- Page 1 advanced 1 Fam. advanced 2 Fam. USER MANUAL Video outdoor panels 1 – 5 Families 4 WIRE door system advanced 3 Fam. advanced 5 Fam.
- Page 2 Contents Connection of additional panels Safety instructions Description of the Touch Line video panels Connection of additional video cameras Recommended cables. Programming and deleting the RFID cards Installation of the Touch Line video panels. Maintenance Connection diagrams for 1 – 5 Families Declaration of conformity.
- Page 3 Fastening Torx screw Microphone LEDs (day and night white lighting) Orientable video camera LEDs signaling status during use Fam 5 Fam 4 Touch key with the name Fam 1 Fam 3 of the family Fam 2 Fam 1 Presence sensors RFID reader Speaker Fastening Torx screw...
- Page 4 UTP Cable Installation For distances between 150 ml and 250 ml it is mandatory to use the twisted pair cable type UTP/ FTP cat5e (AWG24) or UTP/ FTP cat6 (AWG23). 20-25mm 20-25mm Panel Vout Mounting on the wall - Flush 50mm ≈20 cm Mounting on the wall - Surface...
- Page 5 Unmount the module and add name labels Mount back the family name module. Orientation of the video camera 175 cm 175 cm 175 cm 130 cm 130 cm 130 cm 115 cm 115 cm 115 cm...
- Page 6 Electrical connections in the panel Mounting the outdoor panel on the wall Surface Flush Torx Torx Torx Important: For both types of mounting, the Torx screws for fastening the outdoor panels on the wall will be very well tightened, to prevent the anti-theft alarm sensor from setting off.
- Page 7 Connection diagrams for 1 – 5 Families 1 Family LOCK Outdoor Panel SUPPLY LOCK GROUNDED OUTLET EXIT 110/230Va.c. 50/60Hz Vout1 SCU.VDR03.BLG14 OTHER VIDEO AUX1 AUX2 OUT1 OUT2 OUT3 Fam. 1 (Address 1) OUTDOOR INDOOR Vcam AUX1 max.12Ah/12V AUX2 Doorbell GONG 2 Families LOCK SUPPLY...
- Page 8 3 Families...
- Page 9 5 Families...
- Page 10 Connection of additional panels Important: One VPA video panel and one SCU central unit will be mounted at each entrance. To one or more families 110Va.c. 110Va.c. 110Va.c. 110Va.c. 230Va.c. 230Va.c. 230Va.c. 230Va.c. SCU1 SCU2 SCU3 SCU4 PROG PROG PROG PROG SCU.VDR03.BLG34 SCU.VDR03.BLG34...
- Page 11 Connection of additional cameras Video selection Outdoor Panel PROG SCU.VDR03.BLG34 Vout OUT1 Programming and deleting the RFID cards Manual programming of the RFID cards When delivered from the factory, the Touch Line video panels do not have access cards memorized. In order to have access in the building after installation, it is mandatory to program the RFID cards in the video panel as follows: The entire video door phone system is installed and set under tension.
- Page 12 Maintenance The Touch Line outdoor panels must be kept away from corrosive substances, lime and blows. For cleaning the glass screens, use a clean cloth and a solution for glass washing. In case of renovation activities, the Touch Line video door system components must be completely protected with plastic foil. DO NOT undo the electrical connections of the Touch Line video door system components.
- Page 16 BELLCOME is a trademark of ELECTRA Group - No. 013502646 - EUIPO - Alicante, Spain BELLCOME/ELECTRA products are registered as Industrial Models - EUIPO - Alicante, Spain The products are The products contain UL-compliant The products are manufactured under CE certified.
