Travis Industries 6015 HO GSR2 Cheat Sheet

The 6015 HO GSR2 has several new features and characteristics that require special attention during installation and set-up.
This unit uses the new GreenSmart 2 system. Refer to the owner's manual for full details.

REMOVE THE SCREEN BEFORE YOU REMOVE THE GLASS FRAME

This fireplace uses a newly designed screen barrier. Make sure to remove the barrier prior to removing the glass frame.
1. Remove the concealment cover and place aside. It has two holes that aid in removal.
2. Lift up on the barrier screen assembly until the top brackets are clear of the tabs on the glass frame assembly. Direct the
top edge of the barrier screen forward. Lift the bottom tabs out of the brackets on the bottom of the glass frame assembly
and remove the barrier screen from the fireplace.

This Fireplace Requires Firebacks

96100981 Stainless Steel
96100982 Black Enamel

If using LP (Propane)

A conversion kit is required if using propane with this heater (sku 94400999 – GSR Stepper Motor Kit).

No Drill or Screw Zone

Controls for this fireplace are directly in front. Do not drill or screw into this area (see manual for details).

Battery Box Heat Shield

Travis Industries recently updated the 6015 to include a
heat shield over the top of the battery box. Make sure to
replace this heat shield after installing the batteries. The
heat shield must be in place whenever the fireplace is in
operation.
NOTE: The heat shield is shipped in place. It is held in
place with a lock-tie. Remove and discard this lock-tie to
allow the heat shield to be removed and the batteries
installed.
Page 1 of 2
6015 HO GSR2 Cheat Sheet
96100983 Black Painted
96100984 Ledgestone
Heat Shield
Battery Box
17601829
Lock-Tie
FUSE
FUSE
Printed 7/22/20
