2-Product Description - Haier HW07-CP1439 User Manual

EN
Note:
2.1 Picture of appliance
1
Cotton
Synthetics
Mix
Baby clothes
Hygienic
Sportwear
Jeans
Cotton+
1. Detergent / Softener drawer
2. Display
3. Worktop
4. Programme selector
5. Rating plate
6. Service flap
7. Adjustable feet
2.2 Accessories
Check the accessories and literature in occordance with this list (Fig.: 2-3).
Inlet hose-
5 Blanking
assembly
1)
plugs
Bottom cover with felt only available for model HW08-*,sponge for HW07-*,
1)
HW09-*,HW010-*.

2-Product description

2 3 4
Fast wash
HW70-BP1439
Quick 15"
Daily Wash
Wool
Delicate
Handwash
Temp. Speed Steam Extra rinse Delay Start/pause
Bedding
A +++ 7k g 1400
Spin
Energy Capacity rpm
Speed up
5
6
7
Bottom cover
with felt
1)
2
1
T3
S2
T1 S3
1. Transportation bolts (T1-T4)
2. Back cover
3. Back cover screws (S1-S6)
4. Power cord
5. Water inlet valve
6. Drain hose
2
2
Sponge Drain hose
1)
bracket
3 4 5 6
T4
S1
S6
S5
T2
S4
2-3
Warranty User manual
card
-
7
