- Page 1 CableIQ Qualification Tester Getting Started Guide PN 2113427 January 2005, Rev. 3 9/2018 © 2005, 2007, 2015, 2018 Fluke Corporation All product names are trademarks of their respective companies. 1.888.610.7664 www.calcert.com sales@calcert.com...
- Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY Fluke Networks mainframe products will be free from defects in material and workmanship for one year from the date of purchase, unless stated otherwise herein. The CableIQ wiremap adapter is also warranted for one year. Parts, accessories, product repairs and services are warranted for 90 days, unless otherwise stated.
- Page 3 Qualification Tester Accessing the Users Manual This guide provides basic information to help you quickly get started using the tester. The CableIQ Qualification Tester Users Manual on the Fluke Networks website provides additional information. WSafety Warning To avoid possible fire, electric shock, or personal injury: •...
-
Page 4: Setting User Preferences
CableIQ Getting Started Guide Setting User Preferences Turn the rotary switch to SETUP; then use to select a setting. • User Information: Three lines of text are stored with saved Autotests. • Language / ftm: Select a language for the display. -
Page 5: Connecting For Cabling Tests
If you use patch cords at the near or far end during an Autotest, Fluke Networks recommends patch cords at least 2 m long. Connecting to a Data Link... - Page 6 CableIQ Getting Started Guide Connecting to a Star Topology AXY12 Connecting to Coaxial Cabling AXY34 1.888.610.7664 www.calcert.com sales@calcert.com...
- Page 7 Results Icons Results Icons The icons below appear on Autotest and Discover screens. The cabling qualifies for the application. The cabling does not qualify for the application. Results are for informational purposes only, not for qualification. The cabling cannot be completely qualified for the application because the wiremap results are incomplete (wiremap adapter not...
-
Page 8: Discovering Cabling Characteristics
CableIQ Getting Started Guide Discovering Cabling Characteristics Discover mode lets you quickly check wiremaps, measure length, and determine if cabling is connected to a network port, video device, or telephone. Turn the rotary switch to DISCOVER, then connect to twisted pair or 75 coaxial cabling with or without a wiremap adapter at the far end. - Page 9 Discovering Cabling Characteristics Discover Mode on a Port AXY48 Discover Mode on Coaxial Cabling with Adapter AXY50 Discover Mode on Coaxial Cabling Connected to a Device AXY35 1.888.610.7664 www.calcert.com sales@calcert.com...
-
Page 10: Qualifying Cabling With The Autotest
CableIQ Getting Started Guide Discover Mode with MultiMap Verifies wiremaps of multiple telephone outlets connected in a star or bus topology. AXY07 Qualifying Cabling with the Autotest The Autotest tells you if cabling will support a selected application. You can save Autotest results to document an installation. -
Page 11: Using The Toner
Using the Toner Turn the rotary switch to TONE; then select a tone function. The two IntelliTone functions work with a ™ Fluke Networks IntelliTone probe. The other four analog tones can be detected by most tone probes. AXY06 1.888.610.7664 www.calcert.com... -
Page 12: Blinking A Port Light
CableIQ Getting Started Guide Blinking a Port Light The Blink Port Light function helps you determine which cable is connected to which port on a network hub or switch. The tester’s analog toner is also active when the port light function is active. Turn the rotary switch to DIAG;... -
Page 13: Testing For Continuity
Testing for Continuity Testing for Continuity The continuity function lets you test for opens and shorts on the 8-pin modular jack or the coaxial connector. Turn the rotary switch to DIAG. Use to highlight Continuity; then press , or The tester’s beeper is silent for resistances above about 5000 . -
Page 14: Using The Continuity Toner
CableIQ Getting Started Guide Using the Continuity Toner Turn the rotary switch to DIAG; then select Continuity. The beeper’s tone and rhythm increase as resistance decrease. AXY38 Locating Crosstalk and Impedance Faults The Find Crosstalk Fault and Find Impedance Fault functions let you quickly check cable pairs for crosstalk and impedance faults on twisted pair cabling. -
Page 15: Testing Speaker Cabling
Testing Speaker Cabling Testing Speaker Cabling The Speaker Test generates audible tones for testing the wiring and phase of installed twisted pair speaker cabling. Turn the rotary switch to Diag; then select Speaker Test. AXY39 4-clip test lead wiring: Pair 12: green Pair 45: blue Pair 36: orange Pair 78: brown... -
Page 16: Replacing The Batteries
Remove the yellow boot to access battery door. 4 AA batteries (alkaline recommended) 20 hours typical battery life. AXY53 Contacting Fluke Networks Fluke Networks operates in more than 50 countries worldwide. For more contact information, visit our website. 1.888.610.7664 www.calcert.com sales@calcert.com...
