Dear BEHRINGER users,
Page 1 of 10
Using the Behringer FCB1010 Floorboard
The following notes have been compiled from message posts submitted by a number of users on the FDP (Fender
Discussion Pages).
I have performed no editing on the content of these posts and they will be pretty much in the original form (thanks to
Cameron for sending me this compilation) .
In time, I will attempt to format the information presented here in the form of a tutorial - for now, you can just read
through and glean plenty of hints & tips...
***************************************************************************************
Dear BEHRINGER users,
At first we would like to thank you for showing interest in BEHRINGER products. The expression pedals are calibrated and completely checked
before they leave our Company. However it is possible that during transportation or influence of temperature the calibrated values have
become out off reach. Normally after using the pedal for several times, it should be gone. There is a way to re-calibrate your expression pedals.
Calibration – Self-test FCB1010:
Keep pedal 1 and 3 pressed while switching on the unit. The unit is in self-test-mode now. LED's are checking.
Wait until all pedal led's are burning. Push all pedals now (one at a time, including up and down) until all leds are off.
Wait until relay test is finished.
Press the down-button once.
Adjust the left expression pedal (A) to the lowest value. Once adjusted press UP.
Adjust the left expression pedal (A) to the highest value. Once adjusted press UP.
Adjust the right expression pedal (B) to the lowest value. Once adjusted press UP.
Adjust the right expression pedal (B) to the highest value. Once adjusted press UP.
Now the pedals are calibrated and there should be a value of 0-127 to the midi-output.
Another note:
There will be a software update coming up soon, with V-amp configuration and TC G-force.
We hope that we have been able to help you with this information.
http://www.patchwizard.com/pw_mig_FCB1010.htm
12/28/2002
