2. GENERAL DEFINITIONS

2.1.Identifying Sets

Generator sets and its main pieces (engine, alternator) do have nameplates
on them for easing the identification process for the user.
A brief information about the generator set (model codes, serial numbers,
etc...) can be found on these identification nameplates.
An example of "generator set nameplate" can be seen in the picture on the
right.
The customer / user has to provide the supplier the "serial number" of the
subjected generator set while requesting any spare parts or while applying
for a warranty case about that generator set.

2.2.Generator Set

TEKSAN produces reliable generator sets at high quality in accordance with
ISO8528 standards. Generator set specifications, options, electrical and
mechanical drawings are all recorded and followed under the unique serial
number of the generator set.
Main components of the generator set are shown in the figure below.
1 Lifting Lug
2 Jacket Water Heater
3 Fuel Tank
4 Starter Motor
5 Batteries
6 Vibration Isolators
Figure: Main components of a diesel generator set.
BBK-V.122018_ENG
6 Earthing point
7 Lifting Lug
8 Connection Box
9 Control Panel
10 Alternator
11 Air Filter
15
12 Turbocharger
13 Engine
14 Exhaust Outlet
15 Radiator Cap
16 Radiator
17 Baseframe
