- Page 1 HISTORY INFORMATION FOR THE FOLLOWING MANUAL: SERVICE MANUAL GN3FK CHASSIS ORIGINAL MANUAL ISSUE DATE: 2017/6/27 Segment: KCL Version Date Subject 2017/6/27 First version issue. LCD Digital Color TV 9-888-740-01...
- Page 2 MODEL LIST MODEL COLOR COMMANDER DEST. MODEL COLOR COMMANDER DEST. KD-60X690E Black RMT-TX300U UC2/LA1 KD-70X690E Black RMT-TX300U UC2/LA1 KD-60X695E Black RMT-TX300B AR4/LA8 KD-60X697E Black RMT-TX300B KD-60X6700E Black RMT-TX300E/300P AZ1/ME6/EA4 KD-70X6700E Black RMT-TX300E/300P AZ1/ME6/EA4 KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 3 Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that are critical for safe operation are identified in this manual.
- Page 4 Use care when handling the wires or connectors of the inverter circuit. Damaging the wires may cause a short. Protect the panel from ESD to avoid damaging the electronic circuit (C-MOS). 10) It is recommended not to exceed 1 hour of Power-On nor Burn-in period with LCD panel face down condition, in repair activity. KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 5 6. Check the line cords for cracks and abrasion. Recommend the replacement of any such line cord to the customer. 7. Check the antenna terminals, metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. 8. For safety reasons, repairing the Power board and/or Inverter board is prohibited. KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 6 If a cold-water pipe is not accessible, connect a 60- to 100-watt trouble- light (not a neon lamp) between the hot side of the receptacle and the retaining screw. Try both slots, if necessary, to locate the hot side on the line; the lamp should light at normal brilliance if the screw is at ground potential (see Figure B). KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 7 Detect and observe for Panel_12V PANEL_I2C_ERR Detect Panel I2C Communication access error BACKLIGHT Detect and observe backlight error LED_I2C LED Driver communication error BE_I2C (Only record error BE device I2C communication error detection. log) PMIC_I2C (Only record error PMIC communication error log) KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 8 Press the Channel 7 => Channel 0 . Exiting the Self-diagnostic screen To exit the Self Diagnostic screen, turn off the power to the TV by pressing the POWER button on the remote or the POWER button on the TV. KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 9 • The construction parts of an assembled part are indicated with a collation number in the remark colum. • Items marked " * " are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 10 1-2. KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E DISASSEMBLY AND PARTS LIST 1-2-1. STAND BLOCK REF.NO. PART No. DESCRIPTION MARK 4-723-281-01 STAND, NECK 4-723-280-01 STAND, COVER 4-723-282-01 STAND, BRACKET L 4-723-283-01 STAND, BRACKET R 4-723-284-01 STAND, BRACKET FRONT 4-723-296-01 SCREW, +PSW M5X12 7-682-961-09 SCREW, +PSW M4x8 W8 4-729-979-01 SCREW,F,CROSS,T.T-3*6,BLK-ZN.
- Page 11 1-2. KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E DISASSEMBLY AND PARTS LIST 1-2-3. AC COVER AND REAR COVER REF.NO. PART No. DESCRIPTION MARK 4-725-317-01 COVER, AC 1-912-305-11 AC Cord(USA 2pin) For UC2/LA1/CO1 1-912-304-11 AC Cord(Argentina 2pin) For AR4 1-912-303-11 AC Cord(Europe 2pin) For LA8/ME6 1-912-301-11 AC Cord(UK 3pin)
- Page 12 1-2. KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E DISASSEMBLY AND PARTS LIST REF.NO. PART No. DESCRIPTION MARK 1-2-4. OVERALL 1-522-035-11 ANTENNA 1 (W) 1-522-033-11 ANTENNA 2 (B) 1-897-219-11 MOUNTED PWB POWER UNIT 1-897-214-11 MOUNTED PWB A For UC2 1-897-209-11 MOUNTED PWB A For LA8 1-897-217-11 MOUNTED PWB A...
- Page 13 1-2. KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E DISASSEMBLY AND PARTS LIST 1-2-5. TUNER MODULE REF.NO. PART No. DESCRIPTION MARK 8-594-302-70 TUNER MODULE SUT-RA243ZP For UC2/LA1 8-594-308-30 TUNER MODULE SUT-RT243ZP For LA8/AR4 8-594-325-00 TUNER MODULE SUT-DB251ZP For CO1 8-594-328-10 TUNER MODULE SUT-DE251ZP For AZ1/EA4/ME6 A BOARD...
- Page 14 1-2. KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E DISASSEMBLY AND PARTS LIST 1-2-6. LCM REF.NO. PART No. DESCRIPTION MARK 1-812-368-11 LCM ASSY (60) (S600DUC-1) 4-724-143-01 BEZEL, FRONT 4-729-983-01 FC BTM BRACKET (60) 4-729-985-01 Double Side Tape 4-729-980-01 SCREW,A,M2.5,L5 4-729-981-01 SCREW(B)/M2.5*L10 1-2-7. LCM (W/O BEZEL) KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 15 1-2. KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E DISASSEMBLY AND PARTS LIST 1-2-8. PACKAGE REF.NO. PART No. DESCRIPTION MARK 4-723-288-01 CUSHION, UPPER（60） 4-723-289-01 CUSHION, LOWER (60) 4-723-290-01 CUSHION, SIDE L (60) 4-723-291-01 CUSHION, SIDE R (60) 4-723-292-01 PLATE, EPE FRONT (60) 4-723-547-01 CARTON, INDIVIDUAL (UC2) For UC2...
- Page 16 1-2. KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E DISASSEMBLY AND PARTS LIST 1-2-9. OTHER PART PART No. DESCRIPTION MARK 1-493-312-11 REMOTE COMMANDER (RMT-TX300U) For UC2/LA1 1-493-313-11 REMOTE COMMANDER (RMT-TX300B) For AR4/CO1/LA8 1-493-314-11 REMOTE COMMANDER (RMT-TX300E)-AZ1 For AZ1 For ME6/EA4 1-493-315-11 REMOTE COMMANDER (RMT-TX300P)-ME6/EA4 1-853-643-21 CARBON ZINC DRY BATTERY(R03)
- Page 17 1-3. KD-70X690E/KD-70X6700E DISASSEMBLY AND PARTS LIST 1-3-1. STAND BLOCK REF.NO. PART No. DESCRIPTION MARK 4-723-281-01 STAND, NECK 4-723-280-01 STAND, COVER 4-723-282-01 STAND, BRACKET L 4-723-283-01 STAND, BRACKET R 4-723-284-01 STAND, BRACKET FRONT 4-723-296-01 SCREW, +PSW M5X12 7-682-961-09 SCREW, +PSW M4x8 W8 4-729-979-01 SCREW,F,CROSS,T.T-3*6,BLK-ZN.
- Page 18 1-3. KD-70X690E/KD-70X6700E DISASSEMBLY AND PARTS LIST 1-3-3. AC COVER AND REAR COVER REF.NO. PART No. DESCRIPTION MARK 4-725-317-01 COVER AC 1-912-305-11 AC Cord(USA 2pin) For UC2/LA1 1-912-303-11 AC Cord(Europe 2pin) For ME6 1-912-301-11 AC Cord(UK 3pin) For EA4 1-912-302-11 AC Cord(AUS/NZ 2pin) For AZ1 4-723-306-01 COVER, REAR (UC2)
- Page 19 1-3. KD-70X690E/KD-70X6700E DISASSEMBLY AND PARTS LIST 1-3-4. OVERALL REF.NO. PART No. DESCRIPTION MARK 1-522-034-11 ANTENNA 1 (W) 1-522-032-11 ANTENNA 2 (B) 1-897-216-11 MOUNTED PWB POWER UNIT 1-897-215-11 MOUNTED PWB A For UC2 1-897-206-11 MOUNTED PWB A For ZA1/EA4/ME6 1-897-218-11 MOUNTED PWB A For LA1 1-897-212-11 MOUNTED PWB H 1-897-213-11 MOUNTED PWB KEY...
- Page 20 1-3. KD-70X690E/KD-70X6700E DISASSEMBLY AND PARTS LIST 1-3-5. TUNER MODULE REF.NO. PART No. DESCRIPTION MARK 8-594-302-70 TUNER MODULE SUT-RA243ZP For UC2/LA1 8-594-328-10 TUNER MODULE SUT-DE251ZP For AZ1/EA4/ME6 A BOARD For UC2/LA1 For AZ1/EA4/ME6 KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 21 1-3. KD-70X690E/KD-70X6700E DISASSEMBLY AND PARTS LIST 1-3-6. LCM REF.NO. PART No. DESCRIPTION MARK 1-812-369-11 LCM ASSY (70) (S700DUC-1) 4-724-144-01 BEZEL, FRONT 4-729-984-01 FC BTM BRACKET (70) 4-729-980-01 SCREW,A,M2.5,L5 4-729-981-01 SCREW(B)/M2.5*L10 1-3-7. LCM (W/O BEZEL) KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 22 1-3. KD-70X690E/KD-70X6700E DISASSEMBLY AND PARTS LIST 1-3-8. PACKAGE REF.NO. PART No. DESCRIPTION MARK 4-723-314-01 CUSHION, UPPER CENTER 4-723-313-01 CUSHION, UPPER 4-723-315-01 CUSHION, LOWER 4-723-316-01 CUSHION, LOWER CENTER 4-723-317-01 CUSHION, SIDE L 4-723-318-01 CUSHION, SIDE R 4-723-319-01 PLATE, EPE FRONT (70) For UC2 4-723-546-01 CARTON, INDIVIDUAL (UC2) 4-723-548-01 CARTON, INDIVIDUAL (LA1)
- Page 23 1-3. KD-70X690E/KD-70X6700E 1-3-8. PACKAGE REF.NO. PART No. DESCRIPTION MARK CUSHION, EPS BAR 4-729-988-01 (150MMX25MMX11MM) CUSHION, EPS BLOCK 4-729-989-01 (120MMX120MMX30MM) KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 24 1-3. KD-70X690E/KD-70X6700E DISASSEMBLY AND PARTS LIST 1-3-9. OTHER PART PART No. DESCRIPTION MARK 1-493-312-11 REMOTE COMMANDER (RMT-TX300U) For UC2/LA1 1-493-314-11 REMOTE COMMANDER (RMT-TX300E)-AZ1 For AZ1 1-493-315-11 REMOTE COMMANDER (RMT-TX300P)-ME6/EA4 For ME6/EA4 1-853-643-21 CARBON ZINC DRY BATTERY(R03) KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 25 1-4 DISASSEMBLY OF REAR COVER AND SERVICE POSITION DISASSEMBLY AND PARTS LIST 1-4-1. KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E 1. LAY DOWN THE SET IN A FLAT TABLE Make sure no mess things under the front set. KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 26 DISASSEMBLY AND PARTS LIST 2. UNLOCK SCREWS SCREW, +PSW M3X8 W8 18PCS SCREW,ORNAMENTAL M6X12 5PCS SCREW, +BVTP 3X8 TYPE2 IT-3 4PCS KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 27 DISASSEMBLY AND PARTS LIST 3. REMOVE THE REAR COVER Insert the AC cord thought the rear cover hole. Take off the AC cover first Take off the SP connector Lift up the rear cover from the bottom KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 28 DISASSEMBLY AND PARTS LIST 4. SET UP THE SET KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 29 HOOK POSITION DISASSEMBLY AND PARTS LIST KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E Rear Cover KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 30 HOOK POSITION DISASSEMBLY AND PARTS LIST KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 31 1-4 DISASSEMBLY OF REAR COVER AND SERVICE POSITION DISASSEMBLY AND PARTS LIST 1-4-2. KD-70X690E/KD-70X6700E 1. LAY DOWN THE SET IN A FLAT TABLE Make sure no mess things under the front set. KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 32 DISASSEMBLY AND PARTS LIST 2. UNLOCK SCREWS SCREW, +PSW M3X8 W8 21PCS SCREW,ORNAMENTAL M6X12 5PCS SCREW, +BVTP 3X8 TYPE2 IT-3 4PCS KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 33 DISASSEMBLY AND PARTS LIST 3. REMOVE THE REAR COVER Insert the AC cord thought the rear cover hole. Take off the AC cover first Take off the SP connector Lift up the rear cover from the bottom KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 34 DISASSEMBLY AND PARTS LIST 4. SET UP THE SET KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 35 HOOK POSITION DISASSEMBLY AND PARTS LIST KD-70X690E/KD-70X6700E KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 36 HOOK POSITION DISASSEMBLY AND PARTS LIST KD-70X690E/KD-70X6700E KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 37 1-5 DISASSEMBLY OF LCM AND SERVICE POSITION DISASSEMBLY AND PARTS LIST 1-5-1. KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E 1. REMOVE THE STAND Lay down the set. Unlock stand screws. Make sure no mess things under the front set. SCREW, +PSW M5X12 4PCS Unlock bottom bracket screws and take off...
- Page 38 DISASSEMBLY AND PARTS LIST 2. REMOVE THE ORNAMENT PANEL. Take off the ornament panel. Take off the IR board. Peel off bottom Aluminum tape. 20*50mm 6PCS 30*160mm 2PCS Remark: Aluminum tape can not reuse. KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 39 DISASSEMBLY AND PARTS LIST 3. TURN THE SET. Cushion can’t touch this area, the height of cushion must more than 35mm.. KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 40 DISASSEMBLY AND PARTS LIST 4. UNLOCK THE SCREWS. SCREW SILVER/M2.5 x 6 Ni/C1018 19PCS SCREW SILVER/M2.5*L10 Ni/C1018 5PCS KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 41 DISASSEMBLY AND PARTS LIST 5. REMOVE THE BEZEL Take off Bezel top side firstly. KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 42 DISASSEMBLY AND PARTS LIST 6. REMOVE THE CORE TAPE Please replace this photos , it too shinny, SHEET CORE TAPE (E60) 3PCS KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 43 DISASSEMBLY AND PARTS LIST 7. UNLOCK SCREWS AND TAKE OFF FC BOTTOM BRACKET. Unlock screws. SCREW SILVER/M2.5*L10 Ni/C1018 3PCS Take off FC bottom bracket. Remark: FC Bottom Bracket can not reuse. KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 44 TAPE LAYOUT DISASSEMBLY AND PARTS LIST KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E PART No. DESCRIPTION MARK 20*50mm 6PCS Aluminum tape. Can not reuse 60*15mm 20PCS TAPE (3M 1350FB-1)15MMX66M BLK Can not reuse Aluminum tape. Can not reuse 30*160mm 2PCS KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 45 CUSHION ON REAR COVER DISASSEMBLY AND PARTS LIST KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E NWF 20*8*0.35mm 8 PCS NWF 30*8*0.35mm 2 PCS NWF 60*8*0.35mm 1 PCS KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 46 1-5 DISASSEMBLY OF LCM AND SERVICE POSITION DISASSEMBLY AND PARTS LIST 1-5-2. KDKD-70X690E/KD-70X6700E 1. REMOVE THE STAND Lay down the set. Unlock stand screws. Make sure no mess things under the front set. SCREW, +PSW M5X12 4PCS Unlock bottom bracket screws and take off Take off the stand SCREW, +PSW M3X8 12PCS...
- Page 47 DISASSEMBLY AND PARTS LIST 2. REMOVE THE ORNAMENT PANEL. Take off the ornament panel. Take off the IR board. Peel off bottom Aluminum tape. 20*50mm 5PCS 30*160mm 2PCS Remark: Aluminum tape can not reuse. 30*90mm 2PCS KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 48 DISASSEMBLY AND PARTS LIST 3. TURN THE SET. Cushion can’t touch this area, the height of cushion must more than 35mm.. KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 49 DISASSEMBLY AND PARTS LIST 4. UNLOCK THE SCREWS. SCREW SILVER/M2.5 x 6 Ni/C1018 21PCS SCREW SILVER/M2.5*L10 Ni/C1018 3PCS KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 50 DISASSEMBLY AND PARTS LIST 5. REMOVE THE BEZEL Take off Bezel top side firstly. KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 51 DISASSEMBLY AND PARTS LIST 6. REMOVE THE CORE TAPE Please replace this photos , it too shinny, SHEET CORE TAPE (E60) 6PCS KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 52 DISASSEMBLY AND PARTS LIST 7. UNLOCK SCREWS AND TAKE OFF FC BOTTOM BRACKET. Unlock screws. SCREW SILVER/M2.5*L10 Ni/C1018 3PCS Take off FC bottom bracket. KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 53 TAPE LAYOUT DISASSEMBLY AND PARTS LIST KD-70X690E/KD-70X6700E PART No. DESCRIPTION MARK Aluminum tape. Can not reuse 20*50mm 5PCS TAPE (3M 1350FB-1)15MMX66M BLK Can not reuse 60*15mm 23PCS Aluminum tape. Can not reuse 30*160mm 2PCS Aluminum tape. Can not reuse 30*90mm 2PCS KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 54 CUSHION ON REAR COVER DISASSEMBLY AND PARTS LIST KD-70X690E/KD-70X6700E NWF 115*8*0.15mm 4 PCS NWF 60*8*0.35mm 1 PCS KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 55 Left Right Mute Enter Mute Volume “+” 3) Service mode display. When replace Main Board or panel, please confirm " SERIAL NUMBER EDIT " and "Model Number Setting" in service menu, and set to the correct name according to your info. KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 56 ADJUSTMENT STATUS INFORMATION *Below information is just for example, and may not match the actual info you see on consumer’s TV set. Press “Return” key or “Home” key on RC to exit the Status Information screen. KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 57 Service mode off <Return> / <Menu> set type. If they are different, please adjust to the correct one. Adjustment Item up / down Data Value up / down 3. Software upgrade guide, please refer to “APPENDIX-2”. KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 58 MURA data transfer <[ 1.T-con To SoC ]> ※1. Select the Value 1 for each WB/MURA/CUC, then enter "Start" to execute data transfer. CUC data transfer <[ 1.T-con To SoC ]> 2. Waiting 5 seconds. 3. AC Off/On [Start] KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 59 SEC 3. DIAGRAMS AND CHASSIS STRUCTURE 3-1. BLOCK DIAGRAM VGA(Step up only) KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 60 DIAGRAMS AND CHASSIS STRUCTURE 3-2. CONNECTOR DIAGRAM KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 61 DIAGRAMS AND CHASSIS STRUCTURE 3-3. CIRCUIT BOARDS LOCATION KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E A Board SWITCH UNIT Board H Board WIFI KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
- Page 62 DIAGRAMS AND CHASSIS STRUCTURE 3-3. CIRCUIT BOARDS LOCATION KD-70X690E/KD-70X6700E A Board SWITCH UNIT WIFI Board H Board KD-70X690E(UC2/LA1)/KD-70X6700E(AZ1/ME6/EA4)
- Page 63 9-888-740-01 Sony Corporation KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 64 1-1. NO POWER No power Long AC off(> 15 min.) and then Power On Check 5VSB Change at 1 pin of TP209 on the Main board Check PSU_12V at 12 pin Change of TP220 on the Main board Change Main board KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 65 Fix the harness Fix the FFC(LVDS) Harness issue FFC(LVDS) issue Main board issue connection connection Change Equipment No display Change Or Player to check Main board TV display Change Change PSU Panel Signal or Equipment Symptom Problem improvement Adaptor issue KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 66 Check if TV is Change to set to Mute Un-mute “Audio System” Check the Change to “Speakers setting” “TV Speaker” “TV Speakers” Symptom improvement Change the speaker Replace Main board issue harness Main board Symptom improvement Speaker Harness Change issue Speaker KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 67 TROUBLE SHOOTING 1-4. TV COMMANDER BUTTONS MALFUNCTION 1) TV button malfunction Button malfunction on the TV Symptom Replace the harness improvement Change between Main board Key module issue Key module and Key module Symptom improvement Change Harness issue Main board KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 68 Green LED blinks at power indicator Green LED light when using commander Remote Control at power indicator near sensor’s window battery Symptom improvement Change Main board to IR FFC IR board FFC issue Symptom improvement Change IR board IR board issue Change Main board KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
- Page 69 Store the software package to USB memory. (Applicable USB memory : Format by FAT32, USB2.0 type ) However, please store ONLY ONE PKG file to USB Root folder for software update. Model Name Software PKG file name format: sony_fw_2017_1000_UUUSB.pkg 1.KD-60X690E/KD-70X690E(UC2/LA1):UUUSB 2. KD-670X6700E/KD-70X6700E(AZ1/EA4/ME6)：UUPAB 3. KD-60X695E(LA8)：UUCPB version model Name 4.
- Page 70 USB device. 5. When upgrade complete, TV will turn on and LED will be green. ***Please remember to remove USB after upgrade finish. KD-60X690E/KD-70X690E 6. After software update, you will need to do Initial Setup again, so please Model Name follow the steps to confirm the settings.
- Page 71 Panel operation time by hour Just move the cursor to “Test Reset” and then press Right key , Boot count the “Off” will change to “On”, then TV will reboot and you will Total operation time by hour need to perform Initial Setup. KD-60X690E/KD-70X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E/KD-70X6700E(AZ1/ME6/EA4)
