48 frame radial extractor with auger

Advertisement

48 Frame Radial Extractor
HH-826
Controls
Power cord
with Auger
Controls: Listed from left to right:
Extractor Power Toggle On/Off (above)
Extractor Speed Control Dial (below)
Extractor Direction Toggle (above)
Extractor Timer Dial (below)
Pump Power Toggle ON/OFF (above)
Pump Speed Control Dial (below)
Motor
Receptacle
Pump
