Summary of Contents for Bavis Basic Manual Transaction Drawer 3
- Page 1 201 Grandin Road Maineville, Ohio 45039 (513) 677-0500 Basic Manual Transaction Drawer 3 (BD3 ) (BD3.1 Installation and Service Manual Copyright 2016 E. F. Bavis & Associates, Inc. Revised: 05/31/2016 All Right Reserved PN: 00900280...
-
Page 3: Table Of Contents
Basic Manual Transaction Drawer 2 Table of Contents Features ..........................1 Installation ...........................2 Service Information ......................3 Troubleshooting ........................3 Fig. 1 – Mounting Flange Assembly ...................4 Fig. 2 – Removing Back Panel Illustration ................5 Exploded Parts Diagram ....................6 - 9 Parts List ..........................10 Basic Drawer 3, (BD3), Dimensions .................11 Basic Drawer 3.1, (BD3.1), Dimensions ................12... -
Page 5: Features
Features The Basic Manual Transaction Drawer 3 is a reciprocating conveyor system for use in package passing applications. Burglary, theft protection and bullet resistant features have not been evaluated. The conveyor is designed to extend from the inside to the outside of a facility. -
Page 6: Installation
Installation and Service Information Installation 1. Verify that the opening dimensions are correct. 2. Install the mounting flanges onto the pre-drilled holes in the outer edges of the inside face by installing the flanges so the face with the slots is against the inside face of the drawer assembly and the edge the slot is closest to is at the top of the flange, (See Fig. -
Page 7: Troubleshooting
9. Caulk the outside perimeter to make weather tight. 10. Slide the Counter Top and Red Bin Assembly back into the drawer shell/frame, align the Counter Top and reuse the screws and holes to secure it. 11. Re-install the Back Panel and then test the Drawer and Lock operation. Servicing the Inside of the Drawer Access to the inside of the drawer is through the inside back panel. - Page 8 Fig. 1 – Mounting Flange Assembly...
- Page 9 Fig. 2 - Removing Back Panel...
-
Page 10: Exploded Parts Diagram
Inside Parts Exploded View... - Page 11 Red Bin Assembly Exploded View...
- Page 12 Customer Door Exploded View...
- Page 13 Audio Components Exploded View...
-
Page 14: Parts List
Parts List Item # Part # Description Includes Item Qty. 28022592 BD2 Teller Door Assembly 28023021 BD2 Teller Door Hinge Section 28023031 BD2 Teller Door Handle Section 28024191 BD Handle Brush Strip 12002211 Multi Opening Wire Grommet 28007023 BD3 Laminated Countertop 28027022 BD3 Mounting Angle 28012592... -
Page 15: Basic Drawer 3, (Bd3), Dimensions
Basic Drawer 3, (BD3), Dimensions 28 5/8 28 5/8 30 3/4 29 3/16 8 3/8 9 3/8 13 3/4 4 5/16 30 5/8 14 11/16 9 13/16 DRAWER FINISH: BLACK TEXTURED POWDER COAT WITH STAINLESS STEEL #4 FINISH AUDIO PANELS COUNTER TOP: ALMOND LAMINATE (CONTACT FACTORY FOR OTHER FINISHES) FOR DRAWER:... -
Page 16: Basic Drawer 3.1, (Bd3.1), Dimensions
Basic Drawer 3.1, (BD3.1), Dimensions 28 5/8 28 5/8 29 3/16 30 3/4 8 3/8 9 3/8 12 1/16 2 5/8 30 5/8 14 11/16 9 13/16 DRAWER FINISH: BLACK TEXTURED POWDER COAT WITH STAINLESS STEEL #4 FINISH AUDIO PANELS COUNTER TOP: ALMOND LAMINATE (CONTACT FACTORY FOR OTHER FINISHES) FOR DRAWER:... -
Page 17: Wall Opening Height Reference
Wall Opening Height Reference Recommended distance from the drive surface to the bottom of the moving bin is 32” to 40”. Actual distance is to be determined by others. Dimensions shown are for reference only. (BD3 shown) 10 1/4 4 1/2 29 13/16 36 5/8 35 13/16...
