Installation Instructions
Horizontal Ducting Preparation
Bottom Panel Screws
22
1
2
Locking Tabs
AK9228BS & AK9234BS Models Only
4. Remove bottom panel by: 1)
Removing (2) screws from left and
right sides of bottom panel. 2)
Pulling bottom panel toward front
of liner to release from locking
tabs.
5. Disconnect blower molex plug.
6. Remove blower from liner by
removing the (4) 3/16" x 3/8"
screws from the top of the liner.
Set screws aside for later usage.
