C0-210 English Instruction Sheet
Carbon Monoxide Probe
Introduction
The CO-210 Carbon Monoxide Probe (hereafter referred to as
"the Probe") detects the presence of carbon monoxide (CO) and
measures concentrations between 1-1000 parts/million (PPM).
The Probe can be used in one of two ways:
•
As a stand-alone unit that indicates the presence of CO by a
flashing, light-emitting diode (LED) and a beeper.
•
As an accessory to a digital multimeter (DMM) that reads out
1 PPM as 1 mV dc. (The Probe is compatible with most
DMMs that have an input impedance of ≥ 1 MΩ.)
Contacting Fluke
To contact Fluke, call one of the following telephone numbers:
USA: 1-888-99-FLUKE (1-888-993-5853)
Canada: 1-800-36-FLUKE (1-800-363-5853)
Europe: +31 402-675-200
Japan: +81-3-3434-0181
Singapore: +65-738-5655
Anywhere in the world: +1-425-446-5500
Or, visit Fluke's Web site at: www.fluke.com.
PN 689429 (English)
December 1997, Rev 3,4/04
©1997-2004 Fluke Corporation. All rights reserved.
All product names are trademarks of their respective companies.
Page 1
®
C0-210
Instruction Sheet
Advertisement
Table of Contents
Related Manuals for Fluke C0-210
Summary of Contents for Fluke C0-210
- Page 1 1 PPM as 1 mV dc. (The Probe is compatible with most DMMs that have an input impedance of ≥ 1 MΩ.) Contacting Fluke To contact Fluke, call one of the following telephone numbers: USA: 1-888-99-FLUKE (1-888-993-5853) Canada: 1-800-36-FLUKE (1-800-363-5853)
- Page 2 The Probe then turns itself off. If after replacing the battery, the alarm condition persists, the sensor may have failed. Contact an authorized Fluke service center for information on how to replace the sensor. Arrow.com.
-
Page 3: Automatic Power-Off
C0-210 English Instruction Sheet Page 3 Establishing a Baseline Before testing for CO, establish a baseline against which the Probe compares other environments. Do this by turning on the Probe. If the Probe detects between 0-3 PPM of CO, the beeper sounds, the LED flashes once a second, and the Probe establishes a new baseline. - Page 4 10A MAX 1000V MAX FUSED QA001F.EPS Light-Emitting Diode (LED) ON/OFF Button Sensor (Fluke PN 689497) RJ45 Connector Cable with RJ45 Connector and Plug (Fluke PN 689307) DMM Connections and Settings Fluke CO-210 Carbon Monoxide Probe Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from...
-
Page 5: Installing And Replacing The Battery
C0-210 English Instruction Sheet Page 5 Installing and Replacing the Battery QA002F.EPS Screw Battery Door Battery, 9 V NEDA or IEC 6LR61, or equivalent RJ45 Jack Battery Connector Sensor Common Sources of CO Common sources of potentially dangerous levels of CO are: •... - Page 6 C0-210 English Instruction Sheet Page 6 CO and Appliance Malfunctions The following table identifies typical problems that can produce high levels of CO. Appliance Fuel Typical Problems 1. Cracked heat exchanger. Gas furnaces Oil, natural 2. Not enough air to burn fuel...
-
Page 7: Specifications
C0-210 English Instruction Sheet Page 7 Specifications Temperature Operating: C to +50 Storage: C to +50 Humidity (non-condensing) < 3 weeks 0-99 % RH > 3 weeks 0-90 % RH Measurement range 0 to 1000 PPM Measurement 1 PPM for 0 - 200 PPM;... - Page 8 Fluke service center. LIMITED WARRANTY & LIMITATION OF LIABILITY This Fluke product will be free from defects in material and workmanship for one year from the date of purchase. This warranty does not cover fuses, disposable batteries or damage from accident, neglect, misuse or abnormal conditions of operation or handling.
