Instruction Manual
ICAO Taxiway Centerline Light (TCL)
ICAO Intermediate Hold Position Light (IHP)
ICAO ANNEX 14, Third Edition, Figure A2-12 Through A2-16
Copyright © 2019 Cooper Technologies Company
For Parts or Technical Service Call (860) 683-4300
PRO APF Series LED
ICAO Stop Bar Light (STP)
IEC/TS 61827: 2004
