Basic Drawer 3, (BD3), Dimensions

28 5/8
28 5/8
30 3/4
30 5/8
DRAWER FINISH: BLACK TEXTURED POWDER COAT WITH
STAINLESS STEEL #4 FINISH AUDIO PANELS
COUNTER TOP: ALMOND LAMINATE
(CONTACT FACTORY FOR OTHER FINISHES)
FOR DRAWER:
MINIMUM WALL OPENING: 28-3/4" WIDE X 10-1/8" TALL
MAXIMUM WALL OPENING: 30-1/2" WIDE X 13-1/2" TALL
IF THE SITE DIMENSIONS EXCEED THE RANGE OF ANY OF
THE DIMENSIONS LISTED, CONTACT THE FACTORY WHILE
STILL ON SITE FOR OTHER OPTIONS.
DIMENSIONS AND APPEARANCE ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
9 3/8
13 3/4
4 5/16
14 11/16
11
29 3/16
8 3/8
10
9 13/16
10
