SMT module de-soldering and rework Guidelines

2 Manual soldering tools

2.1 Manual soldering tools introduction

NO Manual soldering tools type
1 HAKKO 850 Hot air soldering gun 220~300W
2 Surface thermometer
3 Customized square hot air tip
4 Tweezers
Anti Electrostatic discharge wristband
5
6 Smoke absorber HAKKO 493
7 Repairing board cradle
8 PCB pre-heater
Module de-soldering and rework _UGD_V1.01
Manual soldering tools
Figure 1:

Figure 2: Customized square hot air tip

7
50/60Hz
07.12.2009
