Summary of Contents for TEKSAN GO ON 600W
- Page 1 Portable Power Station User Manual...
- Page 3 Dear Customer Thank you for choosing Teksan GO ON 600W Portable Power Station.We want your product, manufactured with high quality and technology,to offer you the best efficiency. Therefore, please read this manual and the other documents provided carefully before using the product and keep them as a reference.
-
Page 5: Table Of Contents
8. Discharge ..................15 9. Specifications ................16 10. Important Notes ................ 17 10. Terms of Warranty ............... 18-22 11. Contact Us ................23-24 TEKSAN JENERATÖR ELEKTRİK SANAYİ VE TİCARET A.Ş. Yenidoğan Mah. Edebali Cad. No:12 34791 Sancaktepe / İSTANBUL... -
Page 6: Before You Start
1. Before You Start 1. Please completely read the user manual before using this product. TEKSAN will not be liable for any damage to products, personal property, or serious personal injury due to misuse. 2. Do not use incompatible components or replace components in anyway without following the instructions provided with TEKSAN spare part. - Page 7 7. Ensure that servicing is carried out by qualified repair after sales staff using only original TEKSAN spare parts this will ensure that the safety of the product is maintained. 8. Turn off the product when not in use.
-
Page 8: What Is In The Box
3. What is in the Box? Adapter X1 Car Charging Cable X1 TEKSAN GO ON 600W Portable Power Station X1 MC4 Solar Charging User Cable X1 Manual X1... -
Page 9: Product Descriptions
4. Product Descriptions 1. DC Input 7. AC Power Switch 2. Display 8. AC Power Socket 3. QC3.0 Output 9. LED Lighting 4. USB-C Output 10. LED Lighting Button 5. DC/USB Power Switch 6. AC Power Indicator... -
Page 10: Led Display Symbols And Explanations
5. LED Display Symbols and Explanations LED Display Descriptions Battery Level Remaining full charge time or (% symbol flashes when remaining usage time charging) Symbols of the DC output section: Input/Output Power When the DC/USB power button is pressed, the symbols (DC, USB - A , USB - C) are always on. -
Page 11: Operation
6. Operation 1. AC Power Switch Press the AC power button for one second to energize the AC power output. When the AC power output is energized, the AC power indicator symbol lights up on the display screen. To de-energize the AC power output;... - Page 12 7. Protection Mode: TEKSAN GO ON 600W automatically alarms in case of short circuit or overload in an external device. In this case, the output device must be unplugged and the TEKSAN GO ON 600W must be restarted.
-
Page 13: Charge
7. Charge AC Charging Input PV Charging Input Car Charging Input... - Page 14 PV Charging 1. Place the TEKSAN GO ON Solar Panel under direct sunlight. 2. TEKSAN GO ON 600W can be charged by connecting to the solar panel. When the charging progress is 100% and remains constant, the product is fully charged.
-
Page 15: Discharge
8. Discharge Smartphone (10Wh) Laptop (41.4Wh) Drone (89.2Wh) About 40-45 times About 10-11 times About 5-6 times Led Bulb (20W) TV (75W) Electronic Approximately 20-23 Hours Approximately 6-7 Hours Hand Tools (40W) Approximately 11-12 Hours Mini Refrigerator (40W) Slow Cooker (200W) Approximately 11-12 Hours Approximately 2-3 Hours... -
Page 16: Specifications
9. Specifications Model TEKSAN GO ON 600W Capacity 576Wh (12.8V 45Ah) Output Waveform Pure Sine Wave Input AC Input: 27V 4.5A (120W Max.) Solar Panel Input: 12-29V (8A Max.) Car Charging Input: 12V 10A (Max.) Output AC Output: 220-240V 50Hz... -
Page 17: Important Notes
10. Important Notes 1. Product Fails to Supply Power a. Please make sure that the AC power switch or DC power switch is turned on. (If the ambient temperature is not in the range of -10°C-40°C, the product may not have power output). b. -
Page 18: Terms Of Warranty
Teksan Generator A.Ş., it gives warranty for the whole product including all of its parts against material, workmanship and production defects for the period specified above from the invoice date of the product. - Page 19 5. If the consumer exercises the right to free repair, and; - The same malfunction recurs within the warranty period, - The maximum time required for repair is exceeded, or - A report is issued by the authorized service station, seller, manufacturer or importer indicating that it is irreparable;...
- Page 20 a. Malfunction or damage caused by failure to observe the precautionary measures described in the user manual. b. Failure or damage caused by improper storage and handling (complete discharge of the batteries, not fully charged every 3 months when not in use). c.
- Page 21 10. To receive product repair service under warranty, please send the warranty card and product invoice together with the product. 11. The customer is responsible for delivering the product to Teksan Service Centers (Regional Offices) for repair service under warranty and taking it back after repair.
- Page 22 Address: Yenidoğan Mah. Type: Portable Power Edebali Cd. No: 12 Station PK:34791 Sancaktepe Model: GO ON 600W / İSTANBUL Tel: +90 850 281 90 00 Banderole and Serial No: ......Fax: +90 216 312 69 09 Warranty Period: 1 YEAR web adresi: www.teksan.com...
-
Page 23: Contact Us
This product is globally warranted for 12 MONTHS from the date of purchase. To ask a QUESTION or SUGGESTION about this product, please info@teksan.com or contact the most convenient service provider in the service list below. You can contact our nearest service center. - Page 24 19 Mayıs Nbrhd. Atatürk St. Sıtkı Bey Plaza Blok No:82/1D Kadıköy / ISTANBUL Tel: +90 850 281 90 36 Fax: +90 216 312 69 09 Email: kozyatagi@teksan.com ANKARA REGION SALES AND TECHNICAL SERVICE CENTER Bagdat St. 364 Zip Code:6374 OSTIM Yenimahalle / ANKARA Tel: +90 850 281 9022 Fax: +90 312 385 30 98 Email: ankara@teksan.com...
