Wall Opening Height Reference

Recommended distance from the drive surface to the bottom of the moving bin is 32" to 40".
Actual distance is to be determined by others. Dimensions shown are for reference only.
(BD3 shown)
10 10 1/4
4 1/2
1/4
40
29 13/16
36 5/8
35 13/16
Finished Floor
6
Drive Surface
13
