UE-36Li100BL
Issued Date
Issued Version
1. General Information
This specification defines the performance of rechargeable LiFePO4 battery pack
MASTER BATTERY, S.L., describes the type, performance, technical characteristics, warning and caution of the
battery pack. The battery pack support Bluetooth communication function. Through Android and IOS APP, can
read the battery status and information. Especially due to the Android system's openness, different smart phone
manufacturer will have their own different Bluetooth hardware version and customized feature Android systems.
So the APP may not work well on some smart phones (with Android system) due to compatible issue.
It is necessary for the customer to confirm whether the phone is compatible for the APP.
2. Specification (@Battery initial Temp25±5°C)
NO.
Items
Rated Capacity
1
Minimum Capacity
2
Energy
3
Nominal Voltage
4
Outgoing Voltage
5
Internal resistance
6
Limited charge voltage
7
Floating charge voltage
8
Standard charge current
9
Maximum charge current
10
Maximum discharge current
11
Pulse discharge current
12
Discharge cut-off voltage
>
2018-02-07
>
V00
Polígono industrial La Dehesa
C/ Dehesa Vieja,nº2 Nave 16
28052 Madrid (Spain)
Tel. (+34) 918 021 649
Fax. (+34) 917 750 542
info@masterbattery.es
LITHIUM IRON PHOSPHATE BATTERY
UE-36Li100BL
Criteria
100Ah
98Ah
3.84KWh
38.4V
≥38.4V
≤25mΩ
43.8±0.2V
41.4±0.2V
100A
100A
100A
400±100A/Continuous for 5±1s
10.0~11.5V
www.masterbattery.es
manufactured by
Remarks
@0.33C
01
Advertisement
Related Manuals for Master Battery UPOWER Ecoline UE-36Li100BL
Summary of Contents for Master Battery UPOWER Ecoline UE-36Li100BL
- Page 1 UE-36Li100BL manufactured by MASTER BATTERY, S.L., describes the type, performance, technical characteristics, warning and caution of the battery pack. The battery pack support Bluetooth communication function. Through Android and IOS APP, can read the battery status and information. Especially due to the Android system’s openness, different smart phone manufacturer will have their own different Bluetooth hardware version and customized feature Android systems.
- Page 2 UE-36Li100BL www.masterbattery.es Items Description Length: 520±3mm Dimension Width: 268±3mm Height: 222±3mm Weight Approx: 37.3±0.5Kg Charging: 0~45°C Operating Temperature Discharging: -20~60°C Recommended operating temperature: 15°C~35°C Self-discharge rate Residual capacity: ≤5%/month; ≤50%/years Less than 1 month: -20°C~45°C，45% RH~75％ RH Less than 3 months: -10°C~35°C，45% RH~75％ RH Storage Temperature & Humidity Range Recommended storage environment: 15°C~35°C, 45% RH~75％ RH Long time storage:...
-
Page 3: Product Performance
UE-36Li100BL www.masterbattery.es 4. Product Performance Items Criterion Testing method Rest for 1 hour after fully charged, then discharge with Rated Capacity 100Ah 0.33C current until the battery reaches the discharge cutoff voltage. Repeat above process for three times, if the discharge time is not less than 180 minutes, you can stop and define the Discharging current*time Minimum Capacity 98Ah... - Page 4 UE-36Li100BL www.masterbattery.es 5. Protective Circuit Specification The batteries are supplied with a LiFePO4 Battery Management System (BMS) that can monitor and optimized each single prismatic cell during charge & discharge, to protect the battery pack overcharge, over discharge, short circuit. Overall, the BMS helps to ensure safe and accurate running. Items Content Specification...
- Page 5 UE-36Li100BL www.masterbattery.es 6. Dimensional Drawing (Unit: mm) 7. Transportation • Based on the character of cell, proper environment for transportation of LiFePO4 battery pack need to be created to protect the battery. • Battery should be stayed in the warehouse 15ºC 〜 35ºC where it’s dry, clean, shade and well-ventilated. •...
- Page 6 Please read and follow the specification and caution remarks on battery surface before use the battery. Improper use may cause heat, fire, rupture, damage or capacity deterioration of the battery. MASTER BATTERY, S.L. describes is not responsible for any accidents caused by the usage without following our specification.
- Page 7 UE-36Li100BL www.masterbattery.es 10. Other Chemical Reaction Because batteries utilize a chemical reaction, battery performance will deteriorate over time even if stored for a long period of time without being used. In addition, if the various usage conditions such as charge, discharge, ambient temperature, etc.
