Bellcome Touch Line VPA.1FR03.BLB04 User Manual page 7

4
Connection diagrams for 1 – 5 Families
Outdoor Panel
+14
C/D
GND
Vout1
OUTDOOR
Outdoor Panel
+14
C/D
GND
Vout1
OUTDOOR
Note: Any type of TL terminal can be mounted indoors.
For Fam. 1, the terminal has address 1, which is set by the producer.
The additional terminals mounted in parallel will have the address of the main terminal.
For Fam. 2, the terminal will be programmed with address 2.
See the manual of the TL audio-video terminals.
LOCK
+14
SCU.VDR03.BLG14
OTHER VIDEO AUX1
INDOOR
Vcam
AUX1
AUX2
LOCK
VIDEO DOOR PANEL
+14
SCU.VDR03.BLG34
OTHER VIDEO AUX1
INDOOR
Vcam
AUX1
AUX2
LOCK
SUPPLY
EXIT
-
-
AUX2 BAT OUT1 OUT2 OUT3
+ -
BAT
max.12Ah/12V
LOCK
SUPPLY
EXIT
-
-
AUX2 BAT OUT1 OUT3
OUT2
+ -
BAT
max.12Ah/12V
GROUNDED OUTLET
Fam. 1
(Address 1)
+14
C/D
GND
Vin
Doorbell
GONG
GROUNDED OUTLET
Fam. 2
(Address 2)
+14
C/D
GND
Vin
Doorbell GONG
Fam. 1
(Address 1)
+14
C/D
GND
Vin
Doorbell
GONG
1 Family
110/230Va.c.
50/60Hz
EN
6
2 Families
110/230Va.c.
50/60Hz
