Package - Sony KD-60X690E Service Manual

1-2. KD-60X690E/KD-60X695E/KD-60X697E/KD-60X6700E

1-2-8. PACKAGE

40
KD-60X690E(UC2/LA1)/KD-60X695E(AR4/LA8)/KD-60X697E(CO1)/KD-60X6700E(AZ1/ME6/EA4)
38
41
39
42
REF.NO. PART No.
38 4-723-288-01 CUSHION, UPPER（60）
39 4-723-289-01 CUSHION, LOWER (60)
40 4-723-290-01 CUSHION, SIDE L (60)
41 4-723-291-01 CUSHION, SIDE R (60)
42 4-723-292-01 PLATE, EPE FRONT (60)
43 4-723-547-01 CARTON, INDIVIDUAL (UC2)
4-723-549-01
4-723-551-01 CARTON, INDIVIDUAL (AZ1/ME6/EA4)
44 3-674-673-22 STOPPER (A)
45 4-723-285-01 BAG, STAND
46 4-723-293-01 CARTON STAND SUPPORT (60MB)
47 4-409-919-33 BAG,PROTECTION PEHD(1720*1050)
48 4-729-987-01
49 4-729-990-01 CARTON TRAY (60)
49
47
48
43
44
46
45
DISASSEMBLY AND PARTS LIST
DESCRIPTION
CARTON, INDIVIDUAL
(LA1/LA8/CO1/AR4)
SHEET, PROTECTION PE
(L180xW260xT1.01mm)
MARK
For UC2
ForLA1/LA8/CO1/A
R4
For AZ1/ME6/EA4
ASSESSORY BAG
15
