Page 20 * To avoid any interference, keep a minimum distance of 5 meters (16.4 feet) between the soundbar and your Wi-Fi router. >5m NOTE: • Make sure that you have updated the HK Citation / Surround app to the latest version, and have enabled the Bluetooth and location service (iOS / Android).
-
Page 21: Speaker Setup (Optional)
SPEAKER SETUP (Optional) Speaker Setup You can wirelessly pair your CITATION BAR with: • CITATION SUB (subwoofer, sold separately): to enhance the bass performance; • CITATION SURROUND (satellite speakers, sold separately): to set up a 5.0 channel surround sound system. •... - Page 22 3) To remove the setup, press “Surround Setup” or “Subwoofer pairing” again, or reset the soundbar. CITATION SURROUND CITATION SUB CITATION SURROUND LED Indicator (CITATION SUB / CITATION SURROUND) • Pairing White (Flashing) • Out of range / Lost wireless connection White (Constant for 10 •...
-
Page 23: Using Your Citation Bar
USING YOUR CITATION BAR Play Music Stream QQ Music through Wi-Fi NOTES: • The Citation Bar can support audio streaming but not video streaming. • Make sure that QPlay is enabled while streaming music via Wi-Fi. 1) Download and run the QQ Music app on your smartphone or tablet. - Page 24 c. Tap + to set up a speaker group. Group 1 HK Citation / Surround HK Citation Tower 2) Multi-room playback: Follow the steps under "Stream QQ Music through Wi-Fi" to select the grouped speakers. 3) To adjust the volume, do the following: a.
- Page 25 4) To edit the speaker group, do the following: a. On the speaker screen, tap to edit the setup of the speaker group; b. Tap "Edit devices" to add or remove a device; Tap "Ungroup" to remove the speaker group. .
- Page 26 Play Music through Bluetooth You can use your CITATION BAR as a speaker for your Bluetooth enabled smartphone or tablet. 1) Press on the remote control or press (Bluetooth) on the touch screen to enter Bluetooth pairing mode. Æ During the 10 seconds of connection period, or until a successful connection, the white circle below icon will blink.
- Page 27 Talk to Voice Assistant With the Tencent Xiaowei built-in, your CITATION BAR allows you to easily play music, check weather forecasts, set reminders and get answers through voice commands. Set up Xiaowei With the HK Citation / Surround app, do one of the following: •...
- Page 28 3) To stop Xiaowei from listening, press to mute the microphone. “小微小微” Xiaowei status indicator Xiaowei status indicator: Activated Listening Responding Microphone muted NOTE: • To learn more about the services, voice commands or usage provided by Xiaowei, refer to the relevant information in the WeChat Official Account of Xiaowei.
-
Page 29: Sound Settings
SOUND SETTINGS Volume You have three ways to adjust the volume level while playing music. • Press or press and hold - / + button on the top panel. • Softly drag the volume bar on the touch panel. • Adjust the volume on your smartphone or tablet. To mute the soundbar sound, press MUTE on the remote control. -
Page 30: Settings
SETTINGS Display Brightness Press (Options) > (Brightness) to adjust the brightness of the touch screen. Software Upgrade The software of this product will be automatically upgraded to the latest version when it is connected to the Internet via a Wi- Fi network or Ethernet connection. - Page 31 Cleaning and Maintenance Clean the wool fabric occasionally. Use an approved wool shampoo and follow the instructions carefully. Many types of stain can be removed using warm water. If you act quickly, it is not difficult to remove a spill and avoid staining. Soak up the liquid with an absorbent napkin or cloth.
-
Page 32: Specifications
SPECIFICATIONS • Transducer: 3 x 20mm tweeter, 6 x (100mm x 50mm) racetrack woofer • Output power: 150W RMS • Signal-to-noise ratio: >80dB • Power Supply: 100-240V~50/60Hz • Power consumption in sleep mode: <2.0 Watts • Bluetooth® version: 4.2 • Bluetooth transmitter frequency range: 2402 – 2480MHz •... -
Page 33: Troubleshooting
TROUBLESHOOTING Sound No sound from the soundbar. • Make sure that the soundbar is not muted. • Make sure to select the correct audio input source. No sound from CITATION SUB or CITATION SURROUND. • Check if the subwoofer or the satellite speakers LED is in solid white color. - Page 34 Wi-Fi Failed to connect to Wi-Fi. • Make sure that Wi-Fi is turned on. • Make sure that you have selected the right network and entered the correct password. • Make sure that your router or modem is turned on and within the range.
-
Page 35: Trademarks
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by HARMAN International Industries, Incorporated is under license. Other trademarks and trade names are those of their respective owners.
