SmartTrike 650 Manual

Baby bicycle

Advertisement

Quick Links

www.smartrike.com
DO NOT RETURN TO THE STORE
If you are experiencing problems with this
Thank you for buying smarTrike.
R
product, please call our HELP LINE.
For assembly issues or missing parts,
please call us.
USA: 1-855-SMTRIKE
Our SmarTrike assembly experts are ready
R
(1-855-768-7453)
to answer all your questions.
help@smart-trike.com
650
65002A
-1-

Advertisement

loading
Need help?

Need help?

Do you have a question about the 650 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SmartTrike 650

  • Page 1 www.smartrike.com DO NOT RETURN TO THE STORE If you are experiencing problems with this Thank you for buying smarTrike. product, please call our HELP LINE. For assembly issues or missing parts, please call us. USA: 1-855-SMTRIKE Our SmarTrike assembly experts are ready (1-855-768-7453) to answer all your questions.
  • Page 2 607100 607130 607120 607210 607150 607220 607110 607200 665141 695360 607190 Spare part 695280 650170 695410...
  • Page 3 On one side of the rear tube, insert “N” with a “B”. Repeat for the other side of the rear tube. Firmly insert black plug “M” into axle opening, as shown. Align spring lock with dropout hole in axle and push firmly into position, until piece "clicks"...
  • Page 4 Note: The red button aligns the hole. Put the screw on the slot of the connector. Insert part “ ” in the Insert part “D” into the mudguard “C”. body of the trike.
  • Page 5 CLICK! Push the apple rmly down to ly down to Turn the apple to face you. insert, slightly turn until you insert, slightl Push the apple until you " hear a click sound. With the red button on the right side of the trike, insert the wheel into the body of the trike.
  • Page 6 Use L1 to unscrew the back screw,(counter clockwise). Click “F” on to the rear axle. Use “L1” to secure the basket (clockwise).
  • Page 7 Take the seat “G”, push the screw through the seat hole. Screw into the most rear facing hole and firmly tighten By using the Allen key “L2”, remove with Allen key “L2”. screw by turning counter clockwise. With little force, push part “H”...
  • Page 8 Insert the parent handle “I” into the retaining Remove the securing pin with hole on rear of trike. Insert the pin with securing lock. safety lock. Turn the pin until you hear a click. WARNING: This product should be used on safe ground, it should not be used near steps, slopes, roadways, public highways or wet areas.
  • Page 9 Max. load of basket 2.2 lb / 1 kg Attach the four plastic in the Attach handles of the bag “K” to bottom of the bag “K” parent handle hook. Wrap hook and to the rim of the basket. loop strap around the parent handle. Max load 2.2 lb / 1 kg For the 15+ month stage, open the footrests by pulling it down.
  • Page 10 Insert part “P” into the the safetybar, until you hear a "click". -10-...
  • Page 11 Insert part “Q” into the the headrest until you hear a "click". Align part “R” into the designated holes in the center of the handlebar and push down firmly until it "clicks". -11-...
  • Page 12 Usage/Utilisation 15M+ Free-wheel Position: When the clutch is pulled away from the wheel, there is no pedal control. The wheel is in the free-wheel position. Child Control -12-...
  • Page 13 For the 24+ months stage, Push release button to place it fold up left and right footrest. back into frame. -13-...
  • Page 14 The child has pedal control when the clutch is: 1.Pushed closed. 2.Aligned with the front wheel. -16- -14-...
  • Page 15 -15-...
  • Page 16 6m-36m 6M + 9M + www.smartrike.com 12M + 18M + 24M + 30-36M 65028145603 55028136603 -16- -20-...
