- Page 1 Part No:D01965 INSTRUCTION MANUAL 18V Li-Ion CORDLESS DRILL DRIVER ROHS WARNING:Read and understand all instruction.
-
Page 2: Table Of Contents
Contents Cordless Drill…………………………………………..……………….…..1 Introduction……..……………………………………………………..……1 Technical data…………………………………………….………………..1 Safety precautions………………………………………..………………..2 Important safety instructions for charging unit and battery………..2 Electrical safety…………………………………………………………..3 Using an extension lead……………………………………………..……..3 Package contents…………………………………………………………….3 Main parts…………………………………………………………………...…4 Fitting accessories……………………………………………………………4 Inserting and removing drill bits…………………………………..……….4 Adjusting the torque…………………………………………………………..5 Drilling……………………………………………………………………..……..5 Speed selector…………………………………………………………….…….5 Wood Drilling…………………………………………………………...……….6 Metal Drilling……………………………………………………………….…….6 Inserting and removing the battery………………………………….………..6 Operation…………………………………………………………..………………7... -
Page 3: Cordless Drill
Cordless drill Instruction manual Read the instruction manual carefully before use, and keep it for future reference. Voltage/frequency Indicates the required voltage and frequency of the power supply to which the machine is connected. Battery Gives the voltage, strength and type of battery. Charging time Indicates the suggested battery charging time. -
Page 4: Safety Precautions
Safety precautions When using electrical machinery always follow local safety precautions regarding risk of fire, electric shock and injury. In addition to the instructions below, please read the safety precautions in the separate safety folder. 1. Remove the battery. When the electric tool is not in use, is undergoing maintenance or when a device such as a chuck or drill bit is to be replaced. -
Page 5: Electrical Safety
11. The battery must not be charged if the ambient temperature is below 10°C or above 40°C. 12. The ventilation openings on the charging unit must not be blocked. 13. The battery must not be short-circuited. In the event of short-circuit, high-intensity current is present. This may cause the battery to overheat, burst into flames or explode. -
Page 6: Main Parts
Main parts ON / OFF button Forward and reverse Drill chuck l i r elector Battery peed elector Button for battery latch Magnet block Fitting accessories Always remove the battery before fitting accessories. Inserting and removing drill or screw bits In addition to drill bits, the machine can also take screwdriver bits with a hexagonal shaft. -
Page 7: Adjusting The Torque
Adjusting the torque The torque is adjusted by rotating the torque setting（4）, the torque is greater when the torque setting is set on a higher position. The torque is less when the torque setting is set on a low position“1”denote lowest and “Drill bit image ” denote highest. Torque is set by material, you can adjust suitable torque, if the screw is long and material is hard, you can adjust to a bigger setting. -
Page 8: Wood Drilling
Important: NEVER adjust this switch whilst the drill is running .Always let it come to Wood Drilling For maximum performance, use high speed steel drills for wood drilling, turn the torque setting on the drill position“ ”. Begin drilling at a very low speed to prevent the bit When drilling through holes, place a block or wood behind the work piece to prevent rough edges on the back side of the hole. -
Page 9: Operation
Make sure that the rotation direction switch (2) is in the middle position to prevent the machine suddenly starting up. Push the battery into the base of the machine until it clicks into place. See drawing. Press the button (7) to remove the battery from the base of the machine. Operation Always follow the safety instructions and applicable rules. -
Page 10: Charging The Battery
Press the on/o button (1). You can regulate the machine’s rpm by the pressure applied to the switch. Once the switch (1) is released, the drill chuck stops and rotation ceases. Push the rotation direction switch (2) into the centre to lock the machine when it is switched o . -
Page 11: Cleaning And Maintenance
Don’t keep it in a plastic bag to avoid humidity build-up Warranty This Duratool product is guaranteed for a period of 1 Year, t from th date of purchase and applies only to the original purchaser.This guarantee only applies to defects arising from, defective materials and or faulty workmanship that become evident during the guarantee period only and does not include consumable items.The manufacturer will... -
Page 12: Servicing And Information
This will ensure that the safety of the power tool is maintained. Contact your retailer for any other issues. For further details visit WWW.Duratool.co.uk ENVIRONMENT Environment Should your appliance need replacement after extended use do not...
