The foam port bung supplied is optional for any of the boundary settings but is required when the
speaker is positioned flat against a rear boundary. Ensure the bungs are fitted snugly into the port
without inserting them too far. You will find the level of bass is reduced but definition and bass extension
is increased. Experiment to see what you prefer.

Hub positioning and connectivity

The hub can be placed in any convenient location in the same room as the speakers. It can be located
on a shelf or in a cupboard, or mounted on a wall (see below) using two screws (not supplied). Please
note that the hub requires a mains electricity socket. If using the hub with other external sources such
as a TV, then it would be better to place it close to the sources alternatvely locate the hub near your Wi-Fi
router and connect it using an Ethernet cable (not supplied) if a wired internet connection is preferred.
1 2 3
80mm
4 5 6
3mm
7 8
10
Recommended screw:
No. 8 pan head
9
